  1. DBI317 Optimizing SQL Server Performance in a Virtual Environment Denny Cherry Independent Consultant www.mrdenny.com

  2. www.mrdenny.com mrdenny@mrdenny.com @mrdenny Denny Cherry

  3. Topics of Discussion • Diagnosing Performance Problems • Balloon Memory Drivers • Memory Deduplication Options • Storage Configuration Options

  4. Diagnosing Performance Problems • Check Host and Guest CPU numbers • Check Host for CPU thrashing • Check Host and Guest for Disk IO latency

  5. Balloon Memory Drivers • Used by host OS to request memory back from the guest OS • Prevents host of from paging physical memory to the hosts swap file • Should be enabled • Lock pages in memory should be disabled, unless enabled for a specific reason

  6. Memory Reservations • Forces the memory to be available for the guest • Recommended that it be set to a portion of the allocated memory

  7. Memory Reservations • Forces the memory to be available for the guest • Recommended that it be set to a portion of the allocated memory

  8. Memory DeduplicationOptions • Great for OS memory • Doesn’t work at all for SQL Server • Unless… multiple SQL Servers have the same pages in cache

  9. Storage Configuration Options • IO is the same if the disks are physical or virtual • Use automatic tier adjusting technology if possible • Keep OS, data, logs, tempdb on separate disks if possible

  10. Storage Deduplication • Can greatly improve overall performance • By deduplicating OS virtual disks, we save much less data to the array • As less data is written to the array, less OS data is loaded into cache on the array

  11. Monitor, Monitor, Monitor • Did I mention that you need to monitor • Watch all levels of the environment • SQL Server • Guest • Hypervisor • Host • Storage

  12. Related Content • Breakout Sessions (VIR401, VIR308, VIR 309, DBI313, DBI312) Hands-on Labs (DBI12-HOL, DBI11-HOL) Product Demo Stations (demo station title and location) MCSE SQL Server 2012 Find Me Later At the SQL Server Booth

  13. DBI Track Resources @sqlserver @teched_europe #msTechEd SQL Server 2012 Eval Copy Hands-On Labs Get Certified! mva Microsoft Virtual Academy

  14. Resources Learning TechNet • Connect. Share. Discuss. • Microsoft Certification & Training Resources http://europe.msteched.com www.microsoft.com/learning • Resources for IT Professionals • Resources for Developers http://microsoft.com/technet http://microsoft.com/msdn

  15. Evaluations Submit your evals online http://europe.msteched.com/sessions
