  1. Linear Motion

  2. Relative Motion • Motion is relative • An object’s motion is always described in reference to another object

  3. Relative Motion • When an object is said to be traveling at 60 km/h (or at any speed), it is implied that it is moving at 60 km/h relative to the Earth.

  4. Relative Motion Jamiroquai “Virtual Insanity” Travelling Without Moving 1997 Video of the Year CLICK HERE TO WATCH THE VIDEO!

  5. Vectors and Scalars Vector- a quantity possessing both magnitude and direction Scalar- a quantity possessing only magnitude

  6. Vectors and Scalars Examples of Vectors: • Displacement (Δx) • Velocity (v) • Acceleration (a) • Force (F) • Momentum (p)

  7. Vectors and Scalars Examples of Scalars: • Distance (d) • Mass (m) • Speed (v) • Time (t)

  8. Speed Instantaneous speed: the speed that something has at any one instance Average speed: the speed of an object over a time interval

  9. Speed The average speed for a trip might be 53 miles/hour. However, during this trip your instantaneous speed might have been 0 miles/hour at a stoplight... ...or 70 miles/hour on the open road.

  10. Speed What are the units of speed? • miles/hour…………….mph • kilometer/hour……….km/h • meters/second……….m/s • furlongs/fortnight?

  11. Speed • 1. What is the average speed of a cheetah that sprints 100 meters in 4 seconds? • 2. How about if it sprints 50 m in 2 s?

  12. Velocity Velocity = {speed with a direction} Examples: 70 mph is a speed. 70 mph North is a velocity.

  13. Velocity What are the units of velocity? Velocity has the same units as speed except they also have a direction

  14. Velocity and speed equations

  15. Velocity vs. speed • The speedometer of a car moving to the east reads 100km/h. It passes another car that moves to the west at 100km/h. • Do both cars have the same speed? • Do they have the same velocity?

  16. Conceptual Review • In an unusual move by the New York State Department of Transportation, all of the "speed limit" signs were replaced with "velocity limit" signs. • What would such a sign look like? • How could one travel faster than the old speed limit without violating the new velocity limit?

  17. Conceptual Review • Which device(s) on a car can be used to change … • its speed? • its velocity but not its speed?

  18. Conceptual Review • A car driving on a circular test track shows a constant speedometer reading of 100 kph for one lap. • Describe the car's speed during this time. • Describe its velocity. • How do the speed and velocity compare?

  19. Conceptual Review • Is it possible for an object to have … • constant speed and changing velocity, • changing speed and constant velocity?

  20. Conceptual Review • Why are the devices in cars called speedometers and not velocitometers?

  21. Relative Motion…one more time OK Go “Here It Goes Again” Oh No 2007 Grammy award for "Best Short-Form Music Video” CLICK HERE TO WATCH THE VIDEO

  22. Acceleration Acceleration is the rate of change of velocity.

  23. Acceleration What are the units of acceleration? • miles/hour/second…………….mi/h/s • kilometer/hour/second……….km/h/s • meters/second/second……….m/s/s or m/s2

  24. Acceleration equations

  25. Acceleration Acceleration is the positive or negative depending on the direction of the acceleration.

  26. Acceleration An object traveling with a constant positive velocity

  27. Acceleration An object traveling with a constant negative velocity

  28. Acceleration An object traveling with a positive velocity, positive acceleration.

  29. Acceleration An object traveling with a positive velocity, negative acceleration.

  30. Acceleration An object traveling with a negative velocity, negative acceleration.

  31. Acceleration An object traveling with a negative velocity, positive acceleration.

  32. Graphs of Motion On a displacement vs. time graph the slope of the line is equal to the velocity of the object. On a velocity vs. time graph the slope of the line is equal to the acceleration of the object. On a velocity vs. time graph the area underneath the curve is equal to the displacement of the object.
