  1. GE Interlogix Kalatel Division Product Update KTD-405 Programming & Standard Operations

  2. KTD-405 Keypad Programming

  3. KTD-405 keypad (Supervisor Programming) Boot-Up Screen KEYPAD ADDRESS: 99 KEYPAD 99

  4. KTD-405 keypad (Supervisor Programming) Default display after applying power CAMERA --- MONITOR 1

  5. KTD-405 keypad (Programming) Navigating the menus

  6. KTD-405 keypad (Programming) Menus that were not available in the first releases of software are indicated by two beeps and the following display: NOT IMPLEMENTED

  7. Supervisor Programming

  8. KTD-405 keypad (Supervisor Programming) To Access Programming: • Press and hold the key • The unit will beep and show the following display • Remote device programming must be accessed separately. • Supervisor programming password is 1,4,7,6, • Also includes All user programming ENTER PROGRAMMING CODE:

  9. KTD-405 keypad (Supervisor Programming) Resetting the Factory Defaults • The first menu to display will be this one. • Press to advance to the next menu and to return to the previous menu at any time without changing any existing parameters RESET TO DEFAULTS? NO <+>=YES <->=NO NEXT

  10. KTD-405 keypad (Supervisor Programming) If you pressed “+” (yes): • The next display will show: • Followed by: • Followed by: • The keypad will advance to the next menu automatically 1=RESET ALL BUT TITLES 2=RESET ALL ARE YOU SURE? <+>=YES <->=NO NEXT INITIALIZING DEFAULTS PLEASE WAIT

  11. KTD-405 keypad (Supervisor Programming) Setting The Keypad Address • The address is a “user defined” two-digit number • The address must be from 10 to 99 • Each device on the RS-485 network must have a unique address • Address 99 is automatically assigned when the keypad is first connected and will remain unless changed by the user • Entering an address that is already used temporarily displays: • Select  or  to skip over this menu KEYPAD ADDRESS: 99 (01-99) NEXT ADDRESS NOT AVAILABLE

  12. KTD-405 keypad (Supervisor Programming) Backward Compatibility? • If the KTD-405 is being used in a system with: • Existing ProBridges • Existing CBR-KB3 or CBR-KB3/J keypads • Select YES to allow the KTD-405 to communicate properly with these devices. • Select  or  to skip over this menu KB3 PTZ PROTOCOL? NO <+>=YES <->=NO NEXT

  13. KTD-405 keypad (Supervisor Programming) Allow Remote Programming by user? • If the KTD-405 is being used in a system with: • Matrix Switchers or Multiplexers • Alarm Monitoring Equipment • Programmable Dome Cameras or Receivers • Select YES to allow the user to enter the 9,5,1, password and program these devices • Select  or  to skip over this menu ENABLE REMOTE PRGMG? YES <+>=YES <->=NO NEXT

  14. = , = , = , = , KTD-405 keypad (Supervisor Programming) Programming Keypad Titles • A keypad title can be up to 14 characters including: • A – Z and 0 - 9 • Keypads with titles can use the “Seize Control” option • Supervisors can seize camera sites, multiplexers, VCRs, etc. • Supervisors can seize an entire zone in the ZONE mode • Use the joystick or these buttons to program the title • Select  or  to skip over this menu KEYPAD TITLE: <> NEXT

  15. KTD-405 keypad (Supervisor Programming) Changing the SEIZE CONTROL code • Use the number keys to enter the new code • The keypad will advance to the next menu when the last digit is entered • Select  or  to skip over this menu SEIZE CONTROL CODE: 8642 USE NUMBER KEYS NEXT

  16. KTD-405 keypad (Supervisor Programming) Changing the SEIZE CONTROL time • Use the number keys to enter the new time • This is the number of minutes of inactivity before the keypad will exit the seize control mode • Select  or  to skip over this menu SEIZE CONTROL TIME: 5 (1-10) MINUTES NEXT

  17. KTD-405 keypad (Supervisor Programming) Restricting access to presets • Use the number keys to enter the new limit • This is the lowest preset number a user may change • Select  or  to skip over this menu LOWEST USER PRGMD PRESET (01-64) 58 NEXT

  18. KTD-405 keypad (Supervisor Programming) Programming the SOFT keys • This feature is not yet implemented • Select -,  or  to skip over this menu • Pressing + displays the following message: PROGRAM SOFT KEYS? <+>=YES <->=NO NEXT NOT IMPLEMENTED

  19. KTD-405 keypad (Supervisor Programming) Programming the ACCESS codes • This feature is not yet implemented • Select -,  or  to skip over this menu • Pressing + displays the following message: CHANGE ACCESS CODES? <+>=YES <->=NO NEXT NOT IMPLEMENTED

  20. User Programming

  21. KTD-405 keypad (User Programming) To Access User Programming: • Press and hold the key • The unit will beep and show the following display • User programming password is 5,7,9, ENTER PROGRAMMING CODE:

  22. = , =  KTD-405 keypad (User Programming) Changing the Operating Mode • Two choices are available: • Digiplex • Zone • Use the joystick or these buttons to select the mode • Select  or  to skip over this menu OPERATING MODE: DIGIPLEX <,>=SELECT NEXT

  23. KTD-405 keypad (User Programming) DigiPlex mode Menus Setting the system size • Enter the highest camera number in your system • Select  or  to skip over this menu SYSTEM SIZE: <CAMERAS> 511 NEXT

  24. KTD-405 keypad (User Programming) DigiPlex mode Menus Setting the system size • Enter the highest monitor number in your system • Select  or  to skip over this menu SYSTEM SIZE: <MONITORS> 64 NEXT

  25. KTD-405 keypad (User Programming) DigiPlex mode Menus Setting the system size • Enter the highest multiplexer number in your system • Select  or  to skip over this menu SYSTEM SIZE: <MPLXS> 32 NEXT

  26. KTD-405 keypad (User Programming) DigiPlex mode Menus Setting the system size • Enter the highest VCR number in your system • Select  or  to skip over this menu SYSTEM SIZE: <DSR/VCR> 32 NEXT

  27. KTD-405 keypad (User Programming) DigiPlex mode Menus Setting the system size • Enter the highest preset number in your system • Select  or  to skip over this menu SYSTEM SIZE: <PRESETS> 63 NEXT

  28. = , =  KTD-405 keypad (User Programming) DigiPlex mode Menus Restricting system access • This menu restricts access to specified cameras • Use the joystick or these buttons to select the camera • Select  or  to skip over this menu CAMERA 000 ACCESS? YES <+>=YES <->=NO NEXT

  29. = , =  KTD-405 keypad (User Programming) DigiPlex mode Menus Restricting system access • This menu restricts access to specified cameras • Use the joystick or these buttons to select the camera • Select  or  to skip over this menu CAMERA 000 ACCESS? YES <+>=YES <->=NO NEXT

  30. = , =  KTD-405 keypad (User Programming) DigiPlex mode Menus Restricting system access • This menu restricts access to specified monitors • Use the joystick or these buttons to select the monitor • Select  or  to skip over this menu MONITOR 01 ACCESS? YES <+>=YES <->=NO NEXT

  31. = , =  KTD-405 keypad (User Programming) DigiPlex mode Menus Restricting system access • This menu restricts access to specified recorder • Use the joystick or these buttons to select the recorder • Select  or  to skip over this menu • Pressing “+” displays this menu: • Enter a number from 0 to 511, or 0 for NONE or • Select  or  to skip over this menu DSR/VCR 01 ACCESS? YES <+>=YES <->=NO NEXT VCR 01 MATRIX INPUT: 000 <0=NONE> NEXT

  32. = , =  KTD-405 keypad (User Programming) DigiPlex mode Menus Restricting system access • This menu restricts access to specified multiplexer • Use the joystick or these buttons to select the multiplexer • Select  or  to skip over this menu MPLX 01 ACCESS? YES <+>=YES <->=NO NEXT

  33. KTD-405 keypad (User Programming) DigiPlex mode Menus If you pressed “+” (yes): • The next display will show: • Followed by: • Followed by: • The keypad will advance to the next multiplexer menu automatically MPLX01 BRAND CBR DVMRe <,>=SELECT NEXT MPLX 01 MATRIX INPUT? 000 <0=NONE NEXT SELECT MAX OUTPUTS: 02 <,>=SELECT NEXT

  34. KTD-405 keypad (User Programming) DigiPlex mode Menus Programming the monitor offset • Enter a number for the offset needed in your system • Select  or  to skip over this menu MONITOR OFFSET NUMBER: 0 NEXT

  35. KTD-405 keypad (User Programming) DigiPlex mode Menus Queuing and announcing call-ins • If you select “+” in this display: • You need to select either SINGLE or MULTIPLE tone here: • Also specify a monitor to display the queued calls: • Select  or  to skip over this menu ANNUNCIATION? NO <+>=YES <->=NO NEXT CALL TONE TYPE? MULTIPLE <,>=SELECT NEXT SPOT MONITOR NUMBER: 0 <0=UNASSIGNED> NEXT

  36. KTD-405 keypad (User Programming) DigiPlex mode Menus End of menus notification • Pressing  from the previous menu will cause the keypad to display this message: • Select  or press and hold for 3 seconds to exit the menus PRESS <SEQ> FOR 3 SECONDS TO EXIT

  37. = , =  KTD-405 keypad (User Programming) Changing the Operating Mode • Two choices are available: • DigiPlex • Zone • Use the joystick or these buttons to select the mode • Select  or  to skip over this menu OPERATING MODE: ZONE <,>=SELECT NEXT

  38. KTD-405 keypad (User Programming) Zone mode Menus Programming the Mode label • This menu allows you to select one of several labels for the LCD display during normal operations • Selections Include: • ZONE, MPLX, DVMR, TERR, BLDG • FLR, DEPT, STA, SITE, AREA • Select  or  to skip over this menu LCD DISPLAY LABEL: ZONE <,>=SELECT NEXT

  39. KTD-405 keypad (User Programming) Zone mode Menus Programming the zone titles • This menu allows you to select a title to display when the specified zone is being accessed. • Select  or  to skip over this menu • Enter a two-digit code and the keypad will advance to the following menu automatically • Program the label characters the same way as keypad titles • Select  or  to skip over this menu ENTER ZONE ADDRESS: 01 (01-16) NEXT ZONE 01 TITLE: <> (01-16) NEXT

  40. KTD-405 keypad (User Programming) Zone mode Menus Programming the Zone type • This menu allows you to identify the specific device that makes up a zone: • Selections Include: • CALIBUR MMX, CBR DVMRe, CBR TRIPLEX, • CBR DUPLEX, CBR SIMPLEX, MATRIX SWCH, • Select  or  to skip over this menu ZONE 01 HUB: CBR DVMRe <,>=SELECT NEXT

  41. = , =  KTD-405 keypad (User Programming) Zone mode Menus Setting the zone size (monitors) • This menu restricts access only to available zone monitors • Use the number buttons to set the number of monitors • Select  or  to skip over this menu Setting the zone size (cameras) • This menu restricts access only to available zone cameras • Choices include 4, 9, 10, 16 and 32 • Use the joystick or these buttons to select the mode • Select  or  to skip over this menu ZONE 01 MON. OUTPUTS? 01 TO 02 NEXT ZONE 01 CAM. INPUTS? 16 <,>=SELECT NEXT

  42. KTD-405 keypad (User Programming) Zone mode Menus Programming zone access privileges • Program the cameras that this keypad can access: • Program the monitors that this keypad can access: • Program user access to the zone’s recorder : • You should deny access unless you have a Triplex or MMX connected to a VCR using sub-macros. ZONE 1 CAM 01 ACC? YES <+>=YES <->=NO NEXT ZONE 1 MON 01 ACC? YES <+>=YES <->=NO NEXT ZONE 1 RECORDER ACC? YES <+>=YES <->=NO NEXT

  43. KTD-405 keypad (User Programming) Zone mode Menus If the Zone type is set to MATRIX SWCH: • The zone size and access menus displays are slightly different ZONE 02 HUB: MATRIX SWCH <,>=SELECT NEXT

  44. KTD-405 keypad (User Programming) Zone mode Menus Programming zone size • Program the first camera input number for this zone: • Program the number of monitors for this zone: • Program the number of camera inputs on this zone: • Choices include 4, 9, 10, 16 and 32 SELECT START INPUT: 032 <,>=SELECT NEXT ZONE 02 MON. OUTPUTS: 01 TO 16 NEXT ZONE 02 CAM. INPUTS: 64 <,>=SELECT NEXT

  45. KTD-405 keypad (User Programming) Zone mode Menus Programming zone access privileges • Program the cameras that this keypad can access: • Program the monitors that this keypad can access: • Program user access to the zone’s recorder : • You should deny access unless you have a Triplex or MMX connected to a VCR using sub-macros. ZONE 02 CAM 01 ACC? YES <+>=YES <->=NO NEXT ZONE 02 MON 01 ACC? YES <+>=YES <->=NO NEXT ZONE 02 RECORD ACC? YES <+>=YES <->=NO NEXT

  46. KTD-405 keypad (User Programming) Zone mode Menus Queuing and announcing call-ins • If you select “+” in this display: • You need to select either SINGLE or MULTIPLE tone here: • Also specify a monitor to display the queued calls: • Select  or  to skip over this menu ANNUNCIATION? NO <+>=YES <->=NO NEXT CALL TONE TYPE? MULTIPLE <,>=SELECT NEXT SPOT MONITOR NUMBER: 0 <0=UNASSIGNED> NEXT

  47. KTD-405 keypad (User Programming) Zone mode Menus End of menus notification • Pressing  from the previous menu will cause the keypad to display this message: • Select  or press and hold for 3 seconds to exit the menus PRESS <SEQ> FOR 3 SECONDS TO EXIT

  48. Remote Programming

  49. KTD-405 keypad (Remote Programming) To Access Remote Programming: • Press and hold the key • The unit will beep and show the following display • User programming password is 9,5,1, • Correct password entry will cause the following display: • Each selection generates a different set of menus ENTER PROGRAMMING CODE: 1=SWITCHER/MPLX 2=ALARMS 3=CAMERA/RCVR EXIT

  50. KTD-405 keypad (User Programming) Switcher/Mux Menus Switcher/Multiplexer Programming • Identify the device to be programmed • If you select “1” (440) enter the monitor number to use for programming the switcher • The keypad will display this message 1=440 2=CALIBUR 3=340/348 BACK ENTER MONITOR NUMBER: (1-64) BACK SEE MONITOR FOR MENUS HOLD SEQ <3 SEC> TO EXIT
