Presentation Transcript

  1. Chapter 21 Section 2

  2. Ocean Waves Objectives • Describe the formation of waves and the factors that affect the wave size • Explain how waves interact with the coastline • Identify the cause of destructive ocean waves

  3. Ocean Waves A wave is a periodic disturbance in a solid, liquid, or gas as energy is transmitted through the medium A wave has two basic parts- a crest and a trough Wave height Wave length(2 trough's) Wave period(2 crests)

  4. Ocean Waves • Pressure differences from uneven heating on Earth causes air to move • Friction between moving air and water causes ripples in ocean water • The longer the wind blows from a given direction the more energy is transferred and the bigger a wave can become

  5. Ocean Waves • As the energy of a wave moves from water molecule to water molecule in the direction of the wave, the water itself moves very little • The water moves in a circular motion and as depth increases the circular energy of the wave decreases • Below a depth of about one-half the wave length there is almost no circular motion of water

  6. Ocean Waves • Three factors determine the size of a wave • The speed of the wind • The length of time the wind blows • The fetch (the distance that the wind can blow across open water)

  7. Ocean Waves • Strong gusty winds produce choppy water that has waves of various heights, lengths, and from different directions

  8. Ocean Waves • When wind blows the crest of a wave off, whitecaps form • Whitecaps reflect incoming solar radiation and may affect climate

  9. Ocean Waves • In shallow water the bottom of the wave touches the ocean floor • This happens when the depth is about half the wave length • The friction slows the bottom of the wave and causes the wave to break • These are called breakers

  10. Ocean Waves • The size and force of breakers are determined by the size of the original wave, the wavelength, and the steepness of the ocean floor close to the coastline • If the coastline is steep, the wave height increases rapidly and the wave breaks with great force • If gentle the wave has a gentle rolling break

  11. Ocean Waves • Most waves approach the coastline at an angle, as the wave reaches shallow water it bends • Refraction is the process by which ocean waves bend towards the coastline as they approach shallow water • Shallow water slows, deeper water maintains the energy

  12. Ocean Waves • Water carried unto a beach by breaking waves is pulled back into deeper water by gravity • This motion is called an undertow (these are usually not strong)

  13. Ocean Waves • Rip currents form when water from large breakers return to the ocean through channels that cut through underwater sandbars that are parallel to the beach • These can quickly carry a swimmer out to sea

  14. Ocean Waves • The most destructive waves in the ocean are not powered by wind • Tsunamis are giant seismic waves which are usually caused by earthquakes on the ocean floor, but may be caused by underwater landslides, or volcanic eruptions

  15. Ocean Waves • Tsunamis have a great amount of energy and can cause massive destruction because of the wave length which can be as long as 500 km • As the tsunamis reaches the shore the height greatly increases and the wave lows, these can reach 30- 40 m in height • Maybe signaled by a sudden pull back of the shoreline
