Atomic Theory

Atomic Theory. Let’s Take a Trip Through Time!. Atomic Theories Timeline. Democritus 460 – 370 B.C. There are various basic elements from which all matter is made Everything is composed of small atoms moving in a void

zuri
Télécharger la présentation

Atomic Theory

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Atomic Theory

  2. Let’s Take a Trip Through Time!

  3. Atomic Theories Timeline

  4. Democritus460 – 370 B.C. • There are various basic elements from which all matter is made • Everything is composed of small atoms moving in a void • Some atoms are round, pointy, oily, have hooks, etc. to account for their properties • Ideas rejected by leading philosophers because void = no existence

  5. First Concept of an Atom

  6. John Dalton1766-1844 • Introduced his ideas in 1803 • Each element is composed of extremely small particles called atoms • All the atoms of a given elementare identical, but they differ from those of any other element • Atoms are neither created nor destroyedin any chemical reaction • A given compound always has the same relative numbers and kinds of atoms

  7. Dalton’s Model

  8. J.J. Thompson1856-1940 • Discovered electron 1897 – Cathode Ray Experiment • Plum Pudding model 1904 • Electrons in a soupof positive charges • Discovered isotopes 1913

  9. JJ Thompson’s Ideas

  10. Cathode Ray Tube Experiment

  11. Plum Pudding Model

  12. Ernest Rutherford1871-1937 • Nucleus Theory 1910 • alpha particle gold foil experiment • An atom’s mass is mostly in the nucleus • The nucleus has a positive charge (Moseley) • Electrons in fixed orbit

  13. Alpha Particle Experiment

  14. Rutherford Model

  15. Niels Bohr1885-1962 • Planetary Model 1913 • Nucleus surrounded by orbiting electrons at different energy levels • Electrons have definite orbits • Utilized Planck’s Quantum Energy theory • Worked on the Manhattan Project (US atomic bomb)

  16. Bohr’s Model

  17. Bohr Model for Nitrogen

  18. Ernst Schrödinger 1887-1961 Werner Heisenberg 1901-1976 • Quantum Mechanical Model 1926 • Electrons are in probability zones called “orbitals”, not orbits and the location cannot be pinpointed • Electrons are particles and waves at the same time • Developed quantum numbers based on theories of Einstein and Planck

  19. Orbitals

  20. Quantum Mechanical TheoryElectron in a Hydrogen atom

  21. James Chadwick • In 1932 the physicist James Chadwick in England performed a series of experiments and suggested that in fact the new radiation consisted of uncharged particles and he performed a series of experiments verifying this. These uncharged particles were called neutrons

  22. Proton, Electron, Neutron • So…. Recap, who discovered the proton, electron, and neutron?? • The electron was originally discovered by J.J. Thomson when he realized there were negatively through the cathode ray experiment. • The proton is credited to Ernest Rutherford with his gold foil experiment, noticing the alpha particles were being deflected all over. • Lastly, the neutron was discovered by James Chadwick after realizing there was more to the atom than just positively charged particles inside and negatively charged particles orbiting around the outside.

  23. James Chadwick 1932
