  1. Human Machine Interface Dedicated & Professional in HMI Quality Products State-of-the-Art Technology Satisfy Service http://www.weintek .com

  2. Customer-orientated Organization EasyView G.M / CEO Finance Administration Sales Production Dept. Resourcing Vendor Customer R&D Taipei P.M. Customer Service R&D Shenzhen

  3. History of MT Products EasyView New Generation - MT500 PLC Touch Screen HMI * 32 bits RISC CPU * Embedded system support full window operation * Innovative way to debug project - online simulation * Fastest screen refresh among all the competitors’ products * Most easy-to-use screen editor 1994 ~ MT110 - revised MT100 model 1995. 08 ~MT300- 9.4” 640x480 LCD display with touch screen HMI 1995. 11 ~Weintek Labs., Inc.established 1997. 02 ~MT200 - 320x240 LCD display with touch screen HMI 1997. 07 ~MT250 - cost-down model for MT300 1998. 10~MT510S/T - 10.4” DSTN / TFT touch screen HMI 1999. 04 ~MT506L/S - 5.7” 4-Gray / STN touch screen HMI 2000. 03 ~MT508S - 7.7” DSTN touch screen HMI New Family - MT600 Windows CE Touch Screen HMI * Intel processor * Fan-less cooling system * Built-in flash memory and Windows CE OS inside * NEMA4/IP65 compliant front panel * One Compact Flash slot * 10 Base-T Ethernet port 2002. 03 - 05 ~MT5xxV2 - upgraded to Version 2 2002. 07 ~MT5xxV3 - upgraded to Version 3 2002. 07 ~MT509LV3 - 9.4” 4-gray touch screen HMI 2002. 08 ~MT250DV2 - revised model 2003. 04 ~MT606 - 5.7” STN Windows CE touch screen HMI

  4. History of MT Products EasyView 2003. 09 ~MT608 – 7.7” STN Windows CE touch screen HMI 2004. 02 ~MT5xxV4 – upgraded to Version 4 2004. 02 ~MT5xxE4 – plugged Ethernet port doubled Flash Memory in part of the MT5xxV4 Series models 2005. 02 ~MT606CV2 – 5.7” STN Windows CE HMI 2nd Generation – MT600 Window CE Touch Screen HMI * Cirrus Logic EP9315 * 10/100 Base-T Ethernet Port * USB 2.0 * Fastest RISC Platform on the market 2005. 05 ~MT612TV2 – 12.1” TFT Windows CE HMI

  5. Products Development MT8121 MT8104 MT612 MT8080 MT610 MT8056 MT608 MT510T MT606 MT508T MT506T

  6. Weintek’s Product Family -- MT 600 Series MT608T MT606T MT610T MT612T • 10.4” 640x480 TFT LCD • 12.1" 800x600 TFT LCD • 5.6" 320x234 TFT LCD • 8.0" 640x480 TFT LCD • Fastest Speed: The fastest RISC based WinCE HMI on the market. • Microsoft OS: Built-in Windows CE 4.2/5.0 • Compatibility: Used with most of WinCE HMI software, ex. Indusoft, InstantHMI…etc. • Variety: IDE interface, USB2.0, CF slot, Hardware Graphical Acceleration. • Cost-effective: more economical solutions on the market.

  7. Distributors Poland: Czech: Greece: Krakow, Prague (Vrchlabi) Athens Katowice Serbia: Bulgaria: Turkey: Belgrade Sofia Istanbul Sweden: Hisings Backa (Gothenburg) UK: France: Italy: Surrey (London) Atyre (La Rochelle) Bologna Netherlands: Spain: Ede (Amsterdam) Barcelona Russia: Saint Petersburg Canada: Toronto South Korea: Seoul USA: Seattle (WA) Eatontown (NJ), Ann Arbor (MI) West Chester (Ohio) Beaufort (NC) N. Billerica (MA) China: Shenzhen(Weintek Branch) Shanghai (Weintek Office) Taiwan: Taipei (Weintek HQ) Hsinchu, Taichung, Tainan Venezuela: Barquisimeto Brazil: Sao Paulo (SP) Peru: Lima Argentina: Buenos Aires Chile: Santiago Singapore Malaysia: Kuala Lumpur Indonesia: Jakarta Australia: New South Wales Israel: Syria: Kfar-Saba, Petach Tikva Aleppo Egypt: Lebanon: Ramada (Al-Azm Center) Beirut Iran: Tehran Pakistan: Karachi India: Bombay, Pune

  8. Advantages of Weintek’s HMI Products • Professional — Weintek has over 10 years experience in • designing and manufacturing HMI products. • Competitive — The best cost/performance HMI products on • the market. • Reliable — Weintek produced over 200,000 units touch screen • HMI in the past 10 years. • User-friendly — Our design philosophy is to provide high • quality and easy- to-use platform, “EasyView “.

  9. Yearly Sales Comparison (in unit) Quantity( unit) (+45.72%) (+68.05%) (+44.73%) (-4.15%) forecast Year

  10. Yearly Sales Turnovers Amount (Thousand in USD) (31%) (45%) (40%) (-9%) (72%) (66%) (20%) (74%) (65%) (86%) (200%) forecast Year

  11. ISO 9001:2000 Certificate EasyView In July 2004, Weintek Labs., Inc. has been assessed and certified by SGS United Kingdom Ltd. as meeting the requirements of ISO 9001:2000 for the activities of designing and manufacturing of touch panel screen. Weintek's strong commitment to our customers and producing quality products are evident in our ISO 9001 Certification. Working under ISO 9001 Certification Standards, we assure our customers and prospective customers of the highest quality products available.

  12. UL Certificate EasyView

  13. CE Certificate EasyView

  14. Burn-in Test EasyView All of the units have experienced 50°C / 8 hours test at online operation condition.

  15. Vibration Test EasyView Selected units should pass vibration test of 25Hz 2G (X, Y, Z direction) in 30 minutes duration.

  16. Fast Transient Burst Test EasyView The test is intended to prove the immunity of MT touch screen against transient interference caused by a switching transient (interruption of inductive load, balance of relay contact, etc.) All of the MT touch screens are designed to endure 4KV tran-sient burst at 5kHz frequency.

  17. Highly Accelerated Stress Test EasyView To make sure that touch panel and LCD module supplied by the third party are able to endure industry harsh environment, sample of the touch panel and LCD module has to pass highly accelerated stress test.
