  1. MAP CPE Solutions

  2. Agenda FCD Family Overview Applications

  3. Variety of Services – FCD NTU Family POTS Analog Voice • Convergence of multiple services • Centralized Management • Integrated Local Loop ISDN Switch ISDN “S0” FCD Family 10/100BaseT Ethernet E1/T1 Fractional E1/T1 LAN Network Copper Fiber Router n x 56/64Kbps PBX FE1/T1

  4. TDM Multiplexers With Integrated Router FCD-E1/FCD-T1 FCD-IP FCD-E1A FCD-IPD FCD-E1M/T1M FCD-E1LC/FCD-T1LC FCD-IPM FCD-E1L/FCD-T1L FCD-IPL Others FCD Family – Compact Multiservice NTUs FCD Family

  5. Product Highlight: FCD-E1LC/T1LC • Uplink: framed or unframed E1/T1 • User interfaces: Single or dual n x 56/64 kbps, Ethernet (Bridge 10/100, VLAN), sub E1/T1 link • Power supply: wide range (AC & -48vDC) power supply • Management options: SNMP agent, RADview NMS, Telnet, ASCII terminal • Low cost Router 10/100BaseT Bridge Only Serial Data (V.35, X.21 etc) FCD-E1LC FCD-T1LC Router n x 64 kbps E1/T1 TDM Copper PBX Sub E1/T1

  6. Multi-service NTU • Single SNMP Management platform • Multiple services • Managed by single time slot Router FCD-E1L LAN Router DXC ADM FCD- E1L E1 E1 Network E1 Router Router PBX NMS FCD- E1LC LAN

  7. FCD-IP as “Mini Megaplex” E1/T1 (Fiber and Copper) Daisy Chain Application High Capacity Ring Application Shared LAN 3 SUB E1 OSPF Routing FCD-IP MP-2100/2104

  8. Aggregation E1 Application – FCD-IP FCD-IP SUB E1 • Aggregation of 3 Sub E1 channels • Manageable product • Adding value to installed base – easy expansion of existing networks LAN LAN FCD-IP FCD-IP SUB E1 E1 PBX Network LAN FCD-IP SUB E1 PBX

  9. Agenda FCD Family Overview • Applications

  10. Daisy chain solution for the utilities, mobile and transportation markets Drop-and-insert topology saves cost of leased lines or infrastructure investment Drop-off any service Optimized solution for specific node requirements Multiple Services in Daisy Chain Topology AirMux-200 AirMux-200 AirMux-200 AirMux-200 MP-2104 MP-2104 FCD-IP FCD-IP

  11. E1 Ring Topology Solution Video • Flexible • Reliable (SDH-like protection) • Reduced number of products per solution • Reduce space costs • Attractive price/performance • Simple to implementation Fire Alarm ETH MP-2104 FCD-IP FXS FXS E1 Ring ETH MP-2100 PBX NMS Servers

  12. T1/E1 Ring, RFER and Daisy Chain PC “U” Interface ASMi-31 PBX • Highlights: • Ring topology= No single point of failure • Up to 50ms protection speed for RFER and up to 5sec for the T1/E1 Ring • In case of link failure, minimum services down time • Daisy-chain enables support for more services at different locations MP MP PSTN FCD E1/T1 LS Data T1/E1 Ring OR Fast ETH Ring LS Terminal T1/E1/FE MP MP T1/E1/FE LS Data LS Terminal MP T1/E1/FE MP MP

  13. TETRA Backhauling BTS BTS • Base stations can be connected using E1, Serial interface or Ethernet • E1/T1 Ring and RFER for low cost, quick self healing transport layer • Multiple rings for flexible and resilient solution • Fully managed solution • Different form factors for different node needs • Migration path to IP networks • Successfully deployed FCD-IP MP-2104 BTS BTS MP-2104 FCD-IP MSO BTS BTS MP-2104 MP-2104 MP-4100 Remote Dispatcher Room MP-2104 n x 4W FE n x RS-232 Control Room Router Switch
