1. Water King Inc. Delivering Experience, Quality, and Service Since 1934. PRODUCT OVERVIEW

2. Water King – About Us Water King water treatment equipment can be designed and manufactured to meet virtually any water treatment need from residential through commercial/industrial or municipal applications.Softening, dealkalization, reverse osmosis, and multimedia filtration processes, at varying capacities, can be manufactured to meet the needs and specifications of our customers.

3. Products and Services • Water Softeners • Water Filters • Valves • Reverse Osmosis • Ultraviolet Purification • Brine Systems • Control Systems

4. Water Softener Series • RF Series • MF Series • MF FG Series • VN Softeners • BF Light Commercial Series • Custom Systems

5. RF Series Softeners • Models: 50 to 750 • Pipe Size: 1 ½” • Resin Volume: 1 ½ ft3 to 25 ft3 • Continuous Flow Rate: 15 to 63 gpm • Peak Flow Rate: 23 gpm to 82 gpm • Task Master III 1-½” Valves • Top-Mount Tank Adapters • ERCt Electronic Timers • Polyglass Mineral Tanks • Twin Configurations Available

6. MF Series Softeners • Models: 150 to 1200 • Pipe Size: 1 ½”, 3”, 4” • Resin Volume: 5 ft3 to 40 ft3 • Continuous Flow Rate: 49 to 400 gpm • Peak Flow Rate: 65 to 600 gpm • Task Master III 1 ½” Valves • Side-Mount Tank Adapters • ERC-T Electronic Timers • Epoxy-Lined & Coated Carbon Steel Mineral Tanks • Simplex, Twin, Triplex, and Quad Configurations Available

7. MF FG Series Softeners • Models: 150 to 1200 • Pipe Size: 1 ½”, 3”, 4” • Resin Volume: 5 ft3 to 40 ft3 • Continuous Flow Rate: 49 to 274 gpm • Peak Flow Rate: 65 to 364 gpm • Task Master III 1 ½” Valves • Side-Mount Tank Adapters • ERC-T Electronic Timers • Fiberglass Mineral Tanks • Simplex, Twin, Triplex, and Quad Configurations Available

8. VN Series Softeners • Models: 150 to 9000 • Pipe Size: Customer Preference • Resin Volume: 5 ft3 to 280 ft3 • Continuous Flow Rate: 50 to 960 gpm • Peak Flow Rate: 69 to 1260 gpm • DM and DMB Series Diaphragm Valves • Epoxy-Lined & Coated Carbon Steel Mineral Tanks • Twin configurations available

9. BF Light CommercialSeries Softeners • Models: 30 to 70 • Pipe Size: 3/4”, 1”, 1-1/2” • Resin Volume: 1 ft3 to 2-1/4 ft3 • Continuous Flow Rate: 10 to 23 gpm • Peak Flow Rate: 15 to 34 gpm • Performa Top Mount Valve • Fiberglass Mineral Tanks • Polyethylene Brine Tanks • Twin configurations available

10. Softening Resin Packs

11. Water Filters • FRF Series • FMF Series • FMF FG Series • FVN Series • FBF Light Commercial Series

12. Filter Types

13. Valves • Taskmaster III Valve • Brass Valve Upgrade Packages • BF Performa Valve • DM Series – Metal Diaphragm Valve • DMB Metal Diaphragm Valve • Shut-Off Kits

14. Task Master III Valve • 316 Stainless Steel Body and Piston • Five Cycles • All Electronic and Programmable • LCD Display • NEMA4 Enclosure Rating • Top or Side Mounted • Manufactured entirely by Water King • Temperature rating is 180°F • Operating Pressure of 125 psi • 71 gpm backwash rate

15. TM-III Production Line • Start-to-Finish construction of Taskmaster III Valve on site • Full testing of all pressurized castings and seals on completed valves • Full testing on all electrical components and connections • Serialization of each valve to enhance quality control efforts • Large inventory of spare and replacement parts on hand

16. Brass Valve Upgrades • Water King has discontinued the Task Master and Task Master II valve lines. • We offer conversion kits to upgrade to the new Task Master III SS Valve.

17. BF Performa Valve • Simplex or Twin Models • Fully electronic • ¾” or 1” Connection • Internal Backwash • Internal Turbine Flow Meter • PVC, Copper, or Stainless Steel Adapters Available • Bypass Kits Available

18. DM Series Diaphragm Valve • Y-Pattern Valves • Sizes from ¾” to 3” FNPT • Sizes from 3” to 6” Flanged • Stainless Steel and Brass internal components • Buna on Nylon Seals

19. DMB Series Diaphragm Valve • Globe Pattern Valves • Sizes from ¾” to 3” FNPT • Sizes from 2” to 16” Flanged • Sizes 2” to 6” Grooved • Up to 230 psi Pressure • Rubber diaphragm with Stainless Steel Spring • Works well at low pressures

20. Shut-Off Kits • Required for Twin Alternating Units • Wired into the Task Master III Valve Directly • Controls regeneration of units for twin configured systems • Available in individual kits • Pre-Installed and wired on skid mounted systems

21. Reverse Osmosis • Wide Range of Sizes and Applications • Sized for Residential, Commercial, or Industrial use • Custom-Engineered Systems Available

22. Ultraviolet Purification • Ster-L-Ray Germicidal Lamps • Non-chemical disinfection • Sizes range from 1 GPM to 450 GPM • 316 Stainless Steel Body • Pre-Installed on skid-mounted systems

23. Brine Systems

24. Control Systems • ERC Controller for TM-III • ERC VN Controls • Stagers

25. ERC Controller for TM-III

26. ERC VN Controls

27. ERCOne Control for All System Types BF SERIES RF SERIES MF SERIES VN SERIES

28. Flow Meters

29. WaterKing.com • Price Lists– List prices for all standard Water King systems and parts are provided. • Drawings – Most standard WKI systems have general arrangement drawings available for download. • Manuals – Technical, Operations, and Maintenance manuals can be downloaded. • Catalog – Water King’s entire catalog is available and divided into Table of Contents for easy viewing. • Frequently Asked Questions – Solutions to common problems and questions concerning Water King softeners.

30. Water King – Office Staff James "Jim" E. Bowie, Jr., Ph.D., P.E.President Raymond RichardsonTechnical Sales Karen M. Bowie Tammy DuhonOffice Manager Hector MembrenoEngineer Jason McWhorterSales
