1. Mapserver The PSU Experience David Percy Geospatial Data Manager, Geology Department William Garrick Manager of Academic and Research Computing Portland State University

2. 2005 the year of OS GIS • Books • Mapping Hacks • Web Mapping Illustrated • MapServer Essentials • Google Earth • AutoDesk

3. Background of Presenters • Percy • Over 20 years of scientific databases including medical research • Hired by Geology department in 1998 as data manager. GIS became an obvious need. • Began teaching in 1999, since then adding Field GIS, GIS Programming and this year Web Mapping • Will • Manager of Academic and Research Computing • Staff at PSU for 8 years • 12 Student Programmers

4. Previous Web Mapping at PSU • Windows servers in offices running ESRI ~ 1998-2004: • Geology, and Urban Planning • Map Objects, then ArcIMS: Oregon Geologic Map and reference • First Mapserver foray in 2002, project abandoned not due to mapserver • Coastal data, database of Glacier Change, all science goes to the web now. • ASP pages transitioned to Apache, MySQL, PHP in 2003 in preparation for move to Open Source

5. Academic and Research Computing to the rescue! • Managed servers with Linux • Ugly install of ArcIMS • Began discussion of Mapserver/PostGIS • Other projects requesting webmaps from ARC • Strong investment in Apache, PHP, MySQL already. • Leverage existing strengths • Cost of Oracle/SQL Server prohibitive at PSU • Institutional support for Open Source solutions

6. Components of Open Source Web MappingThe new “LAMP” • L – Linux • A – Apache • M – MySQL • P – PHP • L – Linux • A – Apache • M – MapServer • P – PostGIS

7. Open Source Components • GDAL – Raster Library • OGR – Vector Library • GD – Graphics Creation • Proj.4 – Coordinate Systems • FreeType – Nice fonts! • GEOS – Geometry Engine • Shapelib – Shapefile library

8. Setting up a MapServer Site • Installation • Build from source code • Install a package • Get data on server • Create mapfile • (analogous to AXL) • Choose or write a front end • (similar to choice between HTML and JAVA) • Stateless! • (No JAVA Servlets!)

9. A closer look at the “stack” • Front end – • PHP/Mapscript with Javascript • PHP/Mapscript • Pure CGI with template substitution • Data in • PostGIS or Shapefiles for vector • Geotiff, ECW or JPEG2000 for raster • Referenced and styled by MAPFILE • Mapserver CGI built with all the right “includes” • Webserver – Apache • Operating system - Linux

10. The Big Choice:What front end? • Percy facilitates open source sessions • Ka-Map • Chameleon • MapBender, MapLab, FIST • Grad Students revolt! • Requirements defined • Pan, Zoom, Query, some AJAX • In a single weekend prototype developed • Currently used in three production systems, fourth almost ready • Demos!

11. Web Interfaces • Ka-map • Chameleon • Maplab • MapBlender • FIST • CGI • Build your own

12. Conclusions • Web Mapping is reliable and proven • GeoDatabases, combined with WFS and WMS services are reliable and promising • Be careful what Open Source project you align with • Many projects are brilliant, but orphaned • OSCDL will continue support and development, both for map interfaces and backend datastreams.

13. Data Streams • End of Monolithic Web Apps • Open Geospatial Consortium (OGC) • WMS • WFS • Query for capabilities • High Quality data streams from many sources, possibly aggregated through Google Earth

14. Data Management Partnerships • Similar to co-location of servers • Harness the expertise of PSU • percyd@pdx.edu • will@pdx.edu

15. GeoDatabases • PostgreSQL • From Berkely, Ingress • Transactions, rollback and other modern database features • Object – Relational DB • PostGIS • Extensions for GIS functionality to PGSQL
