  1. Rockets Made in Iran Range & Capability

  2. Hasseb mm107 warhead: 8Kg. range: 9Km

  3. Arash 122mm warhead: 18Kg range: 20Km

  4. Arash • 122mm • warhead: 18Kg • range: 20Km

  5. Raaed 1 240 mm warhead: ?? Kg. range: 10 Km

  6. Shahin 1 333 mm warhead 190 Kg range 13 Km

  7. Shahin 2 • 333 mm • warhead 190 Kg • range 20 Km

  8. Oghab 230 mm warhead: 70Kg range: 45 Km

  9. Fajer 3 240 mm warhead: 70 Kg Max. range 45Km.

  10. Fajer 5 333 mm warhead: ??Kg Max.range: 70Km

  11. Fateh-110 ( Mushak 160, NP 110) Range: 170 Km. Warhead: 500Kg

  12. Fateh-110 ( Mushak 160, NP 110)

  13. Fateh-110 ( Mushak 160, NP 110)

  14. Rockets made in Iran

  15. Zilzal 2

  16. Zilzal 2

  17. Zilzal 2

  18. WAR IN HAIFA
