  1. S.Kuroda ( KEK ) RTML( Except Bunch Compressor ) Parameters and Layout Diagnostics and Beam Tuning Accelerator Physics Accelerator Components

  2. Beam Parameters

  3. Layout

  4. Extraction from the DR ( ERTL/PRTL ) No vertical dogleg in ERTL because of the DR vertical position

  5. Return Line ( ELTL/PLTL ) • Following the earth’s curvature in ML tunnel V correctors in each Q V dispersion matching by v correctors at both ends

  6. Return Line ( ELTL/PLTL )(2) Geometry of the dog-leg defined in document EDMS: D*0969955 • Horizontal dogleg at the junction of ML and BDS, which is different in ELTL and PLTL due to positron target

  7. Return Line ( ELTL/PLTL )(3) Mountain topography Flat topography

  8. Turn Around • Horizontal dogleg • Vertical dogleg to adjust elevation to ML • 180-8 deg. turn around with dispersion matching( 8 deg. is needed for spin rotator ) • Bunch by bunch feed-forward. Time delay is 600 ns. z Spin Rotator x H-dogleg y V-dogleg z

  9. Spin Rotator

  10. Diagnostics • Cavity BPM • Laser Wire for emittance measurement

  11. Beam Tuning • Dispersion Correction • Normal and skew Q in ERTL/PRTL in hx region • In pairs with –I --> No introduction of coupling • Normal Q in h/v dogleg of Turn Around • Coupling correction • 4 skew Qs in zero dispersion region downstream of ERTL/PRRTL and Spin Rotator

  12. Beam Physics Issues • ISR Vertical emittance growth is negligible • Beam-Ion instability ( L.Wang, et al ) • < 2mPa

  13. Beam Physics Issues (2) • Stray Field • Tolerance ( K.Kubo ) • 2nT for orbit jitter of 0.2sy • This can be corrected by fast feed-forward • Higher for emittance growth

  14. Stray Field ( Measurement ) N.Solyak 2011

  15. Beam Physics Issues (3) • Halo Formation from Scattering( S.M.Seletskiy ) • 2mPa  2e-6 of beam intensity < tolerance of 1e-5 • Space-Charge Effect • Incoherent space charge tune shift is O(0.15) in v • To be studied

  16. Beam Physics Issues (4) • Emittance Preservation ( A. Latina )

  17. Accelerator Components • Magnets • Vacuum • Requirement: < 2mPa

  18. Summary and Work to Be Done • Lattice and optics design is almost done in TDR • Must be re-designed when the accelerator length is adjusted. • A few things of accelerator physics issue to be done? • Simulation study should be continued( emittance, ..) • Stray field measurement should be continued. • Space charge tune shift • …
