Understanding the Global Positioning System (GPS): Structure, Function, and Accuracy

The Global Positioning System (GPS) is a satellite-based navigation system, operated by the Department of Defense, consisting of three main segments: the Space Segment, Control Segment, and User Segment. With around 30 NAVSTAR satellites in orbit, GPS operates by receiving signals to calculate precise locations. Accuracy can be affected by various factors including clock errors, atmospheric conditions, and multipath errors. Differential GPS is an enhancement technique that reduces errors significantly. Understanding terms like Circular Error Probable (CEP) and Geometric Dilution of Precision (GDOP) is vital for GPS accuracy analysis.
