  1. W KX-TD500 Ver.2-4 Telecom Division Kyushu Matsushita Electric CO., LTD. 210831-1

  2. New Features of TD500 Ver.2-4 1- Incoming Group - ISDN-CO call destination to “DIL1:N” - Delayed ringing for DDI call. - Group Log-in / Log-out. - FWD from Incoming Group - Overflow to the VPS (With Follow-on ID) 2- Extension basis IRNA destination setting 3- Call Forwarding to CO - No answer. 4- Caller ID - Caller ID (Both FSK/DTMF) 5- DECT System Connection TD1232 via BRI 6- Lunch and Break Mode “

  3. Others Features(1/2) 1- Automatic changing summer time function 2- DSS console key setting (DAY/NIGHT, VTR) 3- A verified all account code can be input 4- Secret busy over ride function is supported 5- Operator can change a DISA pass-word 6- Set the voice mail quick setup function, by an assigned the tenant based 7- Three progress tone mode for an internal ISDN 8- Call queuing of DDI/DID incoming call 9- Continuous check-in/out operation “

  4. Others Features(2/2) 10- A different toll restriction function for a TIE call. 11- Select condition to release condition the ISDN line when the disconnecting signal is received. 12- Selectable operation for the timeout of ARS inter digit(Local Access/Disconnect) 13 - All Log out - All-logout function by manual operation - Selectable All Logout feature Enable or not 14- System speed dial Import from CSV file 15- Recall information displays to operator Ext. 16- Outputting the dial of arriving ISDN call “

  5. NEW Incoming Group (1/7) Ver.2-1,2,3 Extension Group - Terminate - Ring - Operator - UCD - DIL1:N (Only for Analog Line) Ver.2-4 Extension Group - Terminate - Ring - Operator - UCD replaced - Incoming Group 1- Terminate 2- Ring 3- Operator 4- UCD 5- DIL 1:N (Also ISDN Line:DDI) “

  6. “ DIL 1:N Terminate Ring Operator UCD        OVF Destination    OVF Timer Mail Box No.      FWD/DND Mode    Search Mode Calls to Empty Group Operator Setting UCD Setting NEW Incoming Group (2/7) Programming items on each group.

  7. NEW Incoming Group (3/7) • Max. 96 Incoming Groups are available. • Incoming Group has a floating number (FDN). • Max. 72 Extension or Extension Group are assigned in one Incoming Group. • One DN can belong (LOG-in) to Max. 8 Incoming Groups at the same time. • Delayed ringing for ISDN DDI calls. • We can LOG-in/LOG-out to/from Incoming Group. • We can assign the voice mail box number for each Incoming Group. • We can use the FWD function in Incoming Group. “

  8. NEW Incoming Group (4/7) Distribution of Call <Example Programming > 1- EXT1000 belongs to EXT Group 1(Operator:2000). 2- EXT Group 1 belongs to Incoming Group 1(DIL1:N:3000). 3- EXT1000 belongs to Incoming Group 2(UCD:4000). Operation 1- Dial 1000 from another EXT/CO line. -> The call arrives at EXT1000 directory. 2- Dial 2000 or 0 from another EXT/CO line. -> The call arrives at EXT1000 as a Operator call. 3- Dial 3000 from another EXT/CO line. -> The call arrives at EXT1000 as a DIL 1:N call. 4- Dial 4000 from another EXT/CO line. -> The call arrives at EXT 1000 as a UCD Group call. “

  9. “ NEW Incoming Group (5/7) It is possible to assign a FDN of DIL 1:N as an ISDN line destination. The delayed ring function is available too.

  10. Disable to assign FWD by EXT. Enable to assign FWD by EXT. of own Group Enable to assign FWD by EXT. of Any Group NEW Incoming Group (6/7) Enable to assign the FWD function in Incoming Group. [741] + [1] + [source Incoming group] + [destination] It is possible to monitor with G-FWD key (R-ON/R-OFF:use/ unused). “

  11. FWD FWD Incom. G 2 Incom. G 1 IRNA Pre-assigned Mail box No. NEW Incoming Group (7/7) Summary FDN 3000 DIL 1:N FDN 4000 UCD DN 1000 DN 1001 “

  12. Trunk Group Incoming Call IRNA No2 IRNA No1 Extension basis IRNA destination 1/2 • It is possible to program an IRNA destination for each Ext., If IRNA destination for Ext. and IRNA destination for CO are assigned at the same time, the destination for Ext. is first priority. • As for the DIL1:N, it arrives several Extensions, the terminating call arrives to the IRNA destination of Trunk Group. “

  13. Extension basis IRNA destination 2/2 Following table shows the combination of IRNA destination and Incoming type. “

  14. Improved FWD/NA to CO Function to forward the incoming call to CO line automatically, if there is no answer the incoming call. To set: 710 + * + Line access number + Outside phone Number + #. To cancel: 710 + 0 “

  15. Caller-ID (Both FSK/DTMF) (1/2) Function to receive Caller ID transmitted for the incoming call from analog CO line. < Analog Caller ID standard > There are two kinds of method of received Caller ID. 1. FSK method (1) FSK-Bellcore standard (TR-NWT-000030) (2) FSK-ETSI standard (ETS300659-1) (3) Format of the data of FSK method Single message format, Multi message format 2. DTMF method (1) DTMF-ETSI standard (ETS300659-1 Annex ) “

  16. Caller-ID (Both FSK/DTMF) (2/2) TD193DX:from Version 1 TD193X:from Version 0 TD193DX:from Version 1 CO Port number This is different by the country. “

  17. DECT System Connection (1/2) Improved Ext. 100 TD50288 Internal ISDN TD280 TD286 Network C-TRN Ext. 100 (TD500 Ext. 1000) Ext. 101 It is possible to connect KX-TD816/1232 DECT System via ISDN-BRI. ISDN-BRI can accept the KME proprietary call transfer sequence, it is possible to transfer the call, without occupying the ISDN Line. “

  18. DECT System Connection (2/2) Only CO ISDN Only CO ISDN • This function operates only when the network type of the ISDN card is set to “Centrex”. • This setting is done on a card unit base, so the remaining CO ISDN port is not able to use it for CO. “

  19. NEW Lunch and Break Mode The Lunch and Break Mode is supported. “

  20. Automatic changing summer time The time of PBX is automatically corrected the time change by time of summer. Start Date (1 hour forward) :YY/MM/DD End Date (1 hour back) :YY/MM/DD The correction is executed at 2 AM of the above mentioned, setting dates. “

  21. DSS/PF Key setting It is possible to assign a Day/Night key onto a DDS key and a VTR (Voice Mail Transfer) key on to a PF key. “

  22. Improved VM Auto Configuration Mode The mail box of the extension can be automatically generated with voice mail by the following options. 1. Create mailboxes only for the tenant which has VM ports 2. Create mailboxes of all tenants “

  23. Disconnecting the Caller by VPS After Transferred Extension answered the call from VPS, caller is disconnect when Transferred Extension disconnects immediately (before the transferring operation of VM is completed). “

  24. Improved ISDN progress tone mode Three kinds ISDN tone can be selected. 1- Mode to listen to the tone according to instruction from network (Mode 1:Automatic) 2- Mode to listen to the tone from network (Mode 2: Network) 3- Mode to listen to the tone from PBX (Mode 3:PBX) “

  25. Improved Conversation (New) Consultation hold Selectable to release ISDN line It can be selected whether to release the line when the disconnecting signal is received from the ISDN line during the conversation. “

  26. Outputting the dial of arriving ISDN call • It is SMDR output function of the dial of the ISDN line during arriving the call. “

  27. “ Improved Selectable of All Logout It can be set whether to use All Log out. It is effective to both Extension group/Incoming group.

  28. Improved Call queuing for All Logout Group Allows for calls to empty (all Logout) Operator or UCD Groups to be queued. If disabled, the extension will receive Reorder Tone, and the CO call will be transferred to the overflow destination immediately. “

  29. Improved Ver. 2-4 PC Programming software We can use Win2000/NT for PC programming “

  30. Improved Secret busy override It is possible to monitor the call without notice, when you interrupt the telephone call. The caller interrupts while the conversation, and goes to the three party conference. However, Extension interrupted connects only the receiving path. “

  31. Call transfer to TIE line As for the transferring to TIE, it is possible to restrict by each COS. TIE ling goes free when transferring is restricted, and the key of consultation Hold becomes the indication of recall. “

  32. Inputting the Account code of Verified All Call It is possible to enter the account code both after CPC is detected and during the conversation to CO line. (It is the same as the Option mode) “

  33. DISA Password can be changed by the Operator It is possible to change the DISA Password from the PITS of Operator by PITS System Program(010). “

  34. Improved Call queuing of DDI/DID Call Specifies the treatment of DDI/DID callers when they dial a busy extension. 1. Send busy tone (Default) 2.Transferred to IRNA destination. 3.Wait till the destination becomes idle. “

  35. Continuous Check-In operation Y/NEXT(S2) is added Y/NEXT(S2) is added Check- In Check- Out “

  36. Improved Timeout of ARS inter digit Specifies the outgoing operation mode when the inter-digit timer (15 sec) expires while making an outgoing call with ARS. It only works when use the ARS from Extension, it does not work when use the ARS by the way of DISA/TIE. “

  37. NEW System Speed Dial Import 1- The data format of System speed dial is CSV. Excel file  (Converts)  CSV file  TD500 2- The data can be up-loaded to PBX by PC programming. 3- Down-loading from PBX is unable. 4- Up-loading is possible only when the PC operates in the interactive mode. “

  38. Recall Display to the Operator The LCD displays as follows, when Transfer Recall comes by Unscreened transfer and Camp-On transfer. 1- Assigned the Extension name RCL:Tony Viola 2- Not assign the Extension name RCL:Ext 101 “
