  1. Notes on Heat Energy

  2. Energy • Is thecapacity to do workor to produce heat • Forms: • Kinetic energy= energy of motion • Potential energy= energy of position • Thermal energy= a form of KE caused by random internal motion of particles of matter

  3. Heat • A form ofenergy • Is measured in calories (cal) orJoules(J) • 1 cal =4.184 J • 1 Cal = 1000 cal • Isnotthe same as temperature!

  4. Temperature • A measure of theKinetic Energyin a system • Units are:FahrenheitorCelsius(Centigrade) orKelvin

  5. Absolute Zero • Corresponds to about-273 oC • Is the (theoretical) point at which the motion of particles of matter –their kinetic energy- ceases

  6. More about Temperature • For most applications in Chemistry, we will use theCelsiusscale. • There is at least one topic for which we must change our temperature units to Kelvins – that is forGas Laws. • On the Kelvin scale there is no “zero” and no negative values. That becomes important in calculations involving gases, since a negative temp might make it look like, in calculations, that there is a negative volume.

  7. Law of Conservation of Energy Energy is neither created nor destroyed…it just Changes form. By the way… We can record a reading as, for example, 102.3 degrees Celsius - but - if we were to record a temperature using the Kelvin scale, we would simply state, for example, “275 Kelvins” (not“degrees kelvin”)

  8. Conversions • C = K – 273so thereforeK = C + 273 • C = 5/9 (F – 32) and F = (9/5*C) + 32 22.5oC = ___ K 55oF = ___ oC 290 K = ___oC 97 oF = ___ oC Temperature “Sense” – Memorize these: Room Temp in C: 22 Body Temp in C: 37 Boiling Pt/Freezing Pt: 100/0

  9. Specific Heat • A property of matter that is unique to each element or compound – • It does not depend on the amount of matter present, so is anintensiveproperty • Also called “heat capacity” • “the amount of energy needed to raise the temperature of 1 g of a substance by 1 degree Celsius”

  10. Formula for Specific Heat • Q = mcDT • WhereQ= “heat” and is measured in J • Wherem= mass and is measured in g • Wherec= specific heat and is measured in …(see next slide!) • WhereDT= (“delta T”) is “change in temperature” and is measured in C

  11. Unit for Specific Heat • So what is the unit for “c”? • Let’s rearrange the formulaQ = mcDTin terms of c (we call this “deriving”) • c = Q / mDT • All units in Chemistry and Physics come from the formulas that they’re in • Therefore,c = Q / mDT J / g oC

  12. Specific Heat of Water • Water, H2O, has anextremely high“heat capacity”, which in plain language, means that it takes a lot of energy to heat it up and it has a tremendous ability to retain heat (aka: takes a lot to cool it down) • The specific heat of water is 4.18 J/goC(which you may recognize as 1 calorie) • Memorize this!!!!!!!!!!!

  13. Why That’s Important • It affects your life every day. • The reason it tends to be cooler at the ocean than in the valley is due to the cH2O • The reason that hurricanes get stronger over warm water is that they’re deriving their energy from the heat contained in the water (maybe that doesn’t affect you every day); it gives them energy • The reason a steam burn is worse than a regular burn is due to the energy in the steam • Can you think of other examples?

  14. Reminder: Law of Conservation of Energy • We know that energy cannot be created or destroyed • We know that heat is a form of energy • So…it must be true that the heat lost by one substance must be “accountable” by another substance or substances, or… • Q lost = Q gained

  15. If Qlost = Qgained • …andif Q = mcDT, then it must be true that… • (mcDT) lost = (mcDT) gained • And that’s the foundation for our next lab: “Specific Heat of a Metal”

  16. Pre-Lab: Specific Heat of a Metal • Discussion: You will be given a sample of a metal. You will have to determine its specific heat. • We already know the specific heat of water (4.18 J/goC) • We will use the concept of … • (mcDT)lost =(mcDT)gainedto solve for the unknown c for the metal

  17. Lab: Specific Heat of a Metal • (mcDT)gained = (mcDT)lost • (mcDT)gained by water = (mcDT)lost by metal • (mcDT)water = (mcDT)metal If the metal starts at the boiling point of water, that’s your T1. The temp after the water has stopped rising has to be the temp of the metal as well, so that is T2. Measure the mass of the water Measure the initial temp of the water before the metal was added; the final temp after the metal heats it up You will be calculating the “c” for the metal You know the “c” for water (4.18 J/gC) Measure the mass of the metal
