“R”, the radius, is 1 foot. R. 1 foot. so A = R 2 3.14 * 1 * 1 3.14 square feet . 2 feet. means “about equal to”. Click your mouse for the next idea !. How would you calculate the area of this circle ?. ...probably using the formula A = R 2.

Télécharger la présentation
## 2 feet

**An Image/Link below is provided (as is) to download presentation**
Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author.
Content is provided to you AS IS for your information and personal use only.
Download presentation by click this link.
While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server.
During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

**“R”, the radius, is 1 foot.**R 1 foot so A = R2 3.14 * 1 * 1 3.14 square feet 2 feet means “about equal to” Click your mouse for the next idea ! How would you calculate the area of this circle ? ...probably using the formula A = R2 Since the diameter is 2 feet, ? The constant , called “pi”, is about 3.14**2 feet**Click your mouse for the next idea ! LETS explore how people figured out circle areas before all this business ? The ancient Egyptians had a fascinating method that produces answers remarkably close to the formula using pi. ?**2 feet**Click your mouse for the next idea ! The Egyptian Octagon Method Draw a square around the circle just touching it at four points. ? 2 feet What is the AREA of this square ? Well.... it measures 2 by 2, so the area = 4 square feet.**2 feet**Click your mouse for the next idea ! The Egyptian Octagon Method Now we divide the square into nine equal smaller squares. Sort of like a tic-tac-toe game ! 2 feet Notice that each small square is 1/9 the area of the large one -- we’ll use that fact later !**2 feet**Click your mouse for the next idea ! The Egyptian Octagon Method Finally... we draw lines to divide the small squares in the corners in half, cutting them on their diagonals. 2 feet Notice the 8-sided shape, an octagon, we have created ! Notice, also, that its area looks pretty close to that of our circle !**1**9 1. 18 1. 18 After all, THIS little square has an area 1/9th of the big one... 1 9 1 9 1 9 And so do these four others... 1. 18 And each corner piece is 1/2 of 1/9 or 1/18th of the big one 1. 18 1 9 2 feet Click your mouse for the next idea ! The Egyptian Octagon Method The EGYPTIANS were very handy at finding the area of this Octagon 2 feet**1**9 1. 18 1. 18 4 pieces that are 1/18th or 4/18ths which is 2/9ths 1 9 1 9 1 9 Plus 5 more 1/9ths 1. 18 1. 18 1 9 2 feet Click your mouse for the next idea ! The Egyptian Octagon Method ...and ALTOGETHER we’ve got... 2 feet For a total area that is 7/9ths of our original big square**We have an OCTAGON with an area = 7/9 of the original**square. 7 9 2 feet Click your mouse for the next idea ! The Egyptian Octagon Method FINALLY... Yep, we’re almost done ! The original square had an area of 4 square feet. 2 feet So the OCTAGON’s area must be 7/9 x 4 or 28/9 or 3 and 1/9 or about 3.11 square feet**AMAZINGLY CLOSE**to the pi-based “modern” calculation for the circle ! 3.11 square feet 3.14 square feet only about 0.03 off... about a 1% error !!
