Air Masses

Air Masses. 4.4. Air masses & Fronts. An air mass is a large body of air of similar temperature, humidity, & air pressure. Four major types of air masses influence the weather in North America: maritime tropical, continental tropical, maritime polar, & continental polar.

yaron
Télécharger la présentation

Air Masses

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Air Masses 4.4

  2. Air masses & Fronts • An air mass is a large body of air of similar temperature, humidity, & air pressure. • Four major types of air masses influence the weather in North America: maritime tropical, continental tropical, maritime polar, & continental polar. • Tropical: warm air mass, forms in the tropics, low air pressure • Polar: cold air mass, forms in the poles, high air pressure.

  3. Air masses & Fronts • Maritime: form over oceans, can be very humid. • Continental: forms over land, can be very dry. • In the continental US, air masses are commonly moved by the prevailing westerlies (pushing air masses from west to east) & jet streams (bands of high-speed winds about 10km above Earth’s surface).

  4. Fronts-the boundary where the air masses meet. • Cold front: a fast-moving cold air mass overtakes a warm air mass. (represented by triangles) • Warm front: a warm air mass overtakes a slow-moving cold air mass. (represented by half circles) • Stationary front: cold & warm air masses meet, but neither can move the other. (represented by half circles and triangles on opposite sides of a line) • Occluded front: a warm air mass is caught between 2 cooler air masses. (represented by half circles and triangles on the same side of a line)

  5. Air Masses & Fronts • When a cold front passes through an area, colder, drier air moves in, often bringing clear skies, a shift in wind, & lower temps. • After a warm front passes through an area, the weather is likely to be humid & warm.

  6. Air Masses & Fronts • If a stationary front remains stalled over an area, it may bring many days of clouds & precipitation. • As the warm air of an occluded front cools and its water vapor condenses, the weather may turn cloudy & rain or snow may fall.

  7. http://www.fcgov.com/oem/oem-images/warm-front.jpg

  8. Air masses & Fronts • A swirling center of low pressure is a cyclone. • Cyclones & decreasing air pressure are associated with clouds, wind, & precipitation. • A swirling center of high pressure is an anticyclone. • The descending air in an anticyclone generally causes dry, clear weather.

  9. Anticyclones & Cyclones
