  1. QUALITY ASSURANCE ADVANCED IMAGING EQUIPMENT CHAPTER 10

  2. Digital Radiographic Imaging Systems • Conversion of Analog Film Image to Digital Format • Laser Scanning Digitizer • Charge- Coupled Device Scanner • Computerized Radiography

  3. DIGITAL RADIOGRAPHIC IMAGING SYSTEMS • Advantages over analog format • Comparison of indirect & direct capture method • Quality Control for DR

  4. Digital fluoroscopy • Last Frame-Hold • Road Mapping • Digital Temporal Filtering • Image Enhancement • Image Restoration • Image Intensifier Tube Digital Fluoroscopy • Flat panel Digital fluoroscopy • Continuous Fluoroscopy • Pulsed Interlaced Scan Mode • Pulsed Progressive Scan • Slow Scan Mode

  5. Quality Control Digital Fluoroscopy Electronic Display devices Multiformat Cameras Laser Cameras Image Archiving and Management Networks

  6. Outcomes Assessment of Radiographic ImagesChapter 11 • Repeat Analysis • Artifact Analysis : Processing/Exposure/Handling & storage • Computerized Radiography & Digital Radiography Artifacts

  7. Mammographic Quality Standards Chapter 12 • Dedicated mammographic equipment • Generator • Tube • Tube window • Focal spot size • SID • Compression • Grids • IR • Film processors • Magnification Mammography

  8. Full-Field Digital Mammography Systems 1)Tissue Equalization 2) Magnification 3) Image Inversion 4) Window leveling 5) Annotations and Measurements
