  1. OmniSwitch 9000E Application Fluent NetworkA New Approach to Network Infrastructure Month 201x

  2. Agenda • AFN Introduction • OmniSwitch 9000E • Positioning • Deployment Scenarios

  3. 1 AFN Introduction

  4. Explosion of applications & devices Virtualizationchangeseverything Raw bandwidth no longerenough Network under unprecedented stress

  5. Alcatel-Lucent’s Application Fluent Network ApplicationFluent Network Devices Uniquely enables a high quality user experience with reduced complexity Applications Communication platform

  6. Alcatel-Lucent’s Application Fluent Network Architecture Resilient Architecture • Simplified • Secure Automatic Control • Dynamic Performance Tuning • Quality Application Delivery Streamlined Operations • Low-Touch Provisioning • Integrated SLA Monitoring Control Operations

  7. Product Portfolio at a Glance IP Address Mgt Infrastructure Mgt Service Mgt Network Mgmnt OmniVista 2500 OmniVista 3600 5620 SAM 8950 AAA VitalSuite LAN WLAN WAN 7750 & 7710 SR OmniAccess WLAN 6000 7450 ESS 7705 SAR NetworkInfrastructure OmniAccess WLAN 4000 OmniSwitch 9000 OmniSwitch 10K Access Gateway OmniSwitch 6850 & 6855 OmniAccess 5700 & 5510 USG OmniAccess WLAN, AP & RAP OmniAccess 5300 BG OmniSwitch 6400 & 6250 Embedded Security NAC Threat containment NetworkSecurity Access Guardian Quarantine Manager CyberGatekeeper FortiGate

  8. 2 OmniSwitch 9000E

  9. OmniSwitch 9000E — Value propositions Architecture Operations Control • Capacity and performance reduces layers • HW and SW redundancy provides maximum uptime • L2 & virtualization technologies increase performance and resiliency • Mission critical — VRF and MPLS • Extensive Policy driven traffic management for high quality bandwidth and latency • Profile directed Security & QOS • Automated deployment and configuration • Low energy consumption • Common OmniSwitch operating system (AOS) reduces training and field proven • Installation flexibility — compact size, front accessible components

  10. Product Portfolio at a Glance IP Address Mgt Infrastructure Mgt Service Mgt Network Mgmnt OmniVista 2500 OmniVista 3600 5620 SAM 8950 AAA VitalSuite LAN WLAN WAN 7750 & 7710 SR OmniAccess WLAN 6000 7450 ESS 7705 SAR NetworkInfrastructure OmniAccess WLAN 4000 OmniSwitch 9000 OmniSwitch 10K Access Gateway OmniSwitch 6850 & 6855 OmniAccess 5700 & 5510 USG OmniAccess WLAN, AP & RAP OmniAccess 5300 BG OmniSwitch 6400 & 6250 Embedded Security NAC Threat containment NetworkSecurity Access Guardian Quarantine Manager CyberGatekeeper FortiGate

  11. OmniSwitch 900xE • Models • OS-9700E: 8 Slots – 384Gbps • OS-9702E: 8 Slots – 768Gbps • OS-9800E: 16 Slots – 768Gbps • Fabric • Resides on Management Modules • Two management modules required for maximum performance • Ports Capacity • 10Gig Wire-speed: 32 ports • 10Gig Oversubscribed: 192 ports • 1Gig Wire-speed: 384 ports

  12. Evolution Overview • AOS 6.4.4 introduces new POE + Network Interface Card • OS9-GNI-P24E is a 24 port 10/100/1000 Copper based NI • Supports 30W per port • AOS 6.4.3 introduces new high density 10-Gig Network Interface Card • OS9-XNI-U12E is a 12 port 10 Gig SFP+ based NI • 2.5:1 oversubscription with 9702E • 6:1 oversubscription with 9800 • AOS 6.4.2 to introduce new capabilities to the OS9000/OS9000E • Hardware enhancements • OS9702-CHASSIS, OS9702E-CMM & associated CB/RCB bundles

  13. OS9-GNI-P24E • Overview • 24 RJ-45 ports 10/100/1000 module • Support 802.3at ( 30W per port) , only limited by the total power supplied by the PoE power supply • Dynamic power management is supported • PoE Power Shelf same as OS-9000 platform, no update • Benefits: • Enables the emerging newer POE devices • Enables the OS9000E to be positioned at the edge/access layer

  14. OS9702-CHASSIS • OS9702-CHASSIS • Compatible with either OS9000 or OS9000E modules (no mix supported) • A replacement product for the OS9700-CHS-FED • Benefits • New backplane for higher capacity switching • More connections, higher speed signals (+33% on backplane capacity) • NEBS Level 3 ready • Certification targeted in Q4 2009, filters will be made available at that time • Flexible assembly (additional attachment holes & removable hardware) • Allowing various options for custom rack mounting • Integrated alarm card (for future use) • Capability to generate outgoing events

  15. OS9702E-CMM • OS9702E-CMM • Operate in OS9700-CHASSIS & OS9702-CHASSIS • Compatible with existing OS9000E Network Interfaces Modules • Benefits • Expanded memory • 1GB of RAM & 256MB of Flash (required for ISSU support) • Double capacity for its embedded switching fabric (compared to previous generation) • Requires the OS9702-CHASSIS for delivering the extra capacity to NIs • 1+1 fabric redundancy for the following modules when combined with OS9702-CHASSIS • OS9-GNI-U24E • OS9-GNI-C24E • OS9-XNI-U12E

  16. Summary • Chassis options for OS9000E modules: • OS9000E chassis to provide 24Gbps (48Gbps half-duplex) between NIs & CMMs • OS9002E chassis to provide 48Gbps (96Gbps half-duplex) between NIs & CMMs • Effective capacity is then determined by the CMM used:

  17. 3 Positioning

  18. OS9000 and 9000E Positioning MetroEthernet Aggregation Service Routers Features, Flexibility, Performance 1st Tier SPs 2ndTier SPs Core/DataCenter Distribution\Aggregation Edge\Wiring Closet Small Medium Large

  19. OmniSwitch 9000E Modular LAN Chassis Positioning Enterprise Edge & Aggregation 1G and 10G port density POE+, Edge security Large Enterprise Core & Distribution High density 10G, 40G/100G ready 256*10G ports non-blocking performance Lossless fabric, Virtual output Queuing MC-LAG OS10K OS9E System performance 10G, 40G, 100G Port density OmniSwitch 9000/E OmniSwitch 10K

  20. 4 Deployment Scenarios

  21. LAN: High Availability • Network Switches • Redundant switching fabric & management • Redundant power supplies • Redundant stack loop • Hot swapability • Hardened OS & embedded security • In Service Software Upgrade (OS9000E) Server access Core • Network links • UDLD • LACP Distribution Network topology • L2: DHL,MSTP, PVST, Ring RSTP, ERP… • IPv4: RIP, OSPF, BGP, VRRP,… • IPv6: RIPng, OSPFv3,.. • MPLS and MPLS fast re-route (for 9000E) Access Resilient switches, links and topology for network continuity

  22. Increasing Network Availability and Reliability >1s reconvergence time with conventional Spanning Tree Protocol With Alcatel-Lucent Ethernet Ring Protection, network converges in less than 50 ms Alcatel-Lucent innovations deliver network continuity

  23. OmniSwitch 6xxx OmniSwitch 6xxx OmniSwitch 6xxx Admin Admin Admin OmniSwitch 900xE OmniSwitch 900xE OmniSwitch 900xE OmniSwitch 900xE OmniSwitch 900xE Staff Staff Agent Agent Agent Staff Enterprise “Metro” MPLS MPLS/VPLS Domain with Static FRR Enterprise QoS for service prioritization ISSU Sample design topology E2E Small Scale Enterprise Network

  24. Data Center interconnection with Alcatel-Lucent equipment VPLS VPLS : Easily extend DC, loop free by nature Easily Add sites and manage end to end configuration with 5620. 5620 NM OS9000E OS6850 OS9000E OS6850 7450 ESS-12 7450 ESS-12 OS9000E OS9000E OS9000 OS9000 7450 ESS-12 7450 ESS-12 OS9000E OS9000E OS9000 OS6850 DataCenter 2 DataCenter 1

  25. 7750 SR 7750 SR 7750 SR 7750 SR OmniSwitch 6xxx OmniSwitch 6xxx OmniSwitch 6xxx OmniSwitch 6xxx High Availability for Mission Critical/SP Services Nodes Hardware Redundancy Fast Reroute MC-LAG DHL OmniSwitch 900xE OmniSwitch 900xE ERP OmniSwitch 900xE OmniSwitch 900xE In Service Software upgrade Available HA features/design options More Reliable Network Supports Business Critical Applications

  26. www.alcatel-lucent.com www.alcatel-lucent.com 26 | Presentation Title | Month Year

  27. Backup – Technical Details

  28. Compatibility & per-slot performance chart * MPLS and OS9-XNI-U12E are mutually exclusive

  29. OS9000 Network Interface Cards

  30. OS9000 Options

  31. OS9000 - Throughput • Throughput numbers are for uni-directional traffic

  32. OS9000 Features Matrix

  33. OS9000 – Over-Subscription • All other modules are wire-speed
