DNA Fingerprinting Preparing Agarose Gels for Use with Carolina Blu

Lucy avatar
Lucy
15 diapositives · 596 Views · Oct 15, 2011

Agarose Gel Prep Step 1 . Remove the lid from the electrophoresis box, face the box with the electrode plugs pointing to the back, and place fingers on each end of the unit while pressing thumbs against the front edge of the lid.Push thumbs against the lid toward the rear to disconnect the power supply leads from the plugs. Lift lid to remove from system..

#agarose gel electrophoresis #southern blot #set #genetic engineering #genetic fingerprinting #alec jeffreys #preparation #gene-splicing
DNA Fingerprinting Preparing Agarose Gels for Use with Carolina Blu - slide 1
01 / 15DNA Fingerprinting Preparing Agarose Gels for Use with Carolina Blu
1 / 17

Télécharger la présentation

DNA Fingerprinting Preparing Agarose Gels for Use with Carolina Blu
Une image / un lien ci-dessous est fourni (tel quel) pour télécharger la présentation

Politique de téléchargement : le contenu du site vous est fourni TEL QUEL pour votre information et votre usage personnel ; il ne peut être vendu, concédé sous licence ni partagé sur d’autres sites sans l’accord de son auteur.Le contenu vous est fourni TEL QUEL, pour votre information et votre usage personnel uniquement. Téléchargez la présentation en cliquant sur ce lien. Lors du téléchargement, si vous ne parvenez pas à télécharger une présentation, l’éditeur a peut-être supprimé le fichier de son serveur.Pendant le téléchargement, si vous ne parvenez pas à obtenir une présentation, le fichier a peut-être été supprimé par l’éditeur.

F I N

Plus de contenu associé

Transcription de la présentation

    2. Agarose Gel Prep Step 1 Remove the lid from the electrophoresis box, face the box with the electrode plugs pointing to the back, and place fingers on each end of the unit while pressing thumbs against the front edge of the lid. Push thumbs against the lid toward the rear to disconnect the power supply leads from the plugs. Lift lid to remove from system.

    3. Agarose Gel Prep Step 2 Remove the gel tray by grasping each side and lifting at an angle to ease the tray out of the system. Rinse the combs, gel tray, and gel box in distilled water to remove any residue.

    4. Agarose Gel Prep Step 3 Replace the gel tray in the system by carefully lowering the tray at an angle so the gaskets fit against the front and rear of the gel box wall.

    5. Agarose Gel Prep Step 4 If the gasket has slipped out of the groove, push it back into place before lowering the tray into the box.

    6. Agarose Gel Prep Step 5 Prepare 700 ml of 1X TBE electrophoresis buffer. Measure 70 ml of 10X TBE stock solution in a 100 ml graduated cylinder.

    7. Agarose Gel Prep Step 6 Add the 70 ml of 10X TBE to 630 ml of distilled water.

    8. Agarose Gel Prep Step 7 Pour into a 250 ml flask or beaker 45 ml of 1X TBE electrophoresis buffer prepared in steps 5 and 6.

    9. Agarose Gel Prep Step 8 Add 0.7 g of agarose to the 1X TBE and swirl to disperse the powder.

    10. Agarose Gel Prep Step 9 Microwave the suspension until it boils (about 30 seconds to 1 minute). Swirl the flask and alternate boiling and swirling at 15 second intervals until the solution has boiled a total of 1 minute or until there are no visible solids.

    11. Agarose Gel Prep Step 10 Cool the agarose solution by adding 45 ml of the 1X TBE buffer, bringing the volume in the container to 90 ml. Swirl the solution gently to avoid trapping air bubbles.

    12. Agarose Gel Prep Step 11 Add 144 µl of Carolina Blu Gel Stain to the agarose solution. The Gel Stain will be provided to Iowa teachers by the ISU Office of Biotechnology.

    13. Agarose Gel Prep Step 12 Place a comb(s) of choice into the tray slot. Slowly pour the agarose solution into the gel tray, taking care not to allow formation of any bubbles within the gel.

    14. Agarose Gel Prep Step 13 Allow the gel to sit at room temperature for about 30 minutes until solid (gel will appear slightly milky).

    15. Agarose Gel Prep Step 14 Prepare the running buffer by adding 732 µl of Carolina Blu Buffer Stain to the 610 ml of 1X TBE buffer that remained after making the agarose gel.
