1. Network Security Professor Dr. AdeelAkram

2. Firewalls: A Practical Guide

3. Outline • ICSA Labs • ICSA Certified Firewalls • KerioWinroute Firewall • Astaro Security Gateway • WatchGuard X1000 Firewall • CASE Study • KerioWinroute Firewall 6

4. About ICSA Labs • For over a decade, ICSA Labs, an independent division of Cybertrust, Inc., has been the security industry's central authority for research, intelligence, and certification testing of products. • ICSA Labs sets standards for information security products and certifies over 95% of the installed base of anti-virus, firewall, IPSec VPN, cryptography, SSL VPN, network IPS, anti-spyware and PC firewall products commonly deployed in the world today.

5. ICSA Labs Certification • ICSA Labs, formerly known as the International Computer Security Association, manages and sponsors security consortia that provide a forum for intelligence sharing among the leading vendors of security products. • In addition, ICSA Labs publishes surveys, security industry studies and buyers' guides for computer security products

6. ICSA Labs Certification • The goal for ICSA Labs Certification is to enhance and improve security implementations of network and Internet computing, which will improve commercial security and its use of appropriate security products, services, policies, techniques, and procedures. • Certification enforces overall confidence in computing and drives enhanced security measures while at the same time, decreasing the intrusion of security measures in everyday life. • Certification also promotes user acceptance of increased security while improving the ease of use, and the invisible, automatic, and seamless integration of security technology in everyday computing.

7. ICSA Labs Test Areas • Anti-Spyware • Antivirus • Cryptography • FIPS 140-2 Cryptographic Module Testing • Firewalls • Intrusion Detection • IPsec • Network Intrusion Prevention • PC Firewalls • PIV / FIPS 201 • Premier Services • SSL-TLS • Wireless

8. Prominent ICSA Certified Firewalls • KerioWinroute Firewall for Windows • Astaro Security Linux • WatchGuard Firebox System Family • Juniper NetworksNetScreen Firewall Family • Microsoft Internet Security and Acceleration Server • CISCO PIX Firewall Family • Check PointSecurePlatform NG • NovellBorderManager

9. KERIO Winroute Firewall • Corporate & enterprise network firewall: • Kerio WinRoute Firewall™ is a corporate gateway firewall for small and medium-sized businesses. • Equipped with VPN server, optional embedded McAfee Anti-Virus, integrated customizable ISS Orange Web Filter, and user-specific Internet access management, Kerio WinRoute Firewall provides a multi-layer architecture for protecting networks, servers and users. • http://www.kerio.com

10. ASTARO Security Gateway • http://www.astaro.com • https://demo.astaro.com Astaro AppliancesAstaro SoftwareAstaro Report ManagerConfiguration ManagerAstaro Secure Client

11. WATCHGUARD Firebox Family • Firebox Soho • Firebox Edge • Firebox Core • Firebox Peak } X-Series

12. CASE STUDY: KWF 6 • Kerio Winroute Firewall • Comes as an installer package • ~ 22 MB (kerio-kwf-6.2.0-1382-win.exe) • Installs on all current versions of Windows

13. KWF6: Installation • System Requirements • • CPU Intel Pentium II or compatible; 300 MHz • • 128 MB RAM • • 2 network interfaces • • 50 MB disc space free for the installation • • Free memory for logs (depends on traffic load and selected logging level) • The product supports for the following operating systems: • • Windows 2000 • • Windows XP • • Windows Server 2003 • Note: The Client for Microsoft Networks component must be installed for all supported operating systems, otherwise WinRoute will not be available as a service and NTML authentication will not function. The component is included in installation packages of all supported operating systems.

14. Installation and Basic Configuration • Launch the installation program • kerio-kwf-6.2.0-1382-win.exe

15. Select Components

16. WinRoute Firewall Engine — core of the application • WinRoute Engine Monitor — utility for WinRoute Firewall Engine control and monitoring • its status (icon in the system’s notification area) • VPN Support — proprietary VPN solution developed by Kerio Technologies, • Kerio Administration Console — the Kerio Administration Console application (universal console for all server applications of Kerio Technologies)

17. Restart the machine when the installation has completed. This will install the WinRoute low-level driver into the system kernel. • WinRoute Engine will be automatically launched after restart. • The engine runs as a service. • The WinRoute Engine Monitor will be launched after a user login. This utility monitors the Engine status and is used to start or stop the engine. • WinRoute Engine Monitor icon is displayed in the system’s notification area (system tray).

18. Conflicting System Services • Internet Connection Sharing and Internet Connection Firewall • Universal Plug and Play Device Host and SSDP Discovery Service

20. Admin Console Settings

21. Remote Access to Admin Console

22. Restart After Install • Engine Monitor: • Appears as system tray icon • Right Clicking shows context Menu

23. First Start Setup

24. Configuration Wizard

26. Internet thru Ethernet

27. Internet thru Dialup

28. Allowed Internet Services to Clients

29. Local Services Publishing

32. Enable NAT

33. Lets go to the Actual Process • Kerio Installed on Lab PCs

34. References • http://download.kerio.com/archive/ Select Kerio Control (Firewall Software / Appliance) • http://www.astaro.com/products • http://www.astaro.com/support/downloads • https://support.astaro.com/support/index.php/Main_Page • http://www.watchguard.com/products/compare.asp • https://www.icsalabs.com

35. Kerio Control Packages

36. Kerio Control Documentation

37. Questions ?????????????????????????????????? adeel.akram@gmail.com
