  1. Dialogue without limits……………. DCN Next Generation

  2. Why a new DCN System ? Trends in the market: • State-of-the-art design and ergonomics • No cell phone disturbances • High-speed, loss-free optical backbone • Audio interfacing and distribution via CobranetTM • Multimedia capabilities like touch screen control • Full graphic display on audience screens • European Union uses 26 interpretation languages • Two delegates using one microphone unit • Increasing trend towards electronic voting • High security via biometrics Wrap up ! Why a new DCN system ? DCN Next Generation

  3. State-of-the-art design and ergonomics • IF Design Award • 1900 products • 740 participants • 31 countries • Design • Landscape / garden effect / organic • Constructivism of Gary O’Geary • Differentiate from competitors • Express innovation Why a new DCN system ? DCN Next Generation

  4. No cell phone disturbances Why a new DCN system ? • Patent has been submitted DCN Next Generation

  5. Incredible speech intelligibility (up to 20kHz) • Audio Bandwidth, 20Hz – 20kHz • Exceeding present standards • Sample rate 44.1 kHz Why a new DCN system ? DCN Next Generation

  6. High-speed, loss-free optical fiber backbone Why a new DCN system ? Trend in new buildings:Optical Fiber DCN Next Generation

  7. Multimedia capabilities like touch screen control • Control a meeting • Microphones • Voting • All room settings Why a new DCN system ? DCN Next Generation

  8. Full graphic display via projectors or plasma displays Show conference data • Voting results • Who has the floor • Messages • Attendance Why a new DCN system ? DCN Next Generation

  9. Automatic camera control Who has the floor Why a new DCN system ? DCN Next Generation

  10. 31 interpretation languages and floor language • High-Quality 64 Channel link between units • 32 HiQ channels uplink • 32 HiQ channels downlink • Floor + 31 Interpretation channels (1+31) Why a new DCN system ? DCN Next Generation

  11. IIIIIIIIIII 31 CHN IIIIIIIIIII 02 ENG Two delegates using one unit • Channel abbreviation • Volume indication Why a new DCN system ? DCN Next Generation

  12. All required voting facilities Configurations • Stand alone, only voting • Full conference facility Facilities • Voting scripts • Result window • Store results • Compare results Why a new DCN system ? DCN Next Generation

  13. Attendance registration with ID cards • Attendance registration • Access control • Present key • PIN • ID card • Biometrics Why a new DCN system ? Why a new DCN system ? DCN Next Generation

  14. Extra microphone information NEW ! • New!Very Important Person • Can always activate their microphone • New! Request to speak • Shows who wants to speak • Patented • Microphone on air Why a new DCN system ? DCN Next Generation

  15. Everything is possible Why a new DCN system ? DCN Next Generation

  16. New Products DCN Next Generation • Contribution • Discussion • Concentus • Flush Mount • Interpretation • Interpreter desks • Channel selector • Central equipment • Central Control Unit • Extension Power Supply • Cobranet Interface • Audio Expander • Analogue • Digital • Software release 2.1 New products DCN Next Generation

  17. DCN Next Generation Discussion Units NEW ! Discussion unit with fixed microphone • Fixed microphone • Single use • Chairman facility • Volume control • Light and dark base New products DCN Next Generation

  18. Free seating for the chairperson NEW ! • Every microphone unit can be changed into a chairperson unit • Adjust switch at bottom • Change the knob • Other advantages • Logistics • Serviceability New products DCN Next Generation

  19. DCN Next Generation Discussion Units Basic discussion unit • Pluggable microphone • Dual use • Chairman facility • Volume control New products DCN Next Generation

  20. Full dual use facility NEW ! • Save on number of microphone units • Two delegates using one microphone unit • Adjust switch at bottom • Change the knob • Two delegates will be identified and are separate addressable New products DCN Next Generation

  21. DCN Next Generation Discussion Units Discussion unit with channel selector • Pluggable microphone • Single use • Chairman facility • 32-channel language selector • Volume control New products DCN Next Generation

  22. DCN Next Generation Discussion Units Discussion unit with dual channel selector • Pluggable microphone • Dual use • Chairman facility • 32-channel language selectors • Volume control New products DCN Next Generation

  23. IIIIIIIIIII 31 CHN IIIIIIIIIII 02 ENG Two delegates using one unit • Channel abbreviation • Volume indication New products DCN Next Generation

  24. DCN Next Generation Discussion Units Discussion unit with voting • Pluggable microphone • Single use • Chairman facility • Volume control • Voting facility New products DCN Next Generation

  25. Make your choice ! NEW ! • Parliamentary • Audience response • Rating • For / against • Multiple choice • Concentus chairman required in stand alone mode New products DCN Next Generation

  26. DCN Next Generation Discussion Units Discussion unit with voting and channel selector • Pluggable microphone • Single use • Chairman facility • 32-channel language selector • Volume control New products DCN Next Generation

  27. DCN Next Generation Discussion Units • Flush mount facility New products DCN Next Generation

  28. Silver high gloss Silver Charcoal Metal semi gloss Metal high gloss Dark Short Design possibilities Accessories Rims • Silver high gloss • Silver • Charcoal • Metal high gloss • Metal semi gloss Base • Light • Dark Microphones • Short • Long New products DCN Next Generation

  29. No unplugged cables during the meeting Cable clamp device Turn and lock New products DCN Next Generation

  30. DCN Next Generation Concentus Units Concentus unit • Pluggable microphone • Flat panel speaker • Volume control New products DCN Next Generation

  31. DCN Next Generation Concentus Units Concentus unit with channel selector • Pluggable microphone • Flat panel speaker • Volume control • 32-channel language selector New products DCN Next Generation

  32. DCN Next Generation Concentus Units Concentus unit full function • Pluggable microphone • Flat panel speaker • Volume control • 32-channel language selector • Graphic LCD with backlighting • ID-card reader New products DCN Next Generation

  33. DCN Next Generation Concentus Units Concentus chairman unit • Pluggable microphone • Flat panel speaker • Volume control • 32-channel language selector • Graphic LCD with backlighting • ID-card reader • Priority button New products DCN Next Generation

  34. Stop Voting Start Start a voting session New products DCN Next Generation

  35. Make your choice ! New products DCN Next Generation

  36. Retrieve information New products Return Mr. Sanchez Speaker DCN Next Generation

  37. Retrieve information New products Return 3 Delegates waiting to speak Requests DCN Next Generation

  38. Ideal Sound Flat panel speaker • Constant directivity at all frequencies • Superior sound coverage • Greatly reduces acoustic feedback • High-quality reproduction New products DCN Next Generation

  39. DCN Next Generation Flush Mounted Units • Design • Landscape / garden effect / organic • Constructivism of Gary O’Geary • Differentiate from competitors • Express innovation • HiQ audio • Easy to Install • Voting • Dual delegate interface New products DCN Next Generation

  40. DCN cable How to connect the Flush Mounted Range New products DCN Next Generation

  41. Dual delegate Interface DCN cable Dual Delegate Facility New products DCN Next Generation

  42. Easy click to fit • No screws visible • Couplings • Flush positioning tool New products DCN Next Generation

  43. 32-Channel Language Selector • Up/Down volume control keys • Up/Down channel select keys • 2-digit LCD with backlighting • Memory of last selected channel and volume (if enabled) • External headphone connection solder-pads and connector • External control to attenuate volume level by 18dB New products DCN Next Generation

  44. Voting units Configurations • Stand alone, only voting • Full conference facility Facilities • Voting scripts • Result window • Store results • Compare results New products DCN Next Generation

  45. System Comparison Benefits Features Structured discussion Discussion system • • • Different languages Interpretation • • • Operator control PC, touch screen • • • Video display Large-scale screens • • • Look who‘s talking Camera control • • • Voting Voting buttons • • • Access control Chip cards, PIN • • Private conversation Intercom • • Messages LCD screen delegate • New products DCN Next Generation

  46. 32-Channel Interpreter desk • 5 incoming channel pre-sets and LCD with quality indicators • A/B type outgoing channel select • Speak slowly function • Intercom call function to chairman and operator • Built-in loudspeaker with channel selector • Stylish and ergonomic layout New products DCN Next Generation

  47. 32-Channel Interpreter desk • Now two color versions available • Amber color display ● Blue color display • Light color base ● Dark grey base New products DCN Next Generation

  48. Striking, ergonomic and functional design We have consulted: • Several interpreter groups Complies with: • ISO 2603 New products DCN Next Generation

  49. Tertiary Secondary Primary Ergonomics New products DCN Next Generation

  50. Outgoing Incoming Ergonomics New products DCN Next Generation
