Presentation Transcript

  1. GridLAB-D and OpenDSS: Better Together 5 September 2019 Thomas E. McDermott Thomas.McDermott@pnnl.gov

  2. GridLAB-D originated to handle buildings, controls, grid and markets. OpenDSS Domains Thomas.McDermott@pnnl.gov

  3. OpenDSS originated from harmonics analysis and DER siting optimization. Auto-adding DG at yellow sites to defer feeder and substation upgrades Injecting harmonic currents into a grid model Thomas.McDermott@pnnl.gov

  4. OpenDSS solves time-series power flow with two loops; power flow (fixed point) and controls (queue). Note: phases are numbered and flexibly connected Thomas.McDermott@pnnl.gov

  5. Which one is better? It depends… Thomas.McDermott@pnnl.gov

  6. Example 1: feeder model conversions between CYMDIST, OpenDSS, CIM and GridLAB-D An SCE circuit layout in OpenDSS Thomas.McDermott@pnnl.gov

  7. Example 2: automates OpenDSS via Framework for Network Cosimulation (FNCS), as with GridLAB-D Total Feeder Load with Switching and PV Add 285 kW PV Open At Noon fncs_player fncs_broker opendsscmd Thomas.McDermott@pnnl.gov

  8. Example 3: linking OpenDSS power flow to GridLAB-D houses and weather over FNCS irradiance power voltage Thomas.McDermott@pnnl.gov

  9. References • Downloading GridLAB-D: https://sourceforge.net/projects/gridlab-d/ • Downloading OpenDSS: https://sourceforge.net/projects/electricdss/ • Downloading OpenDSSCmd: https://sourceforge.net/projects/electricdss/files/OpenDSSCmd/ • Chassin, Fuller, Djilali, “GridLAB-D: An agent-based simulation framework for smart grids”, 2014, doi: 10.1155/2014/492320 • Dugan, McDermott, “An open source platform for collaborating on smart grid research”. 2011, doi: 10.1109/PES.2011.6039829 • Ciraci, Daily, Fuller, Fisher, Marinovici, Agarwal, “FNCS: a framework for power system and communication networks co-simulation”, 2014, https://dl.acm.org/citation.cfm?id=2665044 • Model Converters: https://github.com/GRIDAPPSD/Powergrid-Models/tree/develop • CIM Schema: https://gridappsd.readthedocs.io/en/master/developer_resources/index.html#cim-documentation Thomas.McDermott@pnnl.gov
