iNELS MAIN FEATURES

von avatar
von
15 diapositives · 522 Views · Oct 01, 2014

iNELS MAIN FEATURES. BUS system used for complex control electrical installation. elementary functions: switching, dimming, roller blinds and heating control , security system scene, web server, control via GSM. advance d functions: multimedia, meteostation , cameras, touch panels

#inels main features #inels main features ppt #powerpoint #presentation
iNELS MAIN FEATURES - slide 1
01 / 15iNELS MAIN FEATURES
1 / 17

Télécharger la présentation

iNELS MAIN FEATURES
Une image / un lien ci-dessous est fourni (tel quel) pour télécharger la présentation

Politique de téléchargement : le contenu du site vous est fourni TEL QUEL pour votre information et votre usage personnel ; il ne peut être vendu, concédé sous licence ni partagé sur d’autres sites sans l’accord de son auteur.Le contenu vous est fourni TEL QUEL, pour votre information et votre usage personnel uniquement. Téléchargez la présentation en cliquant sur ce lien. Lors du téléchargement, si vous ne parvenez pas à télécharger une présentation, l’éditeur a peut-être supprimé le fichier de son serveur.Pendant le téléchargement, si vous ne parvenez pas à obtenir une présentation, le fichier a peut-être été supprimé par l’éditeur.

F I N

Plus de contenu associé

Transcription de la présentation

  1. iNELS MAIN FEATURES • BUS system used for complex control electrical installation • elementary functions: • switching, dimming, roller blinds and heating control, security system • scene, web server, control via GSM • advanced functions: • multimedia, meteostation, cameras, touch panels • control of air conditioning, monitoring of energy, Miele home appliance • Applications for tablets and smart phones (Android+iOS) • proprietary 2-wire bus, open protocol TCP/IP (Epsnet) • design of switches Logus90 a Elegant • parameterization software iDM (iNELS Design Manager)

  2. iMM– MAIN FEATURES • allows to control and to manage functions iNELS via TV in Full HD • as a central media center is replaced by CD, DVD, BluRay MP3 player, PC and other media • communication via standard LAN • To support connected devices in Zone (TV, amplifier) ​RS232 or eLAN-iR • „Multiroom“ – to control each other and supervision of the various places (Videozones)

  3. WHAT CAN iMM BRING YOU ? • to control electronic devices (BUS and wireless) via TV gyrocontroller (replacement controllers) • all multimedia files in one place = easy sharing for all users • sharing one satellite receiver (streamer) = 1 card (= 1 charge) • connection – 32 videozones, 16 audiozones • to connect up to 9 IP cameras including record • monitoring energy (table + graph history) • to control third party appliances (Miele, HVAC ...) gadgets (web browser, Facebook, Weather Forecast, …) Gyrocontroler IMM Client

  4. INFRASTRUCTURE • Ethernet (TCP/IP) • iMM Server/ Client (Videozone) • Audiozone (Squeezebox) • connection for RF Control (eLAN RF) • IP Cameras (PTZ support) • Meteostation (IP or 0-10V) • Air Conditioning: direct (LG) or indirect connection (Coolmaster) • RPCXML server for mobile devices • converters for RS-232 / RS-485

  5. WHAT WE CAN CONTROL BY iMM?

  6. DESCRIPTION DEFAULT SCREEN OF APPLICATION

  7. MULTIMEDIA FORMATS SUPPORTED Photos Playback pictures in formats JPG, PNG, GIF Music Playback music in formats MP3, FLAC, WAV, WMA Video Playback movies in formats AVI, MPG, MP4, MKV, TS, VOB, WMV with subtitles SRT or SUB Radio on the internet Playback internet radios in formats WMA, AAC, MP3, M3U

  8. THIRD PARTYDEVICE INTEGRATION Miele@Home • Communication over „powerline“ • Gateway XGW 2000 • iMM + iTP Energy measuring • Electricity, Water, Gas • Pulse output • Display graphs and total values • History of power consumption

  9. AIR CONDITIONING INTEGRATION Direct connection • LG • Converter 485/ETH • iTP Indirect connection • CoolMaster • For 9 Developors(LG, Daikin, Sanyo) • iMM

  10. DEVICE INTEGRATION OF THIRD PARTY Satellite streamer • DreamBox 7020 (2 tuners) • DreamBox 500 (1 tuner) Door communicator Meteostation • 2N Helios • GIOM 3000

  11. ACCESSORIES Screenlet • Weather forecast • Gmail • Facebook Multiroom FolowMe function Selecting Zones You can cancel at any zone and continue watching the moviein a differentzone The videozone can control any Video or other Audiozone

  12. Application iTP-T (iNELS TOUCH PANEL - TABLET) • Android 2.2 and higher • Control of iNELS, RF elements • Multimedia with iMM Server • Miele, Cameras, LG, HVAC • Meteostation, AirPohoda • 3 Version of license: Basic, Multimedia, Full Control • Autonomic control iNELS without iMMServer • 30 days DEMO to try • Available on the e-shop

  13. APPLICATION iTP-M (iNELS TOUCH PANEL - MOBILE) • Same functions as iTP-T • View Titles or List = Optimization Smartphone • Quick overview and control • Local or Public IP • 3 Versions of License: Basic, Multimedia, Full Control • DEMO version for 30 days • BETA version available

  14. THANK YOU FOR YOUR ATTENTION Seminar intelligent electrical installation buildings iNELS, Holešov Ing. Martin Ševela Product Manager iNELS RELEVANT LINKS • Manual for iMM: http://www.inels.cz/media/download/Instalacni_manual_iMM.pdf Manual for iTP Application: http://www.inels.cz/downloads/itp/Uzivatelsky_navod_iTP_android.pdf Public Forum: https://cds.elkoep.cz/forum/inelsforum/_layouts/viewlsts.aspx?BaseType=0&ListTemplate=108 • Ticket System (Technical questions): http://cds.elkoep.cz:8787/ Public iMM server (pro rooms.cfg) : http://nigs232.nwt.cz:8080/
