  1. Trace Evidence

  2. Trace evidence- small pieces of material • Debris from mass produced materials • Abundant in nature

  3. Examples of Trace Evidence • Hair • Fibers • Paint • Glass • Gasoline • Soil • Dust

  4. How is trace evidence collected? • Vacuum • Tape lifts • Picking • Combing • Scraping

  5. Types of Evidence Class evidence can be associated with a general group • Ex. Blood type • Ex. Print from a Size 7 Nike sneaker Individual evidence can be associated with a single source Ex. DNA typing Ex. Size 7 Nike sneaker w/ specific wear pattern

  6. Problems w/ trace evidence 1. Many samples are VERY similar because • Many materials are made through mass production • Tight quality control in the factories means there is little variation. 2. Mobility of criminals - Makes it difficult to trace the evidence back to a specific source.

  7. 3) Trace evidence is least likely to be individualized. • Exception: Hair can be individualized if DNA can be isolated from the root

  8. Locard’s principle • When two objects come into contact, material is exchanged. • How much material is transferred is affected by • Intensity of contact • Duration of contact • Type of surfaces

  9. Questions to ask about trace evidence • 1. What is it? • 2. Man-made or natural? • 3. What is its source? • 4. How common is it? • 5. Can it be identified to a single source?

  10. Equipment • Stereomicroscope 10-60X • Compound microscope 40-1000X • Comparison microscopes • Phase contrast microscope 100-1000X • Better resolution • Scanning electron microscope (100,000X) • Ex. Layered paint • FTIR- Fourier Transform infra Red Spectrophotometer • GC- Gas chromatograph (ex. Gasoline)

  11. Identification process • Compare physical and chemical properties • Look at the probabilities that each piece of evidence could be present • Case Study: Wayne Williams (Atlanta serial killler)

  12. Paint • Physical Analysis • Color • Physical match of broken edges • # of matching layers

  13. Paint • Chemical Analysis • Solubility tests • Determine type: oil-based, water based, acrylic, or latex • analyze chemical make-up

  14. Matching pieces Surface materials Tinting films Labels Paint Color Refractive index (RI) (ability of glass to bend light) Density Glass

  15. Gasoline • Each gas company’s product is different • Forensic lab can identify the brand and grade

  16. Soil Analyze: - color - pH - type of soil - sizes of particles

  17. Information from soil • Where was the crime committed? • Soil type may be unique to a given area • Clay • Sand • Coal dust • Seeds or pollen in the soil may be from specific plants

  18. Dust • Some dust is unique to an area • Ex. Bathroom-talcum powder, cosmetics • Ex. Kitchen- flour, spices • Ex. Factory- remnants of manufacturing process
