  1. SIMATIC WinAC WinAC Slot 41x, Version 3.2 Shipment: 11/2001

  2. Support DP-V1 norm • New! acyclic services (DP-Norm) • Today: DP-V0, S7-Slaves Support of DP-V1 Norm-Slaves e.g. support acyclic services for norm-slaves Routing to slaves on DP/MPI • From external: via Ethernet (3Com, onboard Eth.), CP1613, PC-onboard DP/MPI • From local: STEP 7 Central Diagnostics/Service Improved Integration Easier Handling Aktivate/Deactivate of Slaves • on DP (SFC12) Improved flexibility Mobile participants (Measurement systems) Driverless transportation systems • Objective: • Completion TIA-Functionality • Integration of technological PC-applications WinAC Slot 41x, Version 3.2Overview New functions Customer advantage Improved PC-Integration • Advanced PC Configuration • WinAC Slot within PC-Station Unique configuration of all PC-Comp. More flexibility in communication

  3. Fast I/O-Coupling (Master-Slave) Interoperation with „Not-SIMATIC“-Master Cascade of I/O CPU as Slave on DP • For both onboard DP-interfaces Consistent data on DP • Today 1 DW, New! 4 DW Easy to use, less engineering Faster Plant/component identification • TextString (DIN) User specific component identification according user nomenclatur Usage Win2K Features Advantages for PC-Applications (e.g. USB..) OPC Server of WinAC ist OPC „compliant“ Win 2000 Professional Compliance OPC Server • OPC certified product Technology-Interface WinAC Slot T-Kit Fast Data exchange between PLC and PC-Applications WinAC Slot 41x, Version 3.2Overview New functions Customer advantage

  4. WinAC Slot 41x, V3.2Network-Routing • Routing via Subnet-borders to S7-stations • From external • via Ethernet and Profibus • Examples: • Loading User programs • Loading HW configuration • Test- & Service functionalities PG/OP WinAC Slot 41x S7-Stationen S7-Slave

  5. Advanced PC ConfigurationPC as Runtime Station PC as Runtime Station WinCC ProTool/Pro OPC Server Slot-PLC PC Applikation Virtuell PC-Bussystem Industrial Ethernet PROFIBUS • Advantages • Easy, consistent & cost saving setup of the PC station • STEP 7 - conform configuring for SIMATIC NET products • Unique view on the whole Automation Project - SIMATIC S7 and PC

  6. SIMATIC PC-StationUnified component configuration • Unified component configuration on the PC • WinAC Slot as „Instance“ within Runtime Station • next to • ProTool/Pro, WinCC • Communication • CP5613, CP5611, ...

  7. WinAC Slot 41x, V3.2Components NEW ! WinAC Slot 41x, V3.2 WinAC Slot 41x, V3.1 6ES7673-2CC00-0YX0 6ES7673-6CC20-0YX0 No Change ! 6ES7673-2CC00-0YX0 6ES7673-6CC20-0YX0 MLFB MLFB Hardware CPU 412-2 PCI; 6ES7612-2QH00-0AB4 CPU 416-2 PCI; 6ES7616-2QL00-0AB4 Hardware CPU 412-2 PCI; 6ES7612-2QH00-0AB4 CPU 416-2 PCI; 6ES7616-2QL00-0AB4 No Change ! Spare part CPU‘s Firmware CPU 412-2 PCI; FW 3.0 CPU 416-2 PCI; FW 3.0 Firmware CPU 412-2 PCI; FW 1.1 CPU 416-2 PCI; FW 1.1 Change ! Software (CD) WinAC Slot 41x, V3.1 Software (CD) WinAC Slot 41x, V3.2 (CD) SIMATIC Net  05/00 SIMATIC Net 07/01 STEP 7, V5.1 STEP 7, V5.1, SP 2
