Static Code Checking: Security and Concurrency

1. Static Code Checking: Security and Concurrency Ben Watson The George Washington University CS 297 Security and Programming Languages June 9, 2005

2. The Video

3. The Problem • How to discover errors in code without running it • Code can run for weeks or months without displaying the error • Many errors are caused by pieces of code that are very difficult to test • Device drivers – manufacturers aren’t always good at this, and one OS company can’t possibly test all the tens of thousands of devices out there • The Windows 98 crash was caused by a bad scanner driver • Concurrent code—debugging complicated concurrency problems is a nightmare x n.

4. The Scope • Lines of Code (estimated)

5. The Real Problem • We’re only human • No person, no group of people can possibly manually debug anything as complicated as an OS and its related pieces • Good tools are not enough • Can’t rely on thorough annotations of entire code base • Can’t rely on manual directions: the more automated the better

6. The Solutions • MC Security checking system • RacerX: Race condition and Deadlock detection • General rule inference from source code

7. MECA: Statically Checking Security Properties • Checks low-level properties (pointer safety, etc.) • Relies on annotations that propagate through the analysis • Goals • Expressiveness • Low manual overhead—programmers only have to type in a relatively few number of annotations • Low false-positives

8. How MC Works • Uses a modified GCC compiler • Parses source along with abstract syntax tree generated by compiler • AST used to build a control-flow graph • Annotation propagator uses CFG to propagate annotations through entire graph • Checkers are run on the completed graph • Results are ranked and filtered

9. An example • Rule: OS kernel may not access a user-pointer (there are “paranoid” functions to access the data pointed to by a user-pointer) • Referred to as a “tainted” pointers • Annotate: • Tainted variables, parameters, and fields • Functions that produce tainted values

10. Source annotations struct myStruct { /*@ tainted */ int*p; }; /*@ tainted */ int *foo(/*@ tainted */int *p); void memcpy(/*@ !tainted */void *dst, /*@ !tainted */void *src, unsigned nbytes);

11. Source annotations //Binding: /*@ set_length($ret, sz) */ void* malloc(unsigned sz); //Global: all sys_* calls //are tainted /*@ global $param ${!strncmp(current_fn,”sys_”,4)} ==> tainted */

12. Propagation void bar(/*@ tainted */void *p); struct S{char* buf;} //Before analysis void foo(char** p, struct S* s) { char *r; struct S* ss; r=*p; bar(r); //taints r and *p ss =s; bar(ss->buf); //taints ss and s } //At the end of analysis: Foo(/*@ tainted (*p) */char **p, /*@tainted(s->buf) */struct S* s);s

13. MECA results • On average, one manual annotation led to 682 checks • Linux 2.5.63 Bugs:

14. RacerX • Static detection of race conditions and deadlocks • Designed to find errors in large, multi-threaded systems • Sorts errors by severity (the hard part) • They checked Linux, FreeBSD, and a mystery OS that has only 500,000 lines of code

15. Deadlock • Deadlock • Thread 1 has locked resource A • Thread 2 has locked resource B • Thread 1 needs resource B to complete • Thread 2 needs resource A to complete • Neither can proceed—these threads are deadlocked

16. Race condition • Multiple threads access the same memory • If memory is unprotected: • Two threads can simultaneously write to same memory (bad) • One thread can read, another can write simultaneously (bad) • Two threads can simultaneously read from same memory (probably ok) • It’s a race because final value is non-deterministically chosen by who gets there first.

17. Avoiding the Problem • If data is never accessed by more than one thread, you don’t have to worry about concurrency • If program logicensures that only one thread accesses data, you don’t need to worry about locking the data • If you’re writing a shared component, you almost always have to worry about concurrency

18. Algorithm • “Lockset” algorithm detects both types of problems • Lockset - A pair of • Lock()/Unlock() • InterruptDisable()/InterruptEnable() • Etc.

19. Algorithm • Top-down analysis of control-flow graph • Add/remove locks as needed • Check for race/deadlock on each statement • Cache results to ease exponential graph size

20. Deadlock Check • Basically, finds if there are cycles in the lockset dependencies • If lock a is obtained, then lock b, we have: • a  b • Following this line of reasoning, we can discover cases that look like this: • a  b  c  a

21. Deadlock Check • Deciding how important the cycle is, is non-trivial. • Basically, rank higher according to: • Global locks vs. local locks • Small depth difference vs. big depth difference • Fewer threads vs. more threads

22. Race Checking • This is even harder than deadlock detection • Must answer: • Is lockset valid (if not, you will have LOTS of false positives) • Can the unprotected memory be accessed more than one thread? • Does the access need to be protected? • Two reads do not a wrong make • Must annotate API functions that require locks

23. Race Checking • Deciding if code is multithreaded: • Inferred from “programmer belief” – if a piece of code contains concurrency-related statements, the code is probably multi-threaded • Annotations—designate API functions as requiring locks

24. Race Checking • Does memory need to be protected? • If it’s never written to, no. • If it’s only written on initialization, no. • On a certain code path, if there are a high-number of variables that are potentially written to concurrently, probably. • Anything that can’t be written atomically, yes. (although, this is pretty much anything, especially if you have more than 1 CPU) • If a variable is statistically likely to be protected by locking code (“Programmer Belief”)

25. RacerX: Results

26. Pop Quiz – Question 1 • If you have read the 3rd paper, you may not answer this question. • Find the bug: if (card==NULL) { printk(KERN_ERR “capidrv-%d: … %d!\n”, card->contrnr, id); }

27. Pop Quiz – Answer 1 if (card==NULL) { printk(KERN_ERR “capidrv-%d: … %d!\n”, card->contrnr, id); }

28. Pop Quiz – Question 2 • If you have read the 3rd paper, you may not answer this question. • Find the bug: struct mxser_struct *info = tty->driver_data; unsigned long flags; if (!tty || !info->xmit_buf) return 0;

29. Pop Quiz – Answer 2 struct mxser_struct *info = tty->driver_data; unsigned long flags; if (!tty || !info->xmit_buf) return 0;

30. General Methodology • Take advantage of programmer beliefs • Statistics are our friend • If something is usually done a certain way, then instances that violate that should be examined • Check internal consistency • Discover rules that are built-in to the code • Minimal to no annotation

31. Conclusion • The methods tonight provide some of the best ways to find errors: • Millions of lines of code can be checked with at most hundreds of lines of annotations • The bugs these methods find are fairly specific in nature (revolve around well-structured code constructs)

32. References • Junfeng Yang, Ted Kremenek, Yichen Xie, and Dawson Engler. MECA: an Extensible, Expressive System and Language for Statically Checking Security Properties. ACM CCS, 2003. • Dawson Engler and Ken Ashcraft. RacerX: Effective, Static Detection of Race Conditions and Deadlocks. SOSP 2003. • Dawson Engler, David Yu Chen, Seth Hallem, Andy Chou, and Benjamin Chelf. Bugs as Deviant Behavior: A General Approach to Inferring Errors in Systems Code. OSDI 2000. • Source Lines of Code, http://www.answers.com/topic/source-lines-of-code • Concurrency – Part 2: Avoiding the Problem, http://blogs.msdn.com/larryosterman/archive/2005/02/15/373460.aspx
