Effectively Validate Query/Report: Strategy and Tool

2. Session id: 36993 Effectively Validate Query/Report: Strategy and Tool Steven Luo Sr. System Analyst Barnes & Noble

3. Agenda • PART I: Introduction • Why, when, and how to validate • PART II: Strategy • Basic strategy • Advanced strategy • PART III: Tool • Test script • Engine - sqlUnit • PART IV: Conclusion

4. Why to Validate? • Assure Data Accuracy • Managers need accurate data to make strategic decisions • A company’s sales team needs accurate data to launch market campaign • Assure ETL (Extraction, Transformation, and Loading) Process Correctness • ETL tools • SQL scripts

5. When to Validate? • Any of the following types of testing needs validation: • Unit testing • Integration testing • System testing • Acceptance testing • Maintenance & regression testing

6. How to Validate?

7. Agenda • PART I: Introduction • Why, when, and how to validate? PART II : Strategy • Basic strategy • Advanced strategy • PART III: Tool • Test script • Engine - sqlUnit • PART IV: Conclusion

8. Validating Report/Query • A Query or Report is actually a result set, so validating needs to answer two questions: • Are you getting the result set right? • right data in each cell • Are you getting the right result set? • exact number of records

9. A Typical Process of Generating Reports ETL steps Stored procedure report staging tables materialized view flat files T0 T1 …... Tn

10. Basic Strategy • Assert that each (cell) in the result set matches the data in the source table • Number • String • Date • Result Set, etc. • Sampling should be used if a result set is big • Assert the right number of records in the result set • Check duplicated…

11. Advanced Strategy • Try to uncover invalid data item • Boundary Validation • Count, sum, max, min, x not in table, “between..and” on whole resultset or certain partitions. • Special Value (constraints) Validation • isXXX() and notXXX() • e.g. IsNull, notNull, notNegative, notZero • Business Rule Validation • dept1.sale> dept2.sale

12. Agenda • PART I: Introduction • Why, when, and how to validate ? • PART II : Strategy • Basic Strategy • Advanced Strategy PART III: Tool • Test Script • Engine - sqlUnit • PART IV: Conclusion

13. Why Use a Validation Tool? • Automate the validating process • Reduces the cost, time and effort • Reuse the procedures • Write once, run many times on QA box and/or production box. • Re-factor SQL • Share by group (save to PVCS)

14. Tool • Open Source • jUnit, etc. • Steven Feuerstein’s utPL/SQL • My tool -- sqlUnit

15. sqlUnit Overview • The framework consists of two major parts • test scripts • test engine • implemented in java stored procedure with PL/SQL interface • Implement 2 types of strategy • basic strategy • advanced strategy • Record the validating results • Monitor long-running validation process

16. sqlUnit Overview (2) • From the Engine Perspective • run all your test cases defined in your PL/SQL package • From the User Perspective • write all test scripts • start the Engine

17. Architecture Engine Assert Test scripts …… util Database

18. Test Script (1) • Write Test script in PL/SQL • Define test package • Call APIs • Define test procedures • Test procedure MUST begin with ‘test’ • Setup() : • Teardown(): clean up

19. Test Script (2) • Use your business knowledge to get expected data and actual data • Get raw or original data from source table • such as POS, Daily Sales, etc. • Get data from a report • call API fetchCursorData(…), or • using cursor directly, e.g. cc := my_test_pkg.get_ref_cursor('SCOTT'); loop fetch cc into value1,value2,..., valuek; exit when cc%notfound ; if(...) then sqlunit.assert(‘desc’, value1, 100); end if; end loop;

20. APIs for Basic Strategy procedure runTestCases(testPackageName varchar2) procedure assert(description varchar2, num1 number, num2 number) procedure assert(description varchar2, str1 varchar2, str2 varchar2) procedure assert(description varchar2, a1 STRING_ARRAY, a2 STRING_ARRAY) procedure assert(description STRING_ARRAY, a1 STRING_ARRAY, a2 STRING_ARRAY) procedure assertQuery(description varchar2, query1 varchar2, query2 varchar2) procedure fetchRefCursorInto(pname in varchar2, parameters in STRING_ARRAY, fetchfields in out STRING_ARRAY, uniqField in varchar2, uniqValue in varchar2 ) function getCountForQuery(sqlstr varchar2) return number function getCountForProcedure(sqlstr varchar2) return number

21. Test Script Template

22. Apply Basic Strategy • A tool should pick up: • m column(s) in a row of a result set • m: between 1 and number of columns • m column(s) in n rows of a result set • m: between 1 and number of columns • n: between 2 and number of rows • Cells to be validated: • cells: between 1 and m*n

24. Apply Advanced Strategy • Advanced Strategy • Boundary Object • Special value (Constraint)Object • Business Rule Object

25. Test Script for Advance Strategy procedure test_adv_1 is obj sqlunitBoundary := sqlunitBoundary(NULL,NULL,NULL,NULL); begin obj.setTestingQuery('my_test_pkg.get_ref_cursor(''SCOTT'')'); obj.setCountCriteria(2); obj.setQueryCriteria('c1 is not null'); obj.setQueryType(1); //1 : store procedure. 0: sql query obj.checkBoundary; exception when others then dbms_output.put_line('exception! '); end test_adv_1;

26. Example for Validating Two Queries

27. How Engine Works • Users start the Engine by calling … exec sqlunit.runtestcases('VALIDATEPACKAGE'); • Engine calls back test scripts by calling the following: set_up; test_1; tear_down; set_up; test_2; tear_down; ... set_up; test_n; tear_down; • Test scripts call Framework APIs …. sqlunit.assert(...) sqlunit.assert(...) sqlunit.assert(...)

28. Sequence Diagram testPackage sqlUnit/engine DB Runtestcases() setup test_1 assert recordResult tear_down setup test_2 recordResult assert tear_down View results

29. Record the Test Result • Use package name as testing result table name.

31. Monitoring Validation Process • At Engine level, by instrumentation DBMS_APPLICATION_INFO into Engine, you can monitor the progress • At test script, you can instrument DBMS_APPLICATION_INFO to test scripts too. • Get the progress information from v$session_longop in other session

32. Test Scripts Guideline • Be simple • Don’t use the same sql that generates the report • Use Business/domain knowledge

33. Conclusion • Data accuracy is very important • Use automated validating tool whenever possible

34. Limitation of validation “ Program testing can be used to show the presence of bugs, but never to show their absence” --E. W. Dijkstra

35. References • Asimkumar Munshi, Testing a Data Warehouse Application white paperhttp://www.wipro.com/insights/testingaDWApplication.htm • B. Hailpern and P. Santhanam Software debugging, testing, and verification IBM System Journal Vol. 41, No. 1, 2002 • Thomas Kyte, Expert One on One Oracle, Wrox, 2001
