Understanding Explosives: Types, Detection, and Notable Incidents

shanon avatar
shanon
32 diapositives · 757 Views · Sep 19, 2014

This article explores the science of explosions, detailing how they occur and the components of explosive devices, including fuels, oxidizers, and igniters. It distinguishes between low and high explosives, as well as primary and secondary explosives, and their respective applications. Additionally, the article discusses techniques for detecting explosives, such as x-ray machines and trained canine units, and highlights significant bomb threats and attacks, including the Oklahoma City and Olympic Park bombings.

#understanding explosives: types, detection, and notable incidents #understanding explosives: types, detection, and notable incidents ppt #powerpoint #presentation
Understanding Explosives: Types, Detection, and Notable Incidents - slide 1
01 / 32Understanding Explosives: Types, Detection, and Notable Incidents
1 / 17

Télécharger la présentation

Understanding Explosives: Types, Detection, and Notable Incidents
Une image / un lien ci-dessous est fourni (tel quel) pour télécharger la présentation

Politique de téléchargement : le contenu du site vous est fourni TEL QUEL pour votre information et votre usage personnel ; il ne peut être vendu, concédé sous licence ni partagé sur d’autres sites sans l’accord de son auteur.Le contenu vous est fourni TEL QUEL, pour votre information et votre usage personnel uniquement. Téléchargez la présentation en cliquant sur ce lien. Lors du téléchargement, si vous ne parvenez pas à télécharger une présentation, l’éditeur a peut-être supprimé le fichier de son serveur.Pendant le téléchargement, si vous ne parvenez pas à obtenir une présentation, le fichier a peut-être été supprimé par l’éditeur.

F I N

Plus de contenu associé

Transcription de la présentation

  1. ForensicsExplosions

  2. Explosives An explosion is the product of combustion accompanied by the creation of gases and heat at a rapid rate. As these gases are release from confinement, they produce a blast effect, or an outward rush of gas—at a rate of up to 7,000 mph. These are powerful enough to overthrow walls and collapse roofs.

  3. Explosives An explosive device is comprised of three components: • A type of fuel • An oxidizer • An igniter

  4. Explosives There are two kinds of explosives: • Low Explosives— are explosives with a velocity of detonation less than 1,000 meters per second • High Explosives— are explosives with a velocity of detonation greater than 1,000 meters per second.

  5. Low Explosives • Have a slow burn rate • Produce a propelling or throwing action, making them suitable as propellants for ammunition or sky rockets • Include black powder and smokeless powder

  6. High Explosives • Can detonate almost instantaneously at rates of 1,000 to 8,500 meters per second • Produce a shattering or smashing effect • Usually require a primer and blasting cap • Include: Dynamite TNT PETN RDX

  7. High Explosives Classified into two groups: Primary Explosives --easily detonated by heat and shock Secondary Explosives --relatively insensitive to heat and shock and normally needs to be detonated by a primary explosive

  8. Explosives Primary Explosives • These explosives are ultrasensitive to heat, shock, or friction and under normal conditions will detonate violently instead of burning. • They are used to detonate other explosives through a chain reaction and referred to as primers • These explosives provide the major ingredient of the blasting cap

  9. Explosives Secondary Explosives These explosives are relatively insensitive to heat, shock or friction Will normally burn rather than detonate Used in majority of commercial and military blastings

  10. Explosives An x-ray machine can reveal concealed bombs in luggage or mail packages Pipe bomb Grenade

  11. Explosives Trained dogs are able to detect the scent of explosives, even a few yards away. They are useful anywhere--airplanes, schools, hotels, parking lots, etc.

  12. Explosives A bomb scene investigator needs to be able to recognize and collect appropriate samples of un-detonated residue from the site. A high explosive or a contained low explosive creates a crater at the origin of the blast.

  13. Collection of Residue • All loose soil and other debris must be removed immediately from the interior of the hole and preserved for laboratory analysis • Materials blown away from the blast may too retain explosive residues. • All personnel searching the site must wear disposable gloves, shoe covers and overalls • Materials are best preserved, separated and sealed in metal containers.

  14. Explosives Bomb scene investigators use: • Wire mesh screens to sift through the debris • The Ion Mobility Spectrometer (IMS) is a portable detection machine that uses a vacuum to collect explosive residues • The Color Spot test for identification of common explosives • An Infrared Spectrophotometer to produce a unique “fingerprint” for identification

  15. Explosives • Ion Mobility Spectrometer The vaporized residue is converted to electrically charged ions that move through an electric field. Different ions move at different rates depending on their size and structure, which allows for identification.

  16. Bomb Threats Once a bomb threat or a suspicious package has been detected, the bomb squad or a robot can be dispatched to disarm it.

  17. Explosives Tele-operators can navigate a robot from a safe distance to search and remove a bomb.

  18. Olympic Park Bombing On July 27, 1996, a back- pack was left under a park bench near Centennial Olympic Park. Around 1:30am the back- pack exploded, sending nails and shrapnel over 100 yards into the air.

  19. Olympic Park Bombing Though there were many people in attendance during the explosion, only two were killed, Alice Hawthorne and Melih Uzunyol. Over 100 were injured.

  20. Olympic Park Bombing After a lengthy investigation, the FBI searched and apprehended their suspect, Eric Robert Rudolph.

  21. Olympic bombing (Atlanta 1996) • https://www.youtube.com/watch?v=8Gkz-TaSRXc

  22. Oklahoma City Bombing On April 19, 1995, Timothy McVeigh detonated a rental truck full of fertilizer and fuel oil which exploded, obliterating half of the nine-story building. This explosion killed 168 men, women and children, and injured 600.

  23. Oklahoma Coty bombing • https://www.youtube.com/watch?v=l08zD9Pn1jk

  24. https://www.youtube.com/watch?v=-xiXroQp8t4 Boston bombing
