  1. TECHNIP CAPABILITIES IN THE CASPIANREGION Presented by Brian Roberts at “Oil and Gas of Turkmenistan” September 2003

  2. Contents: 1) The history of Technip 2) Range of services 3) Range of products and technologies 4) Summary of Caspian region projects 5) Products & technologies for Offshore Turkmenistan

  3. 1) The history of Technip: • A French company formed in 1958 by IFP with 20 people • Over last 5 years: • Acquisition of Mannesman, Aker Deepwater and Coflexip • Revenue increased from 1.8 to 4.5 Billion Euros • Workforce increased from 6,000 to 19,000 • Now largest European Oil & Gas services company

  4. 2) Technip range of services: • Engineering: feasibility, conceptual, FEED and detailed engineering services • Procurement: world-wide network based on e:systems • Construction, Installation and HUC Management • Project Management and Financial Engineering • Main engineering and project management centres: Paris, Lyon, Rome, Aberdeen, Düsseldorf, Oslo, Pori, The Hague, Houston, Rio de Janeiro, Abu Dhabi, Shanghai, New Delhi, Kuala-Lumpur, Perth

  5. 2) Technip range of services (continued): • A fleet of 15 subsea installation and construction vessels • 3 construction sites: • US Gulf Coast • Finland • Caspian DeepBlue and Nansen spar GMF - Corpus Christi Mantyluoto - Pori Zykh Baku

  6. 3) Technip range of products: Process technologies including: • Gas sweetening and sulphur recovery • NGL extraction and LNG liquification • Progressive crude distillation • Hydrogen and Synthesis gas • Gas to liquids (GTL) • Ethylene, fertilisers, pharmaceuticals Platform technologies including: • TPG 500 jack-up drilling and production • TPG 500 MFC (Multi-Field Concept) • TPG 500 jackdeck platform • Unideck floatover installation system

  7. 3) Technip range of products (continued): Floating production: • Coflexip flexible flowlines • Reeled Steel Catenary risers • Duco umbilicals • Perry Slingsby Systems ROV's and robotics • The SPAR platform • The EDP platform • Suction Embedded Plate Anchors (SEPLA) • FPSO jackdeck

  8. 4) Technip main projects in the Caspian region (last 5 yrs) Loc. Project Client Cont. Finish Az TPG 500 platform BP R+LS 2006 Tu Diesel Hydrotreater Turkmenneftegas LSTK 2005 Az Preset moorings C-T & ExxonMobil R+LS Ongoing Uz Pyrotechnic plant Uzprommashimpeks LS 2002 Uz Na & Mg Chlorate Ferghana P.O.AZOT LS 2002 Tu Lube oil plant Turkmenneftegas LSTK 2001 Tu Refinery expansion Turkmenneftegas LS 2001 Ka Ethanol unit Kazpischeprom-K. LS 1999 Ka Drill barge Sunkar Parker D./ OKIOC LS+R 1999 RF J/U Marawah imp+up Khazoil LS 1999 RF Dada Gorgud upgr. CIPCO LS+R 1998 Az Istigal drilling upgr. BP LS 1998 Tu S.Kamyschldsha FD Turkmenneftegas LSTK 1998 Ka Alcohol plant Parastatal LS 1998

  9. 5) Products / technologies for offshore Turkmenistan TPG 500 jack-up drilling and production platform: • Designed to fixed platform rules - over 30 year field life • Proven - 2 installed in N.Sea - excellent HSE performance • Self installing - no crane vessel or barge, just 3-4 tugs • Maximum onshore commissioning - no flotel • Flexible fabrication and assembly method • Low abandonment cost - re-use potential BP Harding Elf Elgin Shah Deniz platform and assembly method

  10. 5) Products / technologies for offshore Turkmenistan TPG 500 MFC (Multi-Field Concept) platform: • Jack-up drilling, production platform with integrated subsea oil storage tank • Design derived from the TPG 500 series of platforms • Re-locatable - suitable for: • early production systems for multiple fields • fields with limited local infrastructure • production of heavy or waxy crudes

  11. 5) Products / technologies for offshore Turkmenistan TPG 500 jackdeck platform: • Incorporates conventional integrated truss deck for topsides facilities • Deck fully commissioned onshore, minimum offshore HUC and rapid operation • Transport and installation using a barge • Single installation operation • Legs lowered and deck elevated using the TPG 500 jacking systems • No HLV or flotel required • Low abandonment cost - re-use potential

  12. 5) Products / technologies for offshore Turkmenistan Unideck floatover system: • 2,200-18,000 tonne decks installed • Suitable for West African long period swells using hydraulic jacks for rapid load transfer • Minimum load applied to the jacket(soft mooring lines/rubber fenders) • No HLV required • Deck fully commissioned and tested onshore • Minimum offshore hook-up

  13. Conclusions: • Technip is the largest European O&G services company with a world-wide network of facilities • Offers a wide range of engineering management, construction and installation services • Has technologies well suited to Caspian projects • Has a long established track-record of executing major projects in the Caspian region
