  1. USB Driver and Linux Device Model Dr A Sahu Dept of Comp Sc & Engg. IIT Guwahati

  2. Outline • USB Drivers Overview • URB (USB request Block) • Writing a USB Driver • Linux Device Model • Kobjects, Ksets and Subsystem • Hot plug event generation • Bus, Device, Driver and Class • Dealing with Firmwire • Last/Next Class Agenda • Summery after mid semester, Question pattern, Assignments

  3. USB driver over view • USB drivers lives between different kernel subsystem (blk,net,char..) and USB HW controller • USB core provide an interface to access for USB drivers to use to access and control USB hw • Connect without worrying the different types of USB hardware controller that are present in the system USER VFS layer Blok layer Net Layer Char Layer TTY Layer …. USB device driver kernel USB Core USB host controller Hardware

  4. USB Device Basic • USB device is complex thing • Linux kernel provides a subsystem USB Core to handle most of the complexity • USB device consist of configuration, interface, endpoints • USB device bind to USB interfaces not to entire USB devices Device Config Interface USB Drivers Endpoint Endpoint Endpoint Interface USB Drivers Endpoint Endpoint Endpoint

  5. USB: Endpoints • USB endpoint can carry data in only one direction either host to dev (OUT endpoint) or host to dev (IN endpoint) • Endpoints are 4 types: that describe how data is transmitted • Control: allow access to diff parts of USB dev. Used for conf dev, retrieve info, send cmd, retrieve status. This is small size end points call endpoint 0 • Interrupt:small amount of data at fixed rate: keyborad/mice • BULK:Large data with no loss : printer, storage, network • ISOCHRONOUS: large data, not guaranteed, stream audio/video • Structusb_host_endpoint: address, bitmask attaributes, Maxpacket size that point can handle , Intr Interval

  6. USB Interfaces • USB end points are bundled up with interfaces • One interface handle one type of logical connection (a kbd,mice or a audio) • Some USB can handle multiple interfaces USB speaker with kbd for buttons and USB audio stream • USB interfaces may have alternate setting which are diff choices for param of the interface • Structusb_interface: array of altsetting, num_altsetting, cur_altsetting, minor

  7. USB Configuration • USB interface are themselves bundle up with configurations • A USB device can have multiple conf and might switch between them inorder to change the state of device • A single conf is activated at a time • Summery: • Device: one or more Conf • Conf : one or more Interface • Interface: one or more setting • Interface: one or more end points

  8. USB & Sysfs • /sys/dev/pci0000:00/000:9:0/usb2/2-1 • Long device path • First USB device is a root hub: USB controller usually connected in a PCI device • Whole USB bus connect to root hub • Every USB device take number of root hub as first number in its name, followed by character and then the number of port that device connected. • Root_hub-hub_port:config.interface

  9. USB urb (USB Request Block) • Linux kernel communicated with all USB device with URBS • Urb is used to send/receive data from a specific USB endpoints on a specific usb device in async manner • Every end point can handle queue of urbs • Lifecycle of urb • Created by USB dev driver • Assigned to specific endpoints of a USB dev • Submitted to a USB core by USB driver • Submitted to USB host Controller by USB core • Processed by the USB Host Controller that makes a USB transfer to the device • When urbb is completed, USB host controller notify the dev driver

  10. Enumeration steps • The user plugs a device into USB port. • Hub detects the device • Host learns of new device • Hub resets the device. • Hub establishes a single path between device and a bus.

  11. Device Driver Framework • USB device drivers are registered and deregistered at the subsystem. • A driver must register 2 entry points and its name. • For certain USB devices, a driver registers file operation and minor number.

  12. structusb_driver { const char *name; void * (*probe)(structusb_device *, unsigned int, const structusb_device_id *id_table); void (*disconnect)(structusb_device *, void *); structlist_headdriver_list; structfile_operations *fops; int minor; struct semaphore serialize; int (*ioctl) (structusb_device *dev, unsigned int code, void *buf); const structusb_device_id *id_table; };

  13. Entry Points Framework USB driver has two entry points to normal drivers :- • void *probe ( structusb device *dev, unsigned int interface, const structusb_device_id *id table) – -This entry point is called whenever a new device is attached to the bus. void disconnect ( structusb device *dev, void *drv context) - This function is called whenever a device is disconnected.

  14. Registering a USB Driver • We register our USB driver with USB subsystem using usb_register (struct usb_driver *u_drv) :- This is usually invoked in our init_module(). • Un-registering of the USB driver is usually performed using :- usb_deregister (struct usb_driver *drv) :-This is usually invoked in our cleanup_module().

  15. Hot plug static structusb_device_idskel_table [ ] = { { USB_DEVICE(USB_SKEL_VENDOR_ID, USB_SKEL_PRODUCT_ID) }, { } /* Terminating entry */ }; MODULE_DEVICE_TABLE (usb, skel_table);

  16. Descriptor Explained • A USB device when attached will be enumerated. • Enumeration means assigning the device a unique number. • The unique number must range from 1-127. • A descriptor is basically a structure containing information about the device and its properties.

  17. USB Request Block • A driver passes messages to the USB subsystem using URB • A URB consists of relevant information for executing a USB transaction. • It delivers the data and status back. • Execution of an URB is an asynchronous operation. Ongoing transfer for a particular URB can be cancelled at any time. • Each URB has a completion handler. • URB’s can be linked.

  18. Linux device model • The model provides abstraction, which supports: • Power management and system shutdown • Understanding of the system’s structure • Right order to shutdown • Communication with user space • Sysfs • Knobs for changing operating parameters • Hot-pluggable devices • Device classes • Describe devices at a functional level • Object lifecycles • Reference count

  19. Device model tree • Sysfs: /proc, /dev, /sysfs • Authors can ignore the model, and trust it • Understanding device model is good, if struct leaks • Ex. the generic DMA code works with struct device • Advanced material that need not be read bus devices class pci0 usb Inp dev drivers device mice Dev0:10 Usb-hid usb2 port1 Dev1-10

  20. Object oriented programming • Abstract Data typing • Information hiding • Encapsulation • Inheritance • Derive more specialized classes from a common class • Polymorphism • Refers to the object's ability to respond in an individual manner to the same message • Dynamic binding • Refers to the mechanism that resolves a virtual function call at runtime • You can derive modified action that override the old one even after the code is compiled . Kobject, Kset Bus, driver, device, partition… hotplug(), match(), probe(), kobj_type

  21. Kobject, Ksets, and Subsystems • struct kobject supports • Reference counting of objects • Tracking the lifecycle • Sysfs representation • A visible representation • Data structure glue • Made up of multiple hierarchies with numerous links • Hotplug event handling • Notify user space about the comings and goings of hardware • $(KERNELDIR)/lib/kobject*.c

  22. Kobjectbasics • structkobject { • const char * k_name; • char name[KOBJ_NAME_LEN]; • structkrefkref; • structlist_head entry; • structkobject * parent; • structkset * kset; • structkobj_type * ktype; • structdentry * dentry; • }; • structkset { • struct subsystem * subsys; • structkobj_type * ktype; • structlist_head list; • spinlock_tlist_lock; • structkobjectkobj; • structkset_hotplug_ops * hotplug_ops; • }; Directory entry, maybe for sysfs

  23. Kobject basics Contd.. • Embedded kobjects • A common type embedded in other structures • A top-level, abstract class from which other classes are derived • Ex. in ch3,struct cdev { struct kobject kobj; struct module *owner; struct file_operations *ops; dev_t dev; }; • struct kobject *kp = …; • struct cdev *device = container_of(kp, struct cdev, kobj);

  24. Kobject basics Contd.. • Release functions • Even predictable object life cycles become more complicated when sysfs is brought in; user-space programs can keep a reference for an arbitrary period of time. • Every kobject must have a release method. • The release method is not stored in the kobject itself • kobject types – kobj_type struct kobj_type { void (*release)(struct kobject *); struct sysfs_ops * sysfs_ops; struct attribute ** default_attrs; }; • The kobject contains a field, pointer ktype • If kobject is a member of kset, the pointer provided by kset • struct kobj_type *get_ktype(struct kobject*kobj);

  25. Kobject basics Contd.. • Initialization • Set the entire kobject to 0, memset() • Set up some of fields with kobject_init(), ex. reference count to 1 • Set the name by kobject_set_name(kobj, char *format, …) • Set up the other field, such as ktype, kset and parent • Reference count • struct kobject *kobject_get(struct kobject *kobj); //++ • void kobject_put(struct kobject *kobj); //--, 0 to cleanup • “struct module *owner” in struct cdev? • The existence of a kobject require the existence of module that created that kobject. ex. cdev_get()

  26. Kobject hierarchies, kset • The parent pointer and ksets • “parent” points to another kobject, representing the next level up • “kset” is a collection of kobjects • kset are always represented in sysfs • Every kobject that is a member of a kset is represented in sysfs

  27. ksets • Adding a kobject to a kset • kobject’skset must be pointed at the kset of interest • Call kobject_add(structkobject *kobj); // reference count ++ • kobject_init( ) + kobject_add( )  kobject_register( ) • Removing from the kset • kobject_del( ) • kobject_del( ) + kobject_put( )  kobject_unregister( ) • Operation on ksets • void kset_init(structkset *kset); • intkset_add(structkset *kset); • intkset_register(structkset *kset); • void kset_unregister(structkset *kset); • structkset *kset_get(structkset *kset); • void kset_put(structkset *kset); • ktype, is used in preference to the ktype in a kobject

  28. Subsystems • Representation for a high-level portion of the kernel • Usually show up at the top of the sysfs • Block devices, block_subsys, /sys/block • Core device hierarchy, devices_subsys, /sys/devices • Every bus type known to the kernel… • Driver authors almost never needs to create one • Probably want is to add a new “class” • Subsystem is really just a wrapper around a kset struct subsystem { struct kset kset; struct rw_semaphore rwsem; // used to serialize access };

  29. *(show) (*release)( ) *(store) *sysfs_ops **default_attrs “version” * S_IRUGO Low-level sysfs operations • Every kobject exports attributes, in that its sysfs dir • #include <linux/sysfs.h> • Call kobject_add( ) to show up in sysfs • Default attributes struct attribute { char *name; struct module *owner; mode_t mode; }; structsysfs_ops { ssize_t (*show)(*kobj, struct attribute *attr, char *buffer); ssize_t (*store)(*kobj, struct attribute *attr, const char *buffer, size_t size); }; kfree(); kobj_type sysfs_ops snprintf(); attribute

  30. Low-level sysfs operations • Non default attributes • Attributes can be added and removed at will • intsysfs_create_file(structkobject *kobj, struct attribute *attr); • intsysfs_remove_file(structkobject *kobj, struct attribute *attr); • The same show() and store() are called • Binary attributes • e.g., when a device is hot-plugged, a user-space program can be started via hot-plug mechanism and then passes the firmware code structbin_attribute { struct attribute attr; size_t size; ssize_t (*read)(structkobject *kobj, char *buffer, loff_t pos, size_t size); ssize_t (*write)(structkobject *kobj, char *buffer, loff_t pos, size_t size); }; • intsysfs_create_bin_file(*kobj, structbin_attribute *attr); • intsysfs_remove_bin_file(*kobj, structbin_attribute *attr); • Symbolic links • intsysfs_create_link(*kobj, structkobject *target, char *name); • void sysfs_remove_link(*kobj, char *name);

  31. Hotplug event generation • Hotplug event • a notification to user space from the kernel that something has changed in the system’s configuration • is generated whenever a kobject is created (kobject_add) or destroyed (kobject_del) • e.g., a camera is plugged in USB cable, disk is repartitioned… • To invoke /sbin/hotplug • /proc/sys/kernel/hotplug specifies hotplug program path • Operations in “hotplug_ops” of kset • Search up via parent until finding a kset • (*filter): to suppress hotplug event generation • (*name): to pass the name of relevant subsystem for a parameter • (*hotplug): to add useful environment variables for hotplugscript

  32. device Buses, devices, and drivers • Buses • Channel between the processor and one or more devices • Devices and device drivers • Once again, much of the material covered here will never be needed by many driver authors. bus struct device Driver core kobject core struct ldd_device driver struct device driver struct ldd_driver struct kobject Functional view inside kernel

  33. Hotplug operations’ sample code • Filter example • User space may want to react to the addition of a disk or a partition, but it does not normally care about request queues. static int block_hotplug_filter(struct kset *kset, struct kobject *kobj) { struct kobj_type *ktype = get_ktype(kobj); return ((ktype = = &ktype_block) || (ktype = = &ktype_part)); } • The generation of hotplug events is usually handled by logic at the bus driver level

  34. Buses struct bus_type { char *name; struct subsystem subsys; struct kset drivers; struct kset devices; int (*match)(struct device *dev, struct device_driver *drv); struct device *(*add)(struct device * parent, char * bus_id); int (*hotplug) (struct device *dev, char **envp, int num_envp, char *buffer, int buffer_size); /* Some fields omitted */ };

  35. Buses Contd.. • Bus registration • structbus_typeldd_bus_type = { .name = "ldd", .match = ldd_match, .hotplug = ldd_hotplug, }; • int __init ldd_bus_init(void) { ret = bus_register(&ldd_bus_type); //ret value must be checked … // bus subsystem, /sys/bus/ldd ret = device_register(&ldd_bus); • Deregistration • void ldd_bus_exit(void){ device_unregister(&ldd_bus); bus_unregister(&ldd_bus_type);

  36. Buses Contd.. • Bus methods • int (*match)(struct device *device, structdevice_driver *driver); • Called whenever a new device or driver is added for this bus • Return a nonzero value if the device can be handled by driver static intldd_match(struct device *dev, structdevice_driver *driver) { return !strncmp(dev->bus_id, driver->name, strlen(driver->name)); } • int (*hotplug) (struct device *device, char **envp, intnum_envp, char *buffer, intbuffer_size); • Allow the bus to add environment variables • LDDBUS_VERSION • Iterating over devices and drivers • bus_for_each_dev( ), bus_for_each_drv( ) • Bus attributes • structbus_attribute, (*show), (*store) • BUS_ATTR(name, mode, show, store);  declare “structbus_attr_name” • bus_create_file( ), bus_remove_file( )  lddbusBUS_ATTR(version)

  37. Devices struct device { struct device *parent; structkobjectkobj; char bus_id[BUS_ID_SIZE]; structbus_type *bus; structdevice_driver *driver; void *driver_data; void (*release)(struct device *dev); /* Several fields omitted */ }; Must be set before registering device->kobj->parent == &device->parent->kobj kobject_unregister( ) kobject_hotplug() kobject_del() kobject_put() kobject_release( ) kset’s release evice_release( ) dev->release( )

  38. Devices Contd.. • Device registration • intdevice_register(structdevice *dev); • voiddevice_unregister(structdevice *dev); • An actual bus is a device and must beregistered static void ldd_bus_release(struct device *dev) { printk(KERN_DEBUG "lddbus release\n"); } struct device ldd_bus = { .bus_id = "ldd0", .release = ldd_bus_release }; // device_register( ) & unregister( ) ldd_bus_init( ) & exit( ) // evices subsystem, /sys/devices/ldd0/ • Device attributes • structdevice_attribute, DEVICE_ATTR( ), device_create_file, …

  39. Device structure embeddingfor a specific bus (e.g., pci_dev, ldd_device) • “struct device” contains the device core’s information • Most subsystems track other about the devices they host • As a result, “struct device” is usually embedded • lddbus creates its own device type for ldd devices structldd_device { char *name; structldd_driver *driver; struct device dev; }; #define to_ldd_device(dev) container_of(dev, structldd_device, dev);

  40. Device drivers struct device_driver { char *name; struct bus_type *bus; struct kobject kobj; struct list_head devices; int (*probe)(struct device *dev); int (*remove)(struct device *dev); void (*shutdown) (struct device *dev); };

  41. Classes • net/core/net-sysfs.c, line 460 class_register(&net_class); • net/bluetooth/hci_sysfs.c, line 147 class_register(&bt_class); • drivers/pcmcia/cs.c, line 1892 class_register(&pcmcia_socket_class); • drivers/usb/core/file.c: line 90 class_register(&usb_class); • drivers/usb/core/hcd.c, line 649 class_register(&usb_host_class); • drivers/pci/probe.c, line 110 class_register(&pcibus_class);

  42. Putting all Together

  43. ThanksRef: Chap 13 & 14, LDD 3e Rubini- Corbet
