Generating Heap-bounded Programs

1. Generating Heap-bounded Programs Walid Taha, Stephan Ellner (Rice University) Hongwei Xi (Boston University)

2. Why do languages matter? The need for well thought-out languages (or “models”) will only increase in the future • Applications are constantly growing in complexity • The need for simplicity is constant • Can we think outside our languages? • Using old languages means making old mistakes Carefully designed languages allow us to • Ensure strong safety properties • Preserve desirable reasoning principles • Ultimately: Reduce developer/owner cost

3. FORTRAN C Assembly/C C/C++ Embedded systems:An area of growing demand

4. Trouble with High-level Languages High-level languages deprive programmer of control over basic resources Programming embedded systems requires attention to various kinds of resources: • Concrete resources: • Abstract resources: • Critical sections, capabilities, power, bandwidth, availability, security, freedom of race conditions… Resource-bounded languages provide guarantees But they limit expressivity Can we combine the best of both worlds?

5. I2 I2 I2 I1 P O Traditional Programming I P O LFPL [Hofmann, ’99/00] I1 I1 P1 P1 P2 P2 O O Multi-Stage Programming (MSP) [Taha, Sheard ’97] Multi-Stage Programming (MSP) [Taha, Sheard ’97] I2 I1 P1 P2 O Resource Aware Programming [EMSOFT ’03]

6. Insertion sort This can be resource-bounded program: let rec insert(a,l) = case l of nil -> cons(a, nil) | cons(b,t) -> if a < b then cons(a, cons(b, t)) else cons(b, insert(a, t)) let rec sort(l) = case l of nil -> nil | cons(a,t) -> insert(a, sort(t))

7. I2 I2 I2 I1 P O Traditional Programming I P O LFPL [Hofmann, ’99/00] I1 I1 P1 P1 P2 P2 O O Multi-Stage Programming (MSP) [Taha, Sheard ’97] Multi-Stage Programming (MSP) [Taha, Sheard ’97] I2 I1 P1 P2 O Resource Aware Programming [EMSOFT ’03]

8. Hoffman’s (RB) LFPL • Allows heap-bounded manipulation of dynamic data structures • Can be translated into imperative C programs that have competitive performance (without optimizations) • How does it work: • You want to avoid duplicating structures • Linear types. Default: Variables used only once

9. Insertion sort in LFPL This is a resource-bounded program [Hoffman’99/00] let rec insert(d,a,l) = case l of nil -> cons(a, nil) at d | cons(b,t) at e -> if a < b then cons(a, cons(b, t) at e) at d else cons(b, insert(e,a, t)) at d let rec sort(l) = case l of nil -> nil | cons(a,t) at d -> insert(d, a, sort(t))

10. I2 I2 I2 I1 P O Traditional Programming I P O LFPL [Hofmann, ’99/00] I1 I1 P1 P1 P2 P2 O O Multi-Stage Programming (MSP) [Taha, Sheard ’97] Multi-Stage Programming (MSP) [Taha, Sheard ’97] I2 I1 P1 P2 O Resource Aware Programming [EMSOFT ’03]

11. Multi-stage programming (MSP) • Provide abstraction mechanisms like: polymorphism, higher-order functions, exceptions, … • “Abstractions without guilt” through prg. generation • Without damaging the static typing discipline

12. Multi-stage programming (MSP) Three staging annotations: Simplified typing rules:

13. x P n xn Small example: Exponentiation Single stage: let rec exp(n:int, x:real):real = if n = 0 then 1.0 else if even (n) then sqr (exp(n div 2,x)) else x * (exp(n - 1,x));;

14. x P1 P2 xn n Small example: Exponentiation Two stage: let rec exp(n:int, x:<real>):<real>= if n = 0 then <1.0> else if even (n) then <sqr~(exp(n div 2,x))> else <~x*~(exp(n - 1,x))>;; Only things in gold are left for second stage

15. Small example: Exponentiation To use the staged exp we simply write: <f(x) =~(exp(5,<x>))>;; The result for the second stage is: <f(x)= x*(sqr(sqr(x*1.0)))> No recursion Just 4 ops!

16. I2 I2 I2 I1 P O Traditional Programming I P O LFPL [Hofmann, ’99/00] I1 I1 P1 P1 P2 P2 O O Multi-Stage Programming (MSP) [Taha, Sheard ’97] Multi-Stage Programming (MSP) [Taha, Sheard ’97] I2 I1 P1 P2 O Resource Aware Programming [EMSOFT ’03]

17. Why RAP (= MSP + RB) is hard Two key points: • Want to guarantee RB before generation • Must somehow isolate expressive features, even when used in same language. Naïve combination doesn’t work. For LFPL: • Can just combine non-linear and linear environments • Some first-stage values must be linear • Some second-stage values can be non-linear

18. RAP language for LFPL • GeHB: A language for “Generating Heap-Bounded programs” • Intuitively: Program/configure on PC, execute on embedded/real-time platform • All done in one language that integrates the two platforms very closely • Static analysis (type system) guarantees that • The two platforms never get confused • Before any programs are generated, we know that all generated programs will be resource bounded.

19. Type System

20. Summary of Results • Evaluation (generation) preserves types • Standard type preservation • Code values are easily turned into LFPL code • Requires a form of let-floating • Can only be done for well-typed terms • Generated LFPL code is well-typed • And Hofmann shows how to translate to C • No lost expressivity (GeHB is strictly more expressive)

21. Safe, fast, and generic insert. sort let rec sort_gen(myLess,list) = let [less] = myLess in (* Co-monadic co-bind *) <let rec insert(d,a,l) = case l of nil -> cons(a, nil) at d | cons(b,t) at d' -> if ~ (less(<a> ,<b> )) then cons(a, cons(b, t) at d') at d else cons(b, insert(a, d', t)) at d in let rec sort(l) = case l of nil -> nil | cons(a,t) at d -> insert(d, a, sort(t)) in sort(~list)>

22. Summary • GP languages give us expressivity • But no guarantees about resources • RB languages give us resource bound • But limit expressivity • MSP allows us to express staging • Carefully designed RAP languages give the programmer more control without becoming too low-level or unsafe. Claim: Underlying idea is general & tractable.

23. Future work on RAP Success requires targeting three areas: • Design an theory • Lots of basic PL research needed here • In RB languages, MSP, and how to combine • Applications • Currently: device drivers and n.w. interface cards • Implementation and engineering aspects • Multiple target platforms • Essential for technology transition
