Reflection and Refraction

Reflection and Refraction. Reflection. Two laws of reflection Angle of incidence = angle of reflection The angle of incidence, angle of reflection and normal all lie in the same plane. Refraction. Light travels more slowly in glass, perspex etc than in air or in a vacuum

blaze
Télécharger la présentation

Reflection and Refraction

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Reflection and Refraction

  2. Reflection • Two laws of reflection • Angle of incidence = angle of reflection • The angle of incidence, angle of reflection and normal all lie in the same plane

  3. Refraction • Light travels more slowly in glass, perspex etc than in air or in a vacuum • If light meets a block of glass etc head on it goes straight through • If light meets a block of glass etc at an angle it bends

  4. Refractive Index • Light travels fastest through a vacuum • Light travels more slowly through other materials like glass, water or perspex • The Refractive Index links the speed of light in a vacuum to the speed of light in a medium • Refractive index n = speed of light in a vacuum speed of light in the medium • n = 1.33 for water • n = 1.5 for glass (approx – depends on the glass)

  5. n = sin i sin r Laws of Refraction • Law 1 Snell’s Law Law 2 The incident ray, refracted ray and normal all lie on the same plane

  6. Relative Refractive Index • When a ray travels from one medium to another, the relative refractive index is n(first medium) n(second medium)and you use this relative n in Snell’s Law

  7. Calculations using the laws of refraction • Calculate the relative refractive index • Relative n = n (for first medium) n (for second medium) • Use the relative n in Snell’s Law to solve the problem
