  1. ENERGY EFFICIENCYIN MANUFACTURING MALTA

  2. Energy Efficient Electric Motor Systems for the Manufacturing Industry Key Experts: Prof. Ing. C. Spiteri- StainesCo-Supervisors: Dr. Cedric Caruana Researcher: Mr. Peter Spiteri Industrial Partners : PlaymobilToly Products Andrews Feeds

  3. Introduction It is estimated that motor driven systems account for around 65% of the electricity consumed by the European industry. 1.5% improvement in the motors’ efficiency implies a reduction of 1% energy consumption in the European industry. The more efficient use of energy in the manufacturing industry has become a key factor for the industrial organisations to maintain a competitive edge.

  4. Aims of Project The objective is to facilitate the adoption of energy saving measures on electric motors by the Maltese industry. Carry out an extensive Data gathering exercise on Energy Usage and Patterns of Electrical Motor Systems in various local industries The project will deliver a tool which will allow organisations to evaluate alternative options of reducing their electric motors’ energy consumption. Benefits derived from project: Knowledge on energy savings mechanisms for manufacturing industry Additional benefits: reduced heat dissipation and lower maintenance costs.

  5. Increasing Efficiency in Motor Systems

  6. IE Motor Efficiency Standards The new standard introduces also IE4 (super premium efficiency), a future level above IE3, but IE4 products are not yet commercially available. 50Hz Motors 6

  7. Comparing Old & New Efficiency Standards Old Standards EFF1, EFF2 and EFF 3 New Standards: IE1 – Standard Efficiency (comparable to EFF2) IE2 – High Efficiency (comparable to EFF1) IE3 – Premium Efficiency

  8. How to minimise losses in Motor Driven Systems Replace Old Motor by HEM Use a Motor Energy Controller (only certain applications as we will see) Use a Variable Speed Drive (inverter) Study carried out by South Carolina Energy Office

  9. Check Load Profile of Machine Low Load means Low Efficiency and Low Power Factor Try to use a motor close to its rated power, do not overrate without scope!!!

  10. Load Profile of IMMs (w/o accumulator) 10

  11. Motor Systems Selected for Study • The study consisted of: • Injection Mould Machinesand • other motor driven systems such as elevators, conveyers, mixers and cubers, • at partner premises.

  12. Load profile of IMM with Accumulator Max load = 62.7kW (209%) Motor rating = 30kW Average load = 12.2kW (40.7%) ≈ 7.5kW (25%) Typical load profile of K 60/S 3C (with accumulator) Base load

  13. Load profile of IMM w/o Accumulator Max load = 43.9kW (199.5%) Motor rating = 22kW Average load = 8.1kW (36.8%) ≈ 3.2kW (14.5%) Typical load profile of BA 1500(no accumulator) Base load

  14. Analysis of Injection Mould Machines (Summary) Table showing the motor ratings, typical base loads, average loads, consumption, power factor and peak maximum of all the types. The values in the brackets are the percentages of the motor ratings (1) The IMM motor was power factor corrected ) 14

  15. Analysis–K 60/S 3C Mainly due to base load Motor rating = 30kW 26.3% Electric’s motor percentage time vs the power level

  16. Analysis– K 60/S 3C Mainly due to base load 46.1% Motor rating = 30kW 16 Energy consumption vs the power level

  17. Analysis – BA 1500 Mainly due to base load Mainly due to holding pressure Motor rating = 22kW 14.7% 63.7% Electric’s motor percentage time vs the power level

  18. Analysis – BA 1500 Mainly due to holding pressure Mainly due to base load 41% Motor rating = 22kW 22% Energy consumption vs the power level

  19. Analysis – Main Mixer at high load at low load Motor rating= 30kW Motor rating = 30kW Motor on load = 18.5kW (61.7%) 60.2% 13.4% Average load = 14.2kW (47.3%) 68.1% at low load Motor rating = 30kW at high load Motor at low load = 4.2kW (14%) 8.0%

  20. Analysis – Conveyer high load 15.8kWh low load 67.5% low load 14.1kWh high load 32.5% Motor rating= 4kW Average load = 1.6kW (40%) Motor at no load≈ 1.2kW(30%)

  21. Simulated and Experimental determination of Energy Savings Measurements have shown that in many cases, motors are operated for long duration at low load, thus inefficiently. Solutions: Replace motor with HEM Lower voltage during low load Use MEC (effectively lowers voltage) Use VVVF drive (not always possible) Tests shall be simulated & tested on an experimental set-up

  22. Simulation of Low Load with decrease in Voltage Analysis of Motor with constant Low Load: Simulation results with supply voltage reduced from 100% to 45% with a load factor of 25%. The motor rating is 37kW The efficiency is increased by 16.8%. The input power is decreased from 14.2kW to 11.1kW yielding energy savings of 21.8%. If the supply voltage is reduced ONLY during the base load operation, for IMM, the overall potential energy savings become 9.4%.

  23. Analysis of Lower Voltage Concept to Motor Readings

  24. Transient Response of MEC (Lab Rig) One of the main challenges is due to the relatively short times at which the motor operates at the base loads. occurences of operation at base load are a lot however the timings are very critical. MEC needs toreactrapidly to regulate the supply voltage on the motor according to operation. MEC switched ON

  25. Further Work Emulation of Actual Load Profiles on Laboratory Test Rig. Verification of Energy Saving Mechanisms (HEM and MEC) on industrial premises Development of Motor Energy Saving Tool (MEST). Software tool to guide organisations’ personnel (possibly non-technical) to improve efficiency in motor driven systems

  26. Increasing Energy Efficiency during Reliability Testing of Equipment through Grid‐connected Load Units Industrial Partners : Abertax Delta (Malta) Key Experts: Dr. Maurice Apap Co-Supervisors: Prof. C. Spiteri Staines & Prof. J. Cilia Researchers: Mr. Francarl Galea

  27. Introduction Manufacturing Cycle Testing of each product must take place before reaching the market and the customer. Testing of certain products leads to high energy consumption. power supply full load burn-in test usually last for a minimum of 24 hours. (can exceed 400,000kWhr yearly.) batteries testing is carried out by cycling.

  28. Aims This project is targeted at increasing the efficiency during testing of manufactured electrical equipment: namely, DC Power Supplies and Battery Banks. • Currently Electrical Energy consumed during testing is ‘wasted’ (as heat) in Active Loads. • The aim of this project is to REDIRECT the Electrical Energy used during testing back to the Electrical Supply. • 70% energy saving is predicted.

  29. System Description The Regenerative Active Load shall be made up of: DC-DC Converter Design. Grid Connected Inverter. The Regenerative Active Load was designed to operate over a wide input range of Voltages and Currents to support different types of DC Supply Equipment. DC/DC Converter Specs

  30. DC/DC Converter Topology • Out of many topologies studied, the isolated Ćuk topology was selected on the following criteria: • Low input and output current ripples • can ‘step up’ & ‘step down’ the input voltage • Bipolar current flowing into the transformer (full utilisation) • Saturation of the transformer is not possible • Total isolation of input from output • Transformer’s turns’ ratio can be used to set duty cycle range.

  31. Simulation of Converter Vin =30V Vin =300V

  32. Converter Components Design Gate Drivers Magnetic Components Power Semiconductors Protection Circuit Snubbers Analogue Control Circuit

  33. System Testing The built DC-DC converter was tested and the following issues were checked: Components were monitored for overheating Monitoring of voltage overshoots during switching transients (to verify operation within the maximum device ratings). Verification that current and voltage ripples were within design limits Operation over expected RANGE of output voltage and output current for the designed input voltage range Efficiency was measured for various operating conditions

  34. Regeneration of Electrical Energy For REDIRECTION of testing energy to the Mains supply: The DC-DC converter was interfaced to a standard off-the-shelf Grid-connected Inverter The DUT was tested for various operating points (input voltage and power) and the energy used was transferred via the DC-DC, into the grid-connected inverter, and back to the mains supply.

  35. Results - Measurement of Efficiency 35

  36. Results – Burn-In Test (800W, 200V Power Supply) Experimental tests show that 78% less energy was used to burn-in test SM400AR-4 (4.9kWh instead of 20kWh in 24 hours). • The overall Active Load system operates at an efficiency of 85%. • Efficiencies of the DC-DC converter & grid- inverter were 95% and 89% respectively. 36

  37. Conclusions The results show that: The Regenerative Active Load unit has the potential of saving electrical energy used in testing in Industry. The overall efficiency of the Regenerative Active Load unit ranged from 77% to 85% when operating at full power.

  38. Further Work • To operate system with a wider range of electrical DC supply equipment, modular converters will have to be employed. • This shall require that modular converters be connected in parallel or in series depending on the input voltage requirements. • Simulation showed successful parallel and series operation. • A method of interleaved switching will be applied to obtain a further reduction in the current ripple.

  39. Thank you for your attention MALTA
