Reaction Mechanism

temima avatar
temima
16 diapositives · 822 Views · Feb 23, 2014

Reaction Mechanism. Reaction Mechanism. Process by which a reaction occurs Reaction occurring in a single event or step its called an elementary reaction Total reaction may by a sequence of elementary reactions

#label #hair trigger #trigger #response #displacement #reaction formation #inflammation #reactor
Reaction Mechanism - slide 1
01 / 16Reaction Mechanism
1 / 17

Télécharger la présentation

Reaction Mechanism
Une image / un lien ci-dessous est fourni (tel quel) pour télécharger la présentation

Politique de téléchargement : le contenu du site vous est fourni TEL QUEL pour votre information et votre usage personnel ; il ne peut être vendu, concédé sous licence ni partagé sur d’autres sites sans l’accord de son auteur.Le contenu vous est fourni TEL QUEL, pour votre information et votre usage personnel uniquement. Téléchargez la présentation en cliquant sur ce lien. Lors du téléchargement, si vous ne parvenez pas à télécharger une présentation, l’éditeur a peut-être supprimé le fichier de son serveur.Pendant le téléchargement, si vous ne parvenez pas à obtenir une présentation, le fichier a peut-être été supprimé par l’éditeur.

F I N

Plus de contenu associé

Transcription de la présentation

  1. Reaction Mechanism

  2. Reaction Mechanism • Process by which a reaction occurs • Reaction occurring in a single event or step its called an elementary reaction • Total reaction may by a sequence of elementary reactions • The elementary reactions in a multi-step mechanism must always add to give the chemical equation of the overall reaction

  3. Substances that are formed in one elementary step and consumed in the next are called intermediates • Number of molecules that participate as reactants in an elementary reaction define the moleculartiy • Unimolecular – one reactant • Bimolecular – two • Termolecular - three

  4. Example • It has been proposed that ozone is converted into oxygen gas through the mechanism below a) write the equation for the overall reaction b) identify any intermediates c) describe the molecularity of each step O3 O2 + O O3 + O  2O2

  5. Rate • It is not the overall reaction that determines the rate law rather the elementary reactions • Rate law of an elementary reaction is based on its molecularity • In general the order for each reactant in an elementary reaction is equal to its coefficient in the elementary reaction

  6. Example • If the following reaction occurs in a single elementary step, predict the rate law: O3 + NO  NO2 + O2

  7. Rate-Determining Step • If reaction occurs in a series of elementary steps, one step is often much slower than the others • The slow step limits the speed of the reaction – called the rate determining step

  8. Example • A reaction occurs according to the mechanism below, write the rate law NO2 + NO2 NO3 + NO (slow) NO3 + CO  NO2 + CO2 (fast)

  9. This reaction takes place in three steps

  10. First step is fast Low activation energy Ea

  11. Ea Second step is slow High activation energy

  12. Ea Third step is fast Low activation energy

  13. Second step is rate determining

  14. Intermediates are present

  15. Activated Complexes or Transition States

  16. Mechanisms and rates • There is an activation energy for each elementary step. • Slowest step (rate determining) must have the highest activation energy.
