The shape of flexspline is mainly divided in three types i.e. Cup shape, hollow type and straight tube type. Based on these classification SMD gearbox introduced new series of Harmonic Gearbox. They come up with different mountings like some have large flange, some have low dimensions some have long two-way output pipe. Its combined features allow your application to achieve its customized results. To know more about these harmonic variant please visit reference link- https://www.scribd.com/document/565834648/Harmonic-Reducer-SMD-Gearbox

1 / 2

Télécharger la présentation

HARMONIC REDUCER | SMD Gearbox

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

Playing audio...

  1. HARMONIC GEAR REDUCER SCSG SERIES Nominal Output torque : 21Nm to 180Nm Backlash : less than 0.4 Arc min Available reduction ratio :1:50,1:80 1:100, 1:120 High rigidity for stable precision work. More compact and higher accurate. SSHG SERIES Diverse appearance; suitable for robot arm. Precision: less than 0.4 Arc-min. Torque Capacity: 20Nm to 180Nm Available reduction ratios 1:50 ,1:80, 1:100, 1:120 SSHG-2A When large flange required than standard to distribute the loads. Torque Range – 7 Nm to 523 Ratio Range – 50 to 160 Size – 14 to 45 HIGH PRECISION SERVO GEARBOX SMD provides a wide variety of Servo Gearbox “Reducers" solutions for different sectors of industry. Learn more about the products please visit our website www.smdgearbox.com or you can mail us on sales@smdgearbox.com. You can call us on - +886(09)67388376 / +91-7030669818

  2. HARMONIC GEAR REDUCER SSHG-2SO SERIES Short axial dimension than any other series. We can also say that It can change output shaft into flange. Torque Range – 5.4 Nm to 402 Ratio Range – 50 to 160 Size – 14 to 45 SSHG – 2UJ SERIES Input has shaft end mounting, output is same as our SSHG series. Torque Range – 5.4 Nm to 402 Ratio Range – 50 to 160 Size – 14 to 45 SSHG-2SH SERIES Input and output mounting are hollow hence for bigger bore size this unit can use. Torque Range – 5.4 Nm to 402 Ratio Range – 50 to 160 Size – 14 to 45 HIGH PRECISION SERVO GEARBOX SMD provides a wide variety of Servo Gearbox “Reducers" solutions for different sectors of industry. Learn more about the products please visit our website www.smdgearbox.com or you can mail us on sales@smdgearbox.com. You can call us on - +886(09)67388376 / +91-7030669818
