LINEAR MOTION

Review. LINEAR MOTION. What is it called when the speed of an objects changes?. ACCELERATION. What’s the difference between speed and velocity?. Speed is how fast an object moves and velocity is speed in a given direction. What is the speed of a car that traveled 125 miles in 2 hours?

darin
Télécharger la présentation

LINEAR MOTION

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Review LINEAR MOTION

  2. What is it called when the speed of an objects changes?

  3. ACCELERATION

  4. What’s the difference between speed and velocity?

  5. Speed is how fast an object moves and velocity is speed in a given direction.

  6. What is the speed of a car that traveled 125 miles in 2 hours? • Hint: Make sure you include units! • Do NOT ROUND!

  7. d = 125 miles • t = 2 hours • v = ? • v = d/t • v = 125 miles/2 hours • v = 62.5 mi/hr OR 62.5 mph

  8. How much time does it take for a bird flying at a speed of 45 mph to travel a distance of 1800 miles? • Hint: Calculate time in minutes

  9. v = 45 mi/hr • d = 1800 miles • t = ? • V = d/t • t = d/v • t = 1800 miles/45 mph • t = 40 hours • t = 40 hr *(60min/1 hr) = 2400 min

  10. What is the acceleration due to gravity = to?

  11. g = 9.8 m/s2 ≈ 10 m/s2

  12. _______________ speed is speed at any moment. • Hint: The speedometer in a car measures this.

  13. INSTANTANEOUS

  14. A car accelerates from 25 km/hr to 55 km/hr in 30 minutes. What is its acceleration? • Hint: Make sure your units are km/hr2

  15. vi = 25 km/hr • vf = 55 km/hr • t = 30 min • a = ? • a = (vf – vi)/t • a = (55 -25)/0.5 hr • a = 60 km/hr2

  16. Is the velocity of this object constant or changing? What is the velocity? s

  17. Constant Velocity • Slope = rise/run =Δy/Δx • Slope = dist/time • Slope = (50-0)/(5-0) • Slope = 10 m/s

  18. What do we mean when we say motion is relative?

  19. It is measured with respect to something

  20. A train is accelerating at a rate of 2 m/s2. If its initial velocity is 20 m/s, what is its velocity after 30 seconds?

  21. a = 2 m/s2 • vi = 20 m/s • t = 30 sec • vf = ? • a = (vf – vi)/t • 2 = (vf – 20)/30 • 30*2 = vf – 20 • 60 = vf – 20 • 80 m/s = vf

  22. What is the motion of this object?

  23. Object is NOT moving or it is at rest.

  24. Is acceleration occurring according to this graph?

  25. Yes the speed is increasing at the same rate; this is why it’s linear.

  26. True or False. • On the Moon, ALL objects accelerate at the same rate.

  27. TRUE. No air exists on the moon, therefore there is no resistance pushing against the force of gravity.

  28. Draw the path of an object being thrown up and coming back down (free fall). Show what happens to speed when: • It’s going up • At the top • Coming back down

  29. Suppose that a ball is dropped from a tower 70.0m high. How far will it have fallen after 1.00 s, 2.00 s, and 3.00 s? Neglect air resistance.

  30. g = 10 m/s2 • t = 1 s, 2 s, 3 s • d = ½ *g*t2 • d = ½ * 10 m/s2* (1 s)2 • d = 5 m/s2 * 1 s2 • d = 5 m • d = ½ * 10 m/s2* (2 s)2 • d = 5 m/s2 * 4 s2 • d = 20 m • d = ½ * 10 m/s2* (3 s)2 • d = 5 m/s2 * 9 s2 • d = 45 m

  31. Suppose an object is thrown downward with an initial velocity of 3.0 m/s, instead of being dropped. What would its speed be after 1.0 s and 2.0 s? • Hint: Use vf = vi + a*t

  32. vi = 3 m/s • t = 1 s, 2 s • g = 10 m/s2 • vf = ? • vf = vi + a * t • vf = 3 m/s + (10m/s2 * 1 s) • vf = 3 m/s + 10 m/s • vf= 13 m/s • vf= 3 m/s + (10m/s2 * 2 s) • vf = 3 m/s + 20 m/s • vf = 23 m/s
