  1. Web Authoring Beyond the Basics Darryl Friesen, Peter Scott University of Saskatchewan Libraries Computers In Libraries ‘99

  2. HTML Terminology • Element • Portion of an HTML document • Start Tag, Content, and End Tag • Tag • Markup, not part of the content • Delimited by < and > (end tags also have /) • Attribute • Defines properties for tags and/or elements • Value may be case sensitive, attribute is not Computers in Libraries '99

  3. HTML Terminology • Comment • Portions of text that do not appear in the browser <!-- This is a comment --> TIP: do not use ‘--’ in a comment • Entity • Textual representation of characters or symbols that are hard to reproduce on the keyboard, or are not available in the document’s character encoding Computers in Libraries '99

  4. HTML Terminology <FONT COLOR=“YELLOW”>&copy; 1999</FONT> Start Tag Content Attribute Entity Attribute Value End Tag The entire piece is an Element Computers in Libraries '99

  5. Minimal HTML Document • All HTML documents should have at least these tags: <HTML> <HEAD> <TITLE>Document Title</TITLE> </HEAD> <BODY> Document Content </BODY> </HTML> Computers in Libraries '99

  6. Recommended Tags • The addition of DOCTYPE and META tags is recommended <DOCTYPE HTML PUBLIC “-//W3C/DTD HTML 4.0//EN” “http://www.w3c.org/TR/REC-html40/loose.dtd”> <HTML> <HEAD> <TITLE>Document Title</TITLE> <META NAME=“Name” CONTENT=“Content”> </HEAD> <BODY> Document Content </BODY> </HTML> Computers in Libraries '99

  7. HTML Versions • HTML 3.2 • Most common in use and most supported • The ‘everything and its dog’ version • Different levels of support for different elements in different browsers • HTML 4.0 Strict • Frames, targets, and many elements and attributes not allowed • Emphasizes structure over presentation • Meant for use with style sheets Computers in Libraries '99

  8. HTML Versions • HTML 4.0 Transitional • Strict plus additional presentational attributes, deprecated elements, targets • Why? Current support for style sheets is so poor • HTML 4.0 Frameset • Variant of Transitional for documents using frames Computers in Libraries '99

  9. DOCTYPE Tag • Specifies the version of HTML the document conforms to • DOCTYPE tag should be the first tag in the document, preceding even the HTML tag • Required for valid HTML 4.0 documents • Will theoretically allow the browser to parse and display the document better Computers in Libraries '99

  10. DOCTYPE Tag HTML 3.2 <!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 3.2 Final//EN"> HTML 4.0 Strict <!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.0//EN” "http://www.w3.org/TR/REC-html40/strict.dtd"> HTML 4.0 Transitional <!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.0 Transitional//EN” "http://www.w3.org/TR/REC-html40/loose.dtd"> HTML 4.0 Frameset <!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.0 Frameset//EN” "http://www.w3.org/TR/REC-html40/frameset.dtd"> Computers in Libraries '99

  11. METADATA • Metadata is “structured data about data” • Describes the document more than its content • Excellent example of metadata is the Library catalog • HTML provides the META tag as a means of inserting metadata into your HTML documents Computers in Libraries '99

  12. META Tag • Used to provide metadata about a document • Must be placed inside the HEAD element <HTML> <HEAD> <TITLE>Web Authoring: Beyond the Basics</TITLE> <META NAME=“Author” CONTENT=“Darryl Friesen”> <META NAME=“Author” CONTENT=“Peter Scott”> <META HTTP-EQUIV=“Refresh” CONTENT=“10; URL=http://library.usask.ca/“> </HEAD> <BODY> … </BODY> </HTML> Computers in Libraries '99

  13. Dublin Core • Standard set of metadata elements established through consensus by an international, cross-disciplinary group of professionals • Elements prefixed by DC. In META tag <META NAME=“DC.Creator” CONTENT=“Darryl Friesen”> Content Intellectual Property Instantiation Coverage Source Description Subject Type Title Relation Contributor Creator Publisher Rights Date Format Identifier Language Computers in Libraries '99

  14. Simple Example <TABLE> <TR> <TH>&nbsp;</TH><TH>Score</TH><TH>&nbsp;</TH> </TR> <TR> <TD>Los Angeles Lakers</TD><TD>97</TD><TD>Final</TD> </TR> <TR> <TD>Phoenix Suns</TD><TD>91</TD><TD>&nbsp;</TD> </TR> </TABLE> Tables - An Example Score Los Angeles Lakers 95 Final Phoenix Suns 98 Computers in Libraries '99

  15. Tables - TABLE Tag • Tables are defined using the TABLE element <TABLE attributes>…</TABLE> • WIDTH=“x” or WIDTH=“x%” Defines the table’s width in pixels, or as a percentage of the browser’s window size • ALIGN=[ left | center | right ] Controls the horizontal alignment of the table on the page • BORDER=“x” Sets the thickness of the border line (0 = no border) • CELLPADDING=“x” Controls the spacing between cells • CELLSPACING=“x” Controls the spacing within cells Computers in Libraries '99

  16. Tables - Rows • Table rows are defined using the TR element • Must be contained inside a TABLE element <TR attributes>…</TR> - Table Row • ALIGN=[ left | center | right ] Specifies the horizontal alignment of each cell in the row • VALIGN=[ top | middle | bottom | baseline ] Specifies the vertical alignment of each cell in the row • BGCOLOR=“color” Specifies the background color to use for each cell in the row Computers in Libraries '99

  17. Tables - Cells • Table cells are defined using the TH (header cell) or TD (data cell) elements, and must be contained inside a TR element <TH attributes>…</TH> or <TD attributes>…</TD> • WIDTH=“x” or WIDTH=“x%” • HEIGHT=“x” Suggests the cell’s width and height in pixels. Cell widths can also be expressed as a percentage of the table’s width. • ALIGN=[ left | center | right ] • VALIGN=[ top | middle | bottom | baseline ] Specifies the horizontal and vertical alignment of data in the cell • BGCOLOR=“color” Suggests a background color to use for the cell • NOWRAP Disables word wrap for the cell Computers in Libraries '99

  18. Tables - Pros, Cons & Tips Pros • Convenient method of displaying tabular data • Can be used as a layout tool to produce more interesting sites (i.e. simulates frame layout) Cons • Can causes problems those using non-visual browsers, large fonts, small screen resolution Tips • Make sure you have the same number of cells in each row and column, including the ROWSPAN and COLSPAN values! • Netscape and Internet Explorer treat table and cell WIDTHs differently (suggested vs absolute widths) Computers in Libraries '99

  19. Tables - Revised Example <TABLE CELLPADDING=3 CELLSPACING=0 BORDER=0 WIDTH=200> <TR BGCOLOR="#CC9966"> <TH>&nbsp;</TH><TH COLSPAN=2 ALIGN=LEFT>Score</TH> </TR> <TR BGCOLOR="#CCCC99"> <TD WIDTH="125">Los Angeles Lakers</TD> <TD>97</TD> <TD><FONT COLOR="red">Final</FONT></TD> </TR> <TR BGCOLOR="#CCCC99"> <TD>Phoenix Suns</TD><TD>91</TD><TD>&nbsp;</TD> </TR> </TABLE> Score Los Angeles Lakers 97 Final Phoenix Suns 91 Computers in Libraries '99

  20. Frames • Frames allow the browser window to be split into discrete sections (frames) • Each frame displays its own HTML document which can be manipulated independently of the others • Actions in one frame can update the contents of another (by using targets) Computers in Libraries '99

  21. Frames - Pros and Cons • Pros • Frames can make the site easier to navigate • Cons • Frames can make the site harder to navigate • Individual portions cannot be addressed directly (using a URL) • Not supported by many browsers Computers in Libraries '99

  22. <HTML> <HEAD> <TITLE>This document uses frames</TITLE> </HEAD> <FRAMESET COLS="200,*"> <FRAME NAME="nav" SRC="navigation.html"> <FRAME NAME="main" SRC="main.html"> <NOFRAMES> <BODY BGCOLOR="#FFFFFF"> Hey, you can't see frames! </BODY> </NOFRAMES> </FRAMESET> </HTML> Frames - An Example Computers in Libraries '99

  23. Frames - FRAMESET Tag <FRAMESET attributes>…</FRAMESET> • ROWS=“x,y, …” Defines the number and height of rows in the frame set • COLS=“x,y, …” Defines the number and width of columns in the frame set • Frame sets can nested (i.e. 2 rows, top with 2 columns, bottom with 3 columns) • Lengths can be specified 3 ways • Pixel widths <FRAMESET COLS="200,*"> • Percentages <FRAMESET COLS=”25%,*"> • Relative sizes <FRAMESET COLS=”2*,3*"> Computers in Libraries '99

  24. Frames - FRAME Tag • Individual frames are defined using the FRAME element, and must be contain inside a FRAMESET <FRAME attributes>…</FRAME> • NAME=“name” Gives the frame a name so that it can be referenced later • SRC=“URL” Specifies the HTML document to display in the frame • MARGINWIDTH=“x” MARGINHEIGHT=“x” Specifies the width and height of the margins inside the frame • FRAMEBORDER=[ 0 | 1 ] Specifies whether or not the frame has a visible border or divider • SCROLLING=[ yes | no | auto ] Specifies whether or not scrollbars are provided for the frame • NORESIZE Prevents individual frames from being resized Computers in Libraries '99

  25. Frames - NOFRAMES Tag <NOFRAMES>…</NOFRAMES> • NOFRAMES defines alternate content for browsers that do not support frames • The content should be meaningful, NOT a message telling the user to upgrade the browser • Since the outermost FRAMESET tag replaces the normal BODY tag in the document, a BODY tag should be placed inside the NOFRAMES tag • Only one NOFRAMES element can be present Computers in Libraries '99

  26. Frames - Targets • Targets specify in which frame the target of a link should be displayed • Implemented as attributes to A, BASE, FORM and LINK tags • Value of the attribute is the name given to the frame using the FRAME tag <FRAME NAME="main" SRC="main.html"> <FORM ACTION=“/cgi-bin/search.cgi” TARGET=“main”> … </FORM> <A HREF=“cil99.html” TARGET=“main”>CIL ‘99</A> <BASE TARGET=“main”> <LINK TARGET=“main” … > Computers in Libraries '99

  27. Frames - Special Targets • There are a number of target names that have special meaning: _top • Renders the specified link in the full browser windows, essentially removing all the frames _self • Renders the specified link in the current frame (used to override the default target given in the BASE and LINK tags) _parent • Renders the specified link in the immediate parent frameset _blank • Renders the specified link in a new unnamed window Computers in Libraries '99

  28. Style Sheets • Style sheets are simply a set of rules that tell the browser (or printer, or document reader etc.) how to format and present a document • By separating the document structure from its presentation and using style sheets we can: • create documents that are more portable • format documents differently for different devices • ease the burden of site management • Several different ‘standards’: • Cascading Style Sheets (CSS), • eXtensible Style Sheet Language (XSL), • Document Style Semantics and Specification Language (DSSSL) Computers in Libraries '99

  29. Cascading Style Sheets (CSS) • Each formatting rule is made up of a selector (usually an HTML element) and a style to be applied • Styles are made up of one or more properties, each with a value Syntax: selector { property: value } selector { property1: value1; property2 : value 2 } Example: H1 { font-size: x-large; color: red } H2 { font-size: large; color: blue } Computers in Libraries '99

  30. CSS - Selectors • Basic Selectors • Selectors are basic HTML elements H1 { font-size: x-large; color: red } • Class Selectors • allows the same element to have different styles CODE.html {color: yellow } CODE.css {color: orange } • class can be omitted allowing the style to be applied to any element .note {font-size: small } Computers in Libraries '99

  31. CSS - Selectors • Contextual Selectors • two or more selectors separated by white space • style only applied to elements that match hierarchy P EM {background: yellow } • Grouping Selectors • Selectors separated by a comma allow the same style definition for each element H1, H2, H3 { font-family: Arial, san-serif; font-weight: medium } Computers in Libraries '99

  32. CSS - Common Properties Font Properties font-family: [ font | serif | san-serif | monospace ] font-style: [ normal | bold | bolder | lighter ] font-size: [ x-small | small | medium | large | x-large larger | smaller x pt | x in | x pc ] Color & Background Properties color: [ color name | “#rrggbb” ] background-color: [ color name | “#rrggbb” | transparent ] background-image: [ URL | none ] Computers in Libraries '99

  33. CSS - Common Properties (con’t) Text Properties text-decoration: [ none | underline | line-through ] text-align: [ left | right | center | justify ] vertical-align: [ sub | super | top | middle | bottom ] text-indent: [ x in | x cm | x pt | x % ] line-height: [ normal | x | x in | x cm | x pt | x % ] text-transform: [ none | lowercase | UPPERCASE | Capitalize ] Computers in Libraries '99

  34. CSS - Using Style Sheets • Embedded Style Sheets • Use the LINK tag inside the HEAD element <STYLE TYPE=“text/css” MEDIA=“screen”> <!-- BODY { background: white; color: black } --> </STYLE> • External Style Sheets • use the LINK tag inside the HEAD element <LINK REL=“StyleSheet” HREF=“somestyle.css” TYPE=“text/css”> • Inline Styles <P STYLE=“color: red”>Hi, I’m red.</P> Computers in Libraries '99

  35. CSS - Using Style Sheets • CLASS Attribute • Assumes style is defined using one of the previous methods • CLASS attribute specifies the style to use This is <CODE CLASS=“css”>CSS</CODE> This is <CODE CLASS=“html”>HTML</CODE> • SPAN and DIV Elements • Simple containers that allow a style to be applied to HTML that is not part of an HTML element, but on their own do nothing to alter the format of the document • SPAN is for ‘inline’ use; DIV for block use .highlight: { background: yellow } This is <SPAN CLASS=“highlight”>Important!</SPAN> Computers in Libraries '99

  36. CGI and Forms  The server passes the data to the CGI program  Browser sends the form data to the server  The server sends the results back to the browser  The CGI program processes the data and passes back the results (HTML)  User fills out the form Computers in Libraries '99

  37. CGI and Forms • Common Gateway Interface (CGI) is a standard method for external programs to communicate with information servers (such as web servers) • (Almost) every web page containing forms will require a CGI programs to process the form data • Processing done on the server by a program or script written in Perl, C, Java etc. • Typically requires special access to the server, advanced knowledge of how the server works, as well as programming skills Computers in Libraries '99

  38. Creating Forms • Interactive forms are defined with the FORM tag • Each element of the form (input boxes, buttons etc.) must appear within the FORM element <FORM attributes>…</FORM> • METHOD=[ GET | POST ] Specifies the method used to send the form data to the server. POST is most often used. • ACTION=“URL” Specifies the URL of the CGI program that will process the form data <FORM METHOD=“POST” ACTION=“/cgi-bin/search.cgi”> Computers in Libraries '99

  39. Forms - Common Elements • Text input fields, radio button and checkbox controls, and buttons are done using the INPUT tag <INPUT attributes> • NAME=“name” Identifies the form element by name • TYPE=[ text | password | hidden (text elements) checkbox | radio (controls) submit | reset ] (buttons) • VALUE=“value” Specifies a default value for the element • SIZE=“x” Specifies a width for text input elements • CHECKED Indicates a control is initially checked Computers in Libraries '99

  40. Forms - Common Elements • Drop menus and lists are created using the SELECT element <SELECT attributes> … </SELECT> • NAME=“name” Identifies the form element by name • SIZE=“x” Indicates the number of elements of the total list that are visible at any one time (i.e. drop down menu vs scrolling list box) • MULTIPLE Allows the selection of more than one options from the list Computers in Libraries '99

  41. Forms - Common Elements • Each item in the drop menu or list is defined using the OPTION element <OPTION attributes> display value </OPTION> • VALUE=“value” Specifies the value sent to the CGI program when the item is selected • SELECTED Indicates the item should be initially selected in the list. • display value This is the text that appears in the list or drop down, and can be different that the value sent to the CGI program <SELECT NAME=“email”> <OPTION VALUE=“Darryl.Friesen@usask.ca>Darryl</OPTION> <OPTION VALUE=“scottp@library.usask.ca>Peter</OPTION> </SELECT> Computers in Libraries '99

  42. Server Side Includes • Most web servers have the ability topre-process an HTML document before sending it to the client browser. • Server Side Includes (SSI) take advantage of this feature, and allow the documents to become more dynamic • Basic idea: the web server looks at the content of the HTML file, replacing special embedded commands with other text • Usually some flag indicating the document uses SSI (file extension of .phtml is common) Computers in Libraries '99

  43. Server Side Includes • Syntax: <!--#element attribute=value attribute=value ... --> • Including the contents of another file: <!--#include virtual=“/include/menubar.html” --> • Stamping the document with the current date and time: <!--#echo var=“DATE_LOCAL" --> • Showing the date the file was last changed: <!--#echo var="LAST_MODIFIED" --> Computers in Libraries '99

  44. Tired? Need to stretch? Computers in Libraries '99

  45. JavaScript - Resources • Website Abstraction(www.wsabstract.com) • Dark Library(www.darklibrary.com) • JavaScript WebRing(leden.tref.nl/ageytenb/jswr/) • My Own WebRing(library.usask.ca/~scottp/webring/) Computers in Libraries '99

  46. JavaScript - Rotating Banners • JavaScripts leading to other JavaScripts • Example: • Amazon Rotating Computers in Libraries '99

  47. Design Issues • Sites for discussion • Arkansas State University • Baxter County Library • John Brown University • North Arkansas College • Phillips Community College • University of Arkansas, Little Rock • University of Central Arkansas Computers in Libraries '99

  48. The Dark Side of the Net • Free pages • Advertising • URL Cloaking • Monica's Story (www.pcpages.com/pick/monica) Computers in Libraries '99

  49. Remote Resources • Graphics • Editors and web-based authoring tools library.usask.ca/html Computers in Libraries '99

  50. HTML & CSS Resources W3C - Word Wide Web Consortium • www.w3.org • www.w3.org/TR/REC-html40/ • www.w3.org/Style/CSS/ Web Design Group • www.htmlhelp.com • www.htmlhelp.com/reference/html40/ • www.htmlhelp.com/reference/css/ Index Dot HTML • www.blooberry.com/html/ Computers in Libraries '99
