Shopping is often time-consuming as consumers search multiple websites for the best deals. SOAShopper provides an effective solution by aggregating comprehensive product listings across various platforms in one place. Users can perform searches based on specific criteria like category, currency, and price range, making it easier to find the best offers. With its layered architecture, including business, intermediary, and backend services, SOAShopper simplifies the shopping experience while ensuring seamless integration with major shopping APIs such as Amazon, eBay, and Yahoo.

#streamline your shopping experience with soashopper #streamline your shopping experience with soashopper ppt #powerpoint #presentation
Streamline Your Shopping Experience with SOAShopper - slide 1
01 / 24Streamline Your Shopping Experience with SOAShopper
1 / 17

Télécharger la présentation

Streamline Your Shopping Experience with SOAShopper
Une image / un lien ci-dessous est fourni (tel quel) pour télécharger la présentation

Politique de téléchargement : le contenu du site vous est fourni TEL QUEL pour votre information et votre usage personnel ; il ne peut être vendu, concédé sous licence ni partagé sur d’autres sites sans l’accord de son auteur.Le contenu vous est fourni TEL QUEL, pour votre information et votre usage personnel uniquement. Téléchargez la présentation en cliquant sur ce lien. Lors du téléchargement, si vous ne parvenez pas à télécharger une présentation, l’éditeur a peut-être supprimé le fichier de son serveur.Pendant le téléchargement, si vous ne parvenez pas à obtenir une présentation, le fichier a peut-être été supprimé par l’éditeur.

F I N

Plus de contenu associé

Transcription de la présentation

  1. Shopping is FUN!!!!!!! Ravi Palejiya Ruofan Xu

  2. Goal • Consumer often spends lot of time on searching for best deals of products on different websites. • SOAShopper provides a solution for it. Thus they don’t need to waste their time in exploring websites. • SOAShopper will give one comprehensive list at a single place.

  3. Objective SOAShopper project will meat the following objectives • Product Keywords Search on three different shopping services. • Select search criteria as Category, Currency, Price-Range (High price, Low price) • Product summery with quick link

  4. SOAShopper SOA • Enterprise Layer SOAShopper Website • Business Layer Keyword Search Process Set Search parameters • Intermediary layer Search • Basic layer Amazon Web Services eBay Web Services Yahoo! Web Services Business logic

  5. Sequence Diagram <<Front end>> Customer <<Web Appl>> SOAShoppe <<Service>> eBay Web <<Service>> Amazon Web <<Service>> Yahoo! Web Search Request confirm Search Invoke OfferSearch() Invoke OfferSearch() Invoke OfferSearch() Offerlist() Offerlist() Offerlist() Search Response arrange

  6. Technology Architecture of SOAShopper WSDL/SOAP-Based Consumer REST / Ajax based Consumer SOAP Message Internet Provider<Source> SEI SoaShopper std. XML schema Java Objects Java Objects Service Implementation SOAShopper API Integration Layer Java Java Java Yahoo! API eBay API Amazon API SOAP SOAP XML/HTTP Amazon Web Service Yahoo! Web Service eBay Web Service Plain Old XML JAX WS

  7. Technology Architecture of SOAShopper WSDL/SOAP-Based Consumer REST / Ajax based Consumer SOAP Message Internet Provider<Source> SEI SoaShopper std. XML schema Java Objects Java Objects Service Implementation SOAShopper API Integration Layer Java Java Java Yahoo! API eBay API Amazon API SOAP SOAP XML/HTTP Amazon Web Service Yahoo! Web Service eBay Web Service Plain Old XML converted in to java objects by using JAX-WS compiler Manually JAX WS

  8. Technology Architecture of SOAShopper WSDL/SOAP-Based Consumer REST / Ajax based Consumer SOAP Message Internet Provider<Source> SEI SoaShopper std. XML schema Java Objects Java Objects Service Implementation SOAShopper API Integration Layer Java Java Java Yahoo! API eBay API Amazon API SOAP SOAP XML/HTTP Amazon Web Service Yahoo! Web Service eBay Web Service Plain Old XML Standard XML Schema is used to build request massage and response JAX WS

  9. Technology Architecture of SOAShopper WSDL/SOAP-Based Consumer REST / Ajax based Consumer SOAP Message Internet Provider<Source> SEI SoaShopper std. XML schema Java Objects Java Objects Service Implementation SOAShopper API Integration Layer Java Java Java Yahoo! API eBay API Amazon API SOAP SOAP XML/HTTP Amazon Web Service Yahoo! Web Service eBay Web Service Plain Old XML Implementation Layer – Request massage are serialized into java objects. It provides functionality by binding the service on top of base lavel SOAShopper API. i.e. It interprets search request and invokes proper API method . JAX WS

  10. Technology Architecture of SOAShopper WSDL/SOAP-Based Consumer REST / Ajax based Consumer SOAP Message Internet Provider<Source> SEI SoaShopper std. XML schema Java Objects Java Objects Service Implementation SOAShopper API Integration Layer Java Java Java Yahoo! API eBay API Amazon API SOAP SOAP XML/HTTP Amazon Web Service Yahoo! Web Service eBay Web Service Plain Old XML SOAShopper API provides a common wrapper around the shopping service object models. It’s methods Invokes Integration layer JAX WS

  11. Technology Architecture of SOAShopper WSDL/SOAP-Based Consumer REST / Ajax based Consumer SOAP Message Internet Provider<Source> SEI SoaShopper std. XML schema Java Objects Java Objects Service Implementation SOAShopper API Integration Layer Java Java Java Yahoo! API eBay API Amazon API SOAP SOAP XML/HTTP Amazon Web Service Yahoo! Web Service eBay Web Service Plain Old XML Integration layer will implement the interfaces defined by the SOAShopper API to Shopping services’ APIs i.e. It translates/maps the operations into the syntax and semantics of source systems. JAX WS

  12. Bridge Shopper -imp +offerSearch() ComputerShopper CellphoneShopper eBayShopperImp AmazonShopperImp YahooShopperImp eBay Model Amazon Model Yahoo! Model -port -port -port eBayAPIInterface YahooRESTIntrface Integration Layer ShopperImp +offerSearch() AWSECommercService

  13. WSDL to Java Mapping Tool Buildtime eBay Web Service WSDL Service Endpoint Interface SOAP Request Endpoint javax.xml.ws.Service (factory class) SOAP Response getEBayAPI(…) Proxy Instance Parameters (JAXB Generated Class Instance) Service Endpoint Interface Handler Chain Invocation Handler SOAPHandler <SOAPMessageContext> Return Value (JAXB Generated Class Instance) e-Bay (SOAP) services implementation

  14. Yahoo! (REST) services implementation Yahoo! Shopping Web Services: Product Search REST Documentation (Human Readable) Endpoint REST Interface Implementation RESTful Invocation Methods JAX-WS Dispatch JAXbContext Convert REST Documentation to an Interface (Manual Process) XML/HTTP Request XML/HTTP Response Parameters (Query String) Return Value (JAXB-Generated Class Instance)

  15. Software configurations • J2SE 5 (Java 2 Platform, Standard Edition 5) • Java EE 5 (Java Platform, Enterprise Edition 5) • Glassfish application server • Apache Ant 1.7.0 • Apache Maven 2.0 • Netbeans 5.5 enterprise Edition – for BPEL }Build tools

  16. Errors & Solution In main folder Maven installation was successful

  17. Errors & Solution(Contd.) Solution: Change the C:/mark.homepc into the path of commen_built.xml in main pom.xml

  18. Errors & Solution(Contd.) Solution: Change the path of glassfish in the main pom.xml without /bin

  19. Errors & Solution(Contd.) This error is to be resolved. We have asked author for the help in special google group SOA Using Java Web Services

  20. Errors due to backward slash(/) instead of forward slash(\) for setting path • Space in path name (Ex. C:\Documents and settings)

  21. Demo

  22. References • SOA Using Java Web Services – By Mark D Hansen, April 2007. • Ant: The definitive Guide, Second EditionBy Steve Holzner, April 2005 • A Hands-on Introduction to BPEL by Matjaz B Juric, http://www.oracle.com/technology/pub/articles/matjaz_bpel1.html • Adam Sherman http://www.sherman.ca/archives/2004/07/04/maven-vs-ant • www.w3school.com • Google group communication by Cristiano.

  23. Thank you
