  1. Chapter 9: Algorithm Efficiency and Sorting Chien Chin Chen Department of Information Management National Taiwan University

  2. Measuring the Efficiency of Algorithms (1/5) • Measuring an algorithm’s efficiency is very important. • Your choice of algorithm for a application often has a great impact. • Components that contribute to the cost of a computer program: • The cost of human time. • Time of development, maintenance … • The cost of program execution. • The amount of computer time and space that the program requires to execute.

  3. Measuring the Efficiency of Algorithms (2/5) • Analysis of algorithms: • Provides tools for contrasting the efficiency of different algorithms. • Time efficiency, space efficiency • Should focus on significant differences in efficiency. • Should not consider reductions in computing costs due to clever coding tricks.

  4. Measuring the Efficiency of Algorithms (3/5) • This chapter focuses on time efficiency. • Comparison: implement different programs; check which one is faster. • Three difficulties with comparing programs instead of algorithms: • How are the algorithms coded? • What computer should you use? • What data should the programs use? • The most important difficulty.

  5. Measuring the Efficiency of Algorithms (4/5) • Algorithm analysis should be independent of : • Specific implementations. • Computers. • Data. • How? • Counting the number of significant operations in a particular solution.

  6. Measuring the Efficiency of Algorithms (5/5) • Counting an algorithm's operations is a way to assess its time efficiency. • An algorithm’s execution time is related to the number of operations it requires. • Example: Traversal of a linked list of n nodes. • n + 1 assignments, n + 1 comparisons, n writes. • Example: The Towers of Hanoi with n disks. • 2n - 1 moves.  1 assignment Node *cur = head; while (cur != NULL) { cout << cur->item << endl; cur = cur->next; }  n+1 comparisons  n writes  n assignments

  7. Algorithm Growth Rates (1/3) • An algorithm’s time requirements can be measured as a function of the problem size(instance characteristic). • Number of nodes in a linked list. • Size of an array. • Number of items in a stack. • Number of disks in the Towers of Hanoi problem. • Algorithm efficiency is typically a concern for large problems only.

  8. Algorithm Growth Rates (2/3) Varies with different computers and implementations. • Algorithm A requires time proportional ton2 • Algorithm B requires time proportional ton

  9. Algorithm Growth Rates (3/3) • An algorithm’s growth rate: • How quickly the algorithm’s time requirement grows as a function of the problem size. • Algorithm A requires time proportional to n2. • Algorithm B requires time proportional to n. • Algorithm B is faster than algorithm A. • n2 and n are growth-rate functions. • A mathematical function used to specify an algorithm’s order in terms of the size of the problem. • Algorithm A is O(n2) - order n2. • Algorithm B is O(n) - order n. • Big O notation.

  10. Order-of-Magnitude Analysis and Big O Notation (1/5) • Definition of the order of an algorithm: Algorithm A is order f(n) – denoted O (f(n)) – if constants k and n0 exist such that A requires no more than k * f(n) time units to solve a problem of size n ≥ n0.

  11. Order-of-Magnitude Analysis and Big O Notation (2/5) O(1) constant

  12. Order-of-Magnitude Analysis and Big O Notation (3/5)

  13. Order-of-Magnitude Analysis and Big O Notation (4/5) • Order of growth of some common functions: • O(1) < O(log2n) < O(n) < O(n * log2n) < O(n2) < O(n3) < O(2n). • Properties of growth-rate functions: • O(n3 + 3n) is O(n3): ignorelow-order terms. • O(5 f(n)) = O(f(n)): ignore multiplicative constant in the high-order term. • O(f(n)) + O(g(n)) = O(f(n) + g(n)).

  14. Order-of-Magnitude Analysis and Big O Notation (5/5) • An algorithm can require different times to solve different problems of the same size. • Average-case analysis • A determination of the average amount of time that an algorithm requires to solve problems of size n. • Best-case analysis • A determination of the minimum amount of time that an algorithm requires to solve problems of size n. • Worst-case analysis • A determination of the maximum amount of time that an algorithm requires to solve problems of size n. • Is easire to calculate and is more common.

  15. Keeping Your Perspective (1/2) • Only significant differences in efficiency are interesting. • Frequency of operations: • When choosing an ADT’s implementation, consider how frequently particular ADT operations occur in a given application. • However, some seldom-used but critical operations must be efficient. • E.g., an air traffic control system.

  16. Keeping Your Perspective (2/2) • If the problem size is always small, you can probably ignore an algorithm’s efficiency. • Order-of-magnitude analysis focuses on large problems. • Weigh the trade-offs between an algorithm’s time requirements and its memory requirements. • Compare algorithms for both style and efficiency.

  17. The Efficiency of Searching Algorithms (1/2) • Sequential search • Strategy: • Look at each item in the data collection in turn. • Stop when the desired item is found, or the end of the data is reached. • Efficiency • Worst case: O(n)

  18. The Efficiency of Searching Algorithms (2/2) • Binary search of a sorted array • Strategy: • Repeatedly divide the array in half. • Determine which half could contain the item, and discard the other half. • Efficiency • Worst case: • For large arrays, the binary search has an enormous advantage over a sequential search. • At most 20 comparisons to search an array of one million items. O(log2n)

  19. Sorting Algorithms and Their Efficiency • Sorting: • A process that organizes a collection of data into either ascending or descending order. • The sort key. • The part of a data item that we consider when sorting a data collection. • Categories of sorting algorithms. • An internal sort: • Requires that the collection of data fit entirely in the computer’s main memory. • An external sort: • The collection of data will not fit in the computer’s main memory all at once, but must reside in secondary storage.

  20. Selection Sort (1/9) • Strategy: • Select the largest (or smallest) item and put it in its correct place. • Select the next largest (or next smallest) item and put it in its correct place. • And so on. • Until you have selected and put n-1 of the n items. • Analogous to card playing.

  21. Selection Sort (2/9) • Shaded elements are selected; boldface element are in order. Initial array: Select: swap Partial sorted array: Select: swap Sorted array:

  22. /** Finds the largest item in an array. * @pre theArray is an array of size items, size >= 1. * @post None. * @param theArray The given array. * @param size The number of elements in theArray. * @return The index of the largest item in the array. The * arguments are unchanged. */ int indexOfLargest(const DataType theArray[], int size) { int indexSoFar = 0; // index of largest item // found so far for (int currentIndex = 1; currentIndex < size; ++currentIndex) { if (theArray[currentIndex] > theArray[indexSoFar]) indexSoFar = currentIndex; } // end for return indexSoFar; // index of largest item } // end indexOfLargest typedef int DataType; 0 1 indexSoFar: currentIndex size-1

  23. Selection Sort (4/9) /** Swaps two items. * @pre x and y are the items to be swapped. * @post Contents of actual locations that x and y * represent are swapped. * @param x Given data item. * @param y Given data item. */ void swap(DataType& x, DataType& y) { DataType temp = x; x = y; y = temp; } // end swap

  24. Selection Sort (5/) /** Sorts the items in an array into ascending order. * @pre theArray is an array of n items. * @post The array theArray is sorted into ascending order; * n is unchanged. * @param theArray The array to sort. * @param n The size of theArray. */ void selectionSort(DataType theArray[], int n) { // last = index of the last item in the subarray of // items yet to be sorted, // largest = index of the largest item found for (int last = n-1; last >= 1; --last) { // select largest item in theArray[0..last] int largest = indexOfLargest(theArray, last+1); // swap largest item theArray[largest] with // theArray[last] swap(theArray[largest], theArray[last]); } // end for } // end selectionSort

  25. Selection Sort (6/9) • Analysis: • Sorting in general compares, exchanges, or moves items. • We should count these operations. • Such operations are more expensive than ones that control loops or manipulate array indexes, particularly when the data to be sorted are complex. • The for loop in the function selectoinSort executes n-1 times. • indexOfLargest and swap are called n-1 times.

  26. Selection Sort (7/9) • Each call to indexOfLargest causes its loop to execute last(or size – 1) times. • Cause the loop to execute a total of: • (n-1) + (n-2) + … + 1 = times. • Each execution of the loop performs one comparison: • The calls of indexOfLargest require n*(n-1)/2comparisons. n*(n-1)/2

  27. Selection Sort (8/9) • The n-1 calls to swap require: • 3 * (n-1)moves. • Together, a selection sort of n items requires: • n*(n-1)/2 + 3(n-1) = n2/2 + 5n/2 -3 major operations. • Thus, selection sort is O(n2).

  28. Selection Sort (9/9) • Does not depend on the initial arrangement of the data. • Best case = worst case = average case = O(n2) • Only appropriate for small n!!

  29. Bubble Sort (1/4) • Strategy • Compare adjacent elements and exchange them if they are out of order. • Moves the largest (or smallest) elements to the end of the array. • Repeating this process eventually sorts the array into ascending (or descending) order.

  30. Bubble Sort (2/4) Pass 1 Pass 2 Initial array: Initial array: swap swap swap

  31. Bubble Sort (3/) /** Sorts the items in an array into ascending order. * @pre theArray is an array of n items. * @post theArray is sorted into ascending order; n is unchanged. * @param theArray The given array. * @param n The size of theArray. */ void bubbleSort(DataType theArray[], int n) { bool sorted = false; // false when swaps occur for (int pass = 1; (pass < n) && !sorted; ++pass) { sorted = true; // assume sorted for (int index = 0; index < n-pass; ++index) { int nextIndex = index + 1; if (theArray[index] > theArray[nextIndex]) { // exchange items swap(theArray[index], theArray[nextIndex]); sorted = false; // signal exchange } // end if } // end for } // end for } // end bubbleSort You can terminate the process if no exchanges occur during any pass.

  32. Bubble Sort (4/4) • Analysis: • In the worst case, the bubble sort requires at most n-1 passes through the array. • Pass 1 requires n-1 comparisons and at most n-1 exchanges. • Pass 2 require n-2 comparisons and at most n-2 exchanges. • ... • Require a total of • (n-1) + (n-2) + … + 1 = n*(n-1)/2 comparisons. • (n-1) + (n-2) + … + 1 = n*(n-1)/2 exchanges. • Each exchange require 3 moves. • Thus, altogether there are: 2 * n*(n-1) = O(n2) • In the best case: require only one pass. • n-1 comparisons and no exchanges: O(n)

  33. Insertion Sort (1/4) • Strategy: • Partition the array into two regions: sorted and unsorted. • At each step, • Take the first item from the unsorted region. • Insert it into its correct order in the sorted region. insert sorted unsorted

  34. Insertion Sort (2/4) • You can omit the first step by considering the initial sorted region to be theArray[0] and the initial unsorted region to be theArray[1...n-1]. Initial array: Initial array: shift: shift: shift: insert: insert:

  35. Insertion Sort (3/) /** Sorts the items in an array into ascending order. * @pre theArray is an array of n items. * @post theArray is sorted into ascending order;n is unchanged. * @param theArray The given array. * @param n The size of theArray. */ void insertionSort(DataType theArray[], int n) { for (int unsorted = 1; unsorted < n; ++unsorted) { DataType nextItem = theArray[unsorted]; int loc = unsorted; for (;(loc > 0) && (theArray[loc-1]> nextItem); --loc) // shift theArray[loc-1] to the right theArray[loc] = theArray[loc-1]; // insert nextItem into Sorted region theArray[loc] = nextItem; } // end for } // end insertionSort nextItem 5 unsorted 9 5 7 7 9 5 loc

  36. Insertion Sort (4/4) • Analysis: • In the worst case, the outer for loop executes n-1 times. • This loop contains an inner for loop that executes at mostunsorted times. • unsorted ranges from 1 to n-1. • Number of comparisons and moves: • 2 * [1+2+…+(n-1)] = n*(n-1). • The outer loop moves data items twice per iteration, or 2*(n-1) times. • Together, there are n*(n-1) + 2*(n-1) = n2+n-2 major operations in the worst case, O(n2). • Prohibitively inefficient for large arrays.

  37. Mergesort (1/9) • A recursive sorting algorithm. • Strategy: • Divide an array into halves. • Sort each half (by calling itself recursively). • Merge the sorted halves into one sorted array. • Base case: an array of one item IS SORTED.

  38. Mergesort (2/9) theArray: Divide the array in half and conquer ... sorted array: Merge the halves tempArray: 1 2 3 4 8 copy theArray:

  39. Mergesort (3/9) /** Sorts the items in an array into ascending order. * @pre theArray[first..last] is an array. * @post theArray[first..last] is sorted in ascending order. * @param theArray The given array. * @param first The first element to consider in theArray. * @param last The last element to consider in theArray. */ void mergesort(DataType theArray[], int first, int last) { if (first < last) { int mid = (first + last)/2; // index of midpoint mergesort(theArray, first, mid); mergesort(theArray, mid+1, last); // merge the two halves merge(theArray, first, mid, last); } // end if } // end mergesort

  40. const int MAX_SIZE = 10000; void merge(DataType theArray[], int first, int mid, int last) { DataType tempArray[MAX_SIZE]; // temporary array // initialize the local indexes to indicate the subarrays int first1 = first; // beginning of first subarray int last1 = mid; // end of first subarray int first2 = mid + 1; // beginning of second subarray int last2 = last; // end of second subarray // while both subarrays are not empty, copy the // smaller item into the temporary array int index = first1; // next available location in // tempArray for (; (first1 <= last1) && (first2 <= last2); ++index) { if (theArray[first1] < theArray[first2]) { tempArray[index] = theArray[first1]; ++first1; } else { tempArray[index] = theArray[first2]; ++first2; } // end if } // end for Mergesort (4/) first1 last1 first2 last2 anArray first mid last index 3 5 tempArray

  41. Mergesort (5/9) // finish off the nonempty subarray // finish off the first subarray, if necessary for (; first1 <= last1; ++first1, ++index) tempArray[index] = theArray[first1]; // finish off the second subarray, if necessary for (; first2 <= last2; ++first2, ++index) tempArray[index] = theArray[first2]; // copy the result back into the original array for (index = first; index <= last; ++index) theArray[index] = tempArray[index]; } // end merge

  42. Mergesort (6/9) void mergesort(DataType theArray[], int first, int last) { if (first < last) { int mid = (first + last)/2; mergesort(theArray, first, mid); mergesort(theArray, mid+1, last); merge(theArray, first, mid, last); } } mergesort(theArray,0,5) mergesort(theArray,3,5) mergesort(theArray,0,2) mergesort(theArray,1,1) mergesort(theArray,0,1)

  43. Mergesort (7/9) • Analysis (worst case): • The merge step of the algorithm requires the most effort. • Each merge step merges theArray[first…mid] and theArray[mid+1…last]. • If the number of items in the two array segment is m: • Merging the segments requires at most: • m-1comparisons. • mmoves from the original array to the temporary array. • mmoves from the temporary array back to the original array. • Each merge requires 3*m-1 major operations.

  44. Mergesort (8/9) Level 0 n Merge n items: 3*n-1 operations or O(n) Level 1 n/2 n/2 Merge two n/2 items: 2*(3*n/2-1) operations 3n-2 operations or O(n) Level 2 n/4 n/4 n/4 n/4 Each level requires O(n) operations . . . Level log2n (or 1 + log2n rounded down) 1 1 1 1 1 1 Each level O(n) operations & O(log2n) levels  O(n*log2n)

  45. Mergesort (9/9) • Analysis: • Worst case: • Average case: • Performance is independent of the initial order of the array items. • Advantage: • Mergesort is an extremely fast algorithm. • Disadvantage: • Mergesort requires a second array as large as the original array. O(n * log2n). O(n * log2n).

  46. Quicksort (1/15) • A divide-and-conquer algorithm. • Strategy: • Choose a pivot. • Partition the array about the pivot. • Pivot is now in correct sorted position. • The items in [first…pivotIndex-1] remain in positions first through pivotIndex-1 when the array is properly sorted. • Sort the left section and Sort the right section. (solve small problems)

  47. Quicksort (2/15) • Partition algorithm: • To partition an array segment theArray[first…last]. • Choose a pivot. • If the items in the array are arranged randomly, you can choose a pivot at random. • Choose theArray[first] as the pivot. • Three regions: S1, S2, and unknown.

  48. Quicksort (3/15) • Initially, all items except the pivot (theArray[first]) constitute the unknown region. • Conditions: • lastS1 = first • firstUnknown = first + 1 • At each stop, you examine one item of the unknown region. • i.e., theArray[firstUnknown]. • Determine in which of the S1 or S2 it belongs, and place it there. • Then decrease the size of unknown by 1 (i.e., firstUnknown++). first lastS1 firstUnknown last

  49. Quicksort (4/15) • Move theArray[firstUnknown] into S1: • Swap theArray[firstUnknown] with theArray[lastS1+1]. • Increment lastS1. • Increment firstUnknown. swap S2 unknown S1 ≧p <p <p ≧p <p ≧p ? first lastS1 firstUnknown last

  50. Quicksort (5/15) • Move theArray[firstUnknown] into S2: • Simply increment firstUnknown by 1. S2 unknown S1 ≧p <p ≧p ? first lastS1 firstUnknown last
