  1. Introduce OSGi BlueDavy http://www.osgi.org.cn http://blog.bluedavy.cn 1.0 2007-10-28

  2. Agenda • Play OSGi • Who use OSGi • What is OSGi • OSGi R4 Implemention • How to develop OSGi app • OSGi Resources 2

  3. Play OSGi • Let’s see a short demo • First we see an bulletin application,but only have bulletin list function; • We want to add new bulletin,so we find newbulletin module from module respository,then install & start it,now we can add new bulletin; • We see the feature of OSGi application • modularity • dynamic,”Plug and Play” • extensionable • these features are supported by OSGi,the meaning is that you don’t need realize those features yourself,what you need do is just use it 3

  4. Agenda • Play OSGi • Who use OSGi • What is OSGi • OSGi R4 Implemention • How to develop OSGi app • OSGi Resources 4

  5. Who use OSGi • IBM • Websphere • RSA • BEA • microServices,All BEA product will be based on microServices • Eclipse • Apache • Struts 2 • Spring • Spring-OSGi • Simens,Nokia,BMW,Cisco etc. • SAP,Oracle,IONA etc. are interested in OSGi,and be OSGi EEG member 5

  6. Agenda • Play OSGi • Who use OSGi • What is OSGi • OSGi R4 Implemention • How to develop OSGi app • OSGi Resources 6

  7. What is OSGi • Dynamic Module System For Java • JSR232 JSR291 • Universal Middleware • Best practice guide and support for building modularity/dynamic/extensionable system • Modularity with rule; • Dynamic support for module,OSGi service,configuration; • Extension support with OSGi service. 7

  8. Modularity Define module in OSGi; Publish functions for other modules; Use functions provided by other modules. Service registry packages packages OSGi Basic Concepts OSGi Framework Bundle Bundle JAVA Operating System Hardware 8

  9. Define module in OSGi • In OSGi module compose of one or more bundles; • Bundle is a normal jar file,the difference is its Manifest.mf file,OSGi add some specical header info property to declarative bundle,such as: • bundle-version,export-package,import-package 9

  10. Publish functions for other bundles • add export-package header info to provide package for other bundles to use,such as cn.org.osgi.ppt.service; • add Fragment-Host header info to provide all resources for host bundle to use; • publish OSGi service for other bundles; • Use BundleContext.registerService to register normal java interface as OSGi service; • Write xml with rule to declarative normal java class as OSGi component,and provide service interface for other bundles,such as: 10

  11. Use functions provided by other modules • add import-package header info to import packages provided by other bundles,then you can use the java class in those packages; • add require-bundle header info to use all export packages and resources provider by bundle; • use OSGi service provided by other bundles; • Use BundleContext.getService to get OSGi service provided by other bundles; • Write xml with rule to declarative normal java class as OSGi component,and inject OSGi service provided by other bundles,such as: 11

  12. OSGi Basic Concepts • Dynamic • Bundle lifecycle • OSGi component lifecycle • Handle the dynamic • when bundle lifecycle changed; • when OSGi component lifecycle changed; • when configuration changed; • when framework changed; • when custom event published; 12

  13. Bundle lifecycle • OSGi provide an API for manageing bundles lifecycle (Install/Resolve/Start/Stop/Refresh/Update/Uninstall),so OSGi framework RI will control bundle lifecycle self; INSTALLED STARTING start RESOLVED ACTIVE stop UNINSTALLED STOPPING 13

  14. OSGi component lifecycle • Component that provide no service; • when all need OSGi services(exclued optional service) are usable,the component will be actived; • Component that provide services; • when all need OSGi services(exclued optional service) are usable; • other component call this OSGi service implemention. 14

  15. Handle the dynamic • when bundle lifecycle changed; • OSGi component lifecycle will change automatically; • OSGi will handle bundle lifecycle dynamic self; • when OSGi component lifecycle changed; • OSGi service tracker can be used to monitor OSGi service; • Declarative Services use bind-method,unbind-method to notify the dynamic of OSGi service. • when configuration changed; • Configuration Admin Service automatically notify the configuration change. • when framework changed; • FrameworkEventListener can be implemented to monitor framework. • when custom event published; • EventAdmin Service can to used to publish & handle custom event. 15

  16. OSGi Basic Concepts • Extensionable • Service filter supported by OSGi can be used to extension function; • Multi service reference supported by OSGi can be used to extension function; • Extension point provided by Equinox can be used to extension function. 16

  17. Agenda • Play OSGi • Who use OSGi • What is OSGi • OSGi R4 Implemention • How to develop OSGi app • OSGi Resources 17

  18. OSGi R4 Implemention • Equinox • Realized by Eclipse team; • As the OSGi R4 RI; • http://www.eclipse.org/equinox. • Used by Eclipse RCP & Eclipse other products. • Felix • Realized by Apache Team; • http://felix.apache.org. 18

  19. Agenda • Play OSGi • Who use OSGi • What is OSGi • OSGi R4 Implemention • How to develop OSGi app • OSGi Resources 19

  20. How to develop OSGi app • Get started • Write your first bundle • Deploy & Manage first bundle • Publish and use OSGi Service • FAQ 20

  21. Get started • Download Eclipse from www.eclipse.org • Download Equinox bundles from www.eclipse.org/equinox • most bundles exist in eclipse 21

  22. Write your first bundle • New plugin-project,select this plug-in is targeted to run with an OSGi framework in project wizard page; 22

  23. Write your first bundle • Then enter the plug-in content page • Write associate info,then click finish to create the project. 23

  24. Write your first bundle • Write activator class • Say ‘hello’ when bundle started; • Say ‘byebye’ when bundle stopped; 24

  25. Deploy & Manage first bundle • Deploy in eclipse • Deploy outside alone • Manage bundle in console 25

  26. Deploy in eclipse • Open run dialog,new in Equinox OSGi Framework, select Workspace Plug-ins and org.eclipse.osgi in Target platform; 26

  27. Deploy in eclipse • Click Run button,then you can see this in console; 27

  28. Deploy outside alone • Create equinox framework app outside alone first; • create Equinox directory,then create configuration,plugins directory in Equinox directory; • put org.eclipse.osgi.jar & org.eclipse.osgi.services.jar to plugins directory; • create config.ini in configuration directory,content in config.ini like this: osgi.noShutdown=true osgi.bundles=org.eclipse.osgi.services_3.1.100.v20060601.jar@start osgi.bundles.defaultStartLevel=4 osgi.configuration.cascaded=false eclipse.ignoreApp=true • create run.bat in Equinox directory,content in run.bat(windows) like this: @echo off java -jar plugins/org.eclipse.osgi_3.2.1.R32x_v20060919.jar - configuration configuration -console 28

  29. Deploy outside alone • Start equinox framework and install first bundle in OSGi console; • install first bundle use directory mode; • Input command like this in OSGi console: install file:/D:\work\workspace\OSGi-Bulletin\FirstBundle • install first bundle use jar file; • package first bundle into jar file; • Export the project as deployable plug-ins and fragments • Input command like this in OSGi conosle: install file:/D:\Opendoc\Equinox\plugins\FirstBundle_1.0.0.jar 29

  30. Manage bundle in console • use ss to find bundle id • use start,stop,update,uninstall to manage bundle with bundle id • start 2 (start bundle) • stop 2 (stop bundle) • update 2 (update bundle on the fly) • uninstall 2 (uninstall bundle) 30

  31. Publish OSGi Service • Use OSGi declarative services to publish and use OSGi Service,then when you run OSGi application,you need install Equinox DS plugin; • Create ServiceBundle to publish OSGi service; • Create cn.org.osgi.ppt.service.HelloService Interface; • Create cn.org.osgi.ppt.component.HelloComponent to implemention HelloService; • Publish HelloService as OSGi service using DS component xml; <component name="HelloComponent"> <implementation class="cn.org.osgi.ppt.component.HelloComponent"/> <service> <provide interface="cn.org.osgi.ppt.service.HelloService"/> </service> </component> • Add component.xml to MANIFEST.MF Service-Component property • Export package cn.org.osgi.ppt.service 31

  32. Use OSGi Service • Add cn.org.osgi.ppt.service to import-package; • Use HelloService in firstbundle with two kind methods; • context.getService method • In Activator class: ServiceReference serviceRef=context.getServiceReference(HelloService.class.getName()); if(serviceRef!=null){ HelloService service=(HelloService) context.getService(serviceRef); service.say("Activator"); } • Declarative Services method • create cn.org.osgi.ppt.firstbundle.FirstComponent class with inject service method: publicvoid setService(HelloService service){ this.service=service; } publicvoid unsetService(HelloService service){ if(this.service!=service) return; this.service=null; System.out.println("HelloService不可用"); } • write ds component xml to inject OSGi service; • Add component.xml to MANIFEST.MF Service-Component property 32

  33. Agenda • Play OSGi • Who use OSGi • What is OSGi • OSGi R4 Implemention • How to develop OSGi app • OSGi Resources 33

  34. OSGi Resources • OSGi R4 Specifications • 《OSGi实战》Opendoc • 《OSGi进阶》Opendoc • http://www.osgi.org • http://www.osgi.org.cn • http://www.aqute.biz • http://blog.bluedavy.cn 34

  35. OSGi China User Group Thank You ! Click to edit company slogan .
