  1. ITEC 352 Lecture 33 USB (2)

  2. Review • Intro to USB • History • Rationale • Competitors • Serial versus parallel • Topology

  3. Objectives • Types of transfer modes • Pins • Encoding electricity into 0’s and 1’s • Packets

  4. Transfer modes • Isochronous transfers • Guaranteed rate but possible data loss • Interrupt transfers • Quick response transfer • Bulk transfers • Uses all available bandwidth • No guarantee on timing or latency • Control transfers • Tell the device what to do

  5. Connector • Pin Layout (1-4) • Vcc +5V (Why is this important?) • Data- • Data+ • Ground • Why so simple?

  6. Why 2 wires? • Why do you think 2 data wires is important? • Twice the capacity (parallel)? • Error detection? • Host to Client, Client to Host? • Others?

  7. Electricity • Sends a signal across a wire Note: How clean is this signal? What can we do to with this level of signal strength?

  8. Brainstorm • Develop a system for sending 0s and 1s across an electrical wire in a safe manner • Tools • Clock pulses

  9. NRZI Encoding • Start at 1 or 0 • At the next clock edge • If value changes it is a 1 • If it stays the same it is a 0 • Or vice versa (USB uses same as 1, change is 0)

  10. Circuitry thought • Have to have some way to accumulate the bits • Start with 32 bits of 0 • Shift bits right • Insert bit from wire into accumulator • Sound familiar to P1? • Binary adders + Flip flops • 5 bits of memory (2^5 = 32) • Add 1 to it each time • When overflow happens, data is ready Note: not exactly what is used, but close

  11. Process • A protocol (what is it in your own words?) • Which ones do you know of? • Handshaking • Series of known 0s and 1s • Timing • Devices run at different speeds • Have to figure out their transmission speed • Handshake allows you to figure out the timing

  12. Packets • Group of 0’s and 1’s put together • Agreed upon method of communication • Preamble (timing) = 1100 0011 1100 • Ping = 0100 0010 1101 • Response • ACK = 0010 0100 1011 • NAK… • Stall…

  13. How it works • Once you identify yourself • Certain number of bits read in based on command • Data transfer basics • Send data command from computer • Data sent from device • Ack from computer saying it got data • If Ack not there, data resent • Also have to verify data is ok and not corrupt

  14. Data safety • How can you verify that a series of 0’s and 1’s are transferred correctly? • Ideas?

  15. Software • Read X bits into an array == Packet! • Handling each bit… • Not very desirable • Libraries to handle this for us • Next time!

  16. Summary • USB • Electrical and • Next time • Code / libraries
