  1. Masonry

  2. Masonry • Stone • Bricks • Terra cotta • Mortars • Plasters

  3. Stone • 1. Types of building stones a. Igneous b. Sedimentary c. Metamorphic • 2. Cutting and shaping techniques • 3. Stone finishes • 4. Types of walls

  4. 1. Types of building stones • a. Igneous • b. Sedimentary • c. Metamorphic

  5. Rock cycle Igneous Erosion & Precipitation Heat Sedimentary Heat & Pressure Metamorphic

  6. Igneous rocks Asher and Adams Pictorial Album of American Industry, 1876 Cobble Hill granite quarry, Barre, VT

  7. Granites

  8. Barre white granite

  9. Sedimentary Limestones

  10. Limestones Indiana limestone Trenton limestone

  11. Trenton limestone St. Marc des Carriers, Quebec

  12. Sandstone Longmeadow sandstone Billings Library, Burlington, VT

  13. Metamorphic Sandstone to Quartzite Limestone to Marble Shale to Slate

  14. Quartzite Redstone quarry, Burlington, VT

  15. Monkton Quartzite redstone

  16. Marble

  17. Slate

  18. Hand sawing marble, Diderot, 1762

  19. Steam channeling machine, 1891

  20. Wire saw cutting granite

  21. Stone plane

  22. Stone Finishes

  23. Cobble Ashlar

  24. Rubble
