  1. Bridges Trusses

  2. Trusses • Before 1800 almost all bridges were made from stone arches • The expansion of the railroad, in particular the USA transcontinental railroad led to the need for the building of cheap, quick bridges made with readily available raw materials. • These were initially made from wood, but steel and iron were eventually used • But they were all of a Truss construction

  3. Trusses • Trusses are an economical method of building structures that are required to carry load over long distances • They use the tensile and compressive strength properties of steel and wood

  4. Trusses • Early Truss bridge builders learned through a process of trial and error leading to a set of Rational Design rules • One of the early successful truss designs was the Pratt Truss • Here you can see the load applied though W, with the reaction of the abutments on either side being R • Note ∑W must always=∑R and the job of the truss is to transfer the load efficiently from the bridge deck to the ground

  5. Trusses • There the truss member, the chords take the load and depending on the nature of the truss these may be in either tension or compression • This is an important concept as materials behave differently under compression or tension

  6. http://andrew.triumf.ca/andrew/popsicle-bridge/

  7. Trusses • Compression failure or buckling is a common mode of failure as when buckling begins, alignment becomes skewed and rapid failure may then occur • Buckling may be prevented by making the stick more rigid. Traditionally this is done with e use of box girders or I beams • In out case we need to make stiff laminates http://andrew.triumf.ca/andrew/popsicle-bridge

  8. Trusses • There is a near infinite number of truss variations here are the most common • The Howe • The Pratt • The Warren • Design your own • http://www.jhu.edu/virtlab/bridge/truss.htm

  9. Bridge Stress Scenarios

  10. Bridge BuildThe Challenge Your goal is to build a bridge using 120 popsicle sticks and hot glue – all supplied by Rooney. The Rules are: • Maximum of a total of 120 popsicle sticks. • You will be given a length of balsa wood that can be used for the bridge deck • I must be able to drive a 3 inch wide car across the bridge • The bridge must fit on the Rooney test rig • The bridge will be 24 inches wide. • I must be able to place a 2 inch dia. plunger through to the center of the deck to apply load. • Glue is used only for gluing purposes and not to artificially strengthen the bridge.

  11. Bridge BuildThe Challenge I would recommend you take the following steps: • Fully understand how the JHU bridge applet works • Test different designs using the model • When you are happy with your design draw a full scale plan • Use this plan as a construction guide for your build • Sort through your popsicle sticks and pick the best • Carefully build your side members • Glue can only be used for gluing – not for artificial strengthening • Assemble your bridge • THINK ABOUT THE LOAD BEING APPLIED!!!!!!

  12. Bridge BuildThe Report • Introduction • Design – your design and the reasons you made your decisions • Include copies of your work • Build - How well did it go? did you encounter any problems? • Testing - What happened to your bridge on testing • How did it fail? • How did it compare to the best? • Future - What would you do different next time?
