  1. En-route Working Group(and working group of the whole) 13 March 2013

  2. All Working Groups • Operational DCL End-to-End • At final draft • Comments to Carol Burr by APril • Will be approved at DCIT-32 in April • Next step is to start the Flight Deck and other documents (SIDD?) • Actions have been allocated to start this • Action allocated to begin preparation of other operational documentation • IOC requirements reviewed and prioritized based on operational viability and fleet inclusion • UM83 on/off switch • UM79 repeat TO point • Airway/airway • Radials flown as route elements

  3. En-Route End-to-end Service descriptions • DCIT-31 target: En-Route end-to-ends complete, Use Case level • Transfer of Comm / Initial Contact (Andy Fry leading) • Route modifications (Suzy Hawkins leading) • Additional feedback will be treated as it comes in (e.g. we just received new “full” use cases) • Plenary approves both end-to-end documents? • Detailed message construction and messaging scenarios • Target is end-August to match FAA timescales • Specific lists already available in both TOC/IC and Route Mod’s • Actions assigned out for detailed scenarios • Will be synched with Harris Interoperablity testing activity now being launced • End-to-ends are the central repository so that ground and air have common testing scenarios and cross-usable results • We are on track for DCIT synched requirements by FID • Validation still needs to be done

  4. Back-up

  5. FAA Services Roadmap CY 14 16 18 20 22 24 26 28 30 Segment 1 Phase 1 - Tower Service Departure Clearance Tower IOC Departure Clearances (DCL) Segment 1 Phase 2 - En Route Services Transfer of Communications Initial Check-In Altitudes / Altimeter Settings Go Button / Airborne Reroutes Tailored Arrivals Controller Initiated Routes Direct-to-Fix Crossing Restrictions Advisory Messages Speed and Headings Beacon Codes Stuck Microphone Transfer of Communications Initial Check-In Altitudes / Altimeter Settings Go Button / Airborne Reroutes Tailored Arrivals Controller Initiated Routes Direct-to-Fix Crossing Restrictions Advisory Messages Speed and Headings Beacon Codes Stuck Microphone Data Comm Routine Communications En Route IOC Initial En Route Services TFM Data Comm Reroutes Segment 1 Phase 3Full En Route Services Data Comm Routine Communications FANS 1/A+ over VDL-2 transitioning to ATN Avionics FANS Ground System ATN Segment 2 - Advanced Services Segment 2 IOC 4D Trajectories D-TAXI

  6. En-route Working Group Working Targets • Final Investment Decision in fall 2014 • Requirements need to be done at end-2013 / early-2014 (CY) • For DCIT, this End-to-End, Flight Deck and SIDD level documents • DCIT ERWG Priorities • Service work areas selected on the basis of complexity, criticality to Program, and aircraft operator value • Complexity • Criticality to Program success • TOC/IC, including National Single Data Authority (NSDA) and “Eligibility into this” • Route Modifications • Go Button • Controller Initiated Reroutes • Direct-to-fix • Tailored Arrivals • Crossing constraints
