  1. Chapter 2 Decision-Making Instructions (Instructions: Language of the Computer Part V)

  2. So far we’ve learned: • MIPS (RISC) Design Principles • Simplicity favors regularity • Smaller is faster • Make the common case fast • Good design demands good compromises • Recent Instructions: add, sub, lw, sw, addi, la, move sll, srl, and, or, andi, ori, nor • Instruction Formats • R-format, I-format Florida A & M University - Department of Computer and Information Sciences

  3. Up to Now • All instructions only manipulate data…we’ve built a calculatorof sorts. • In order to build a computer, we need decision making instructions • alter the control flow, • i.e., change the "next" instruction to be executed address it by supplying a pointer to a memory address Florida A & M University - Department of Computer and Information Sciences

  4. C++ Decisions • Two kinds of decision statements in C++ • if-then • if (condition) consequence • if-then-else • if (condition) consequence else alternative • Rearrange if-then into following: if (condition) goto L1;consequence; L1: Florida A & M University - Department of Computer and Information Sciences

  5. C++ Decisions • Rearrange if-then-else into following: if (condition) goto L1; OR if (condition) goto L1; alternative; consequence; goto L2; goto L2; L1: consequence; L1: alternative; L2: L2: These are not as elegant as C++, but same meaning and easier to translate into MIPS Florida A & M University - Department of Computer and Information Sciences

  6. Conditional Branches • When condition branch to instruction label; otherwise continue sequentially. • beqrs, rt, L1 • beq is “branch if registers are equal” • if (rs == rt) branch to instruction labeled L1; • bners, rt, L1 • bne is “branch if registers are not equal” • if (rs != rt) branch to instruction labeled L1; Florida A & M University - Department of Computer and Information Sciences

  7. Unconditional Branch • jlabel • Jump Instruction: jump (or branch) directly to the given label • Same meaning as goto label in C++ • Technically, it has the same effect as: beq $0,$0,label Florida A & M University - Department of Computer and Information Sciences

  8. (false) i != j (true) i == j i == j? f=g+h Done Compiling if Statements • C++ statement if (i == j) f = g + h; • Variable/register relationship: f : $s0 g : $s1 h : $s2 i : $s3 j : $s4 bne $s3,$s4,Doneadd $s0,$s1,$s2 Done: Note: Compiler automatically creates labels (e.g. Done) to handle decisions (branches). Generally not found in HLL code. Florida A & M University - Department of Computer and Information Sciences

  9. (false) i == j (true) i != j i != j? f=g+h f=g-h Done Compiling if Statements • C++ statement if (i != j) f = g + h; else f = g – h; • Variable/register mapping: I /$s3 , j / $s4  j; f $s0, g/$s1, h/$s2 Florida A & M University - Department of Computer and Information Sciences

  10. (false) i == j (true) i != j i != j? f=g+h f=g-h Fini: Compiling if Statements • MIPS beq $s3,$s4,Fadd $s0,$s1,$s2)jFini F: sub $s0,$s1,$s2 Fini: F: Florida A & M University - Department of Computer and Information Sciences

  11. MIPS Labels • A branch label indicates the addressof the memory word where the instruction is stored Florida A & M University - Department of Computer and Information Sciences

  12. Conditional Branches • Instruction Syntax: 1 2, 3, 4 • where 1 : operation name 2 : first register operand 3 : second register operand 4 : label that represents the offset in number of instructions or words from the next instruction (i.e., PC +4 ) Florida A & M University - Department of Computer and Information Sciences

  13. Conditional Branch The assembler relieves the assembly language programmer from the tedium of calculating addresses for branches Florida A & M University - Department of Computer and Information Sciences

  14. MIPS:Semantics of Branching • If we don’t take the branch: PC = PC + 4 • If we do take the branch: PC = (PC + 4) + (immediate* 4) • Observations • Immediate field specifies the number of words to jump, which is simply the number of instructions to jump. • Immediate field can be positive or negative. • Due to hardware, add immediate to (PC+4), not to PC; will be clearer why later in course Florida A & M University - Department of Computer and Information Sciences

  15. C++ Loops • Simple loop in C do { sum = sum + k; k = k + 1; } while ( k != 100); • Rewrite this as: Loop: sum = sum + k; k= k + 1; if (k != 100) goto Loop; Florida A & M University - Department of Computer and Information Sciences

  16. Compiling Loop Statements • Rewritten loop: Loop: sum = sum + k; k = k + 1; if (k != 100) goto Loop; • MIPS : // $t1 = k; $t2 = sum; $t3 = 100; li $t3,100 # $t3  100 Loop: add $t2, $t2, $t1 # sum  sum + I addi $t1, $t1, 1 # i  I + 1 bne $t1, $t3, Loop # goto Loop if i != 100 Florida A & M University - Department of Computer and Information Sciences

  17. C++ Loops • There are three types of loops in C++: • while • do while • for • Each can be rewritten as either of the other two, so the method used in the previous example can be applied to while and for loops as well. • Key Concept: Though there are multiple ways of writing a loop in MIPS, the key to decision making is the conditional branch Florida A & M University - Department of Computer and Information Sciences

  18. Basic Blocks A basic block is a sequence of instructions with No embedded branches (except at end) No branch targets (except at beginning) • A compiler identifies basic blocks for optimization • An advanced processor can accelerate execution of basic blocks Florida A & M University - Department of Computer and Information Sciences

  19. More Conditional Operations • Up to now, only tested equalities (== or != in C++). Generally, programs need to test <, ≤, > and ≥ as well • Set result to 1 if a condition is true; else 0 • Similar to Halix COMPARE instructions • slt rd, rs, rt • if (rs < rt) rd = 1; else rd = 0; • slti rt, rs, constant • if (rs < constant) rt = 1; else rt = 0;“ Florida A & M University - Department of Computer and Information Sciences

  20. More Conditional Operations • Use in combination with beq, bne • C++ Statement: if (g < h) goto L1; • Compiled to MIPS: • slt $t0,$s0,$s1 bne $t0,$0,L1 • Register $0 always contains the value 0, so bne and beq often use it for comparison after an slt instruction Florida A & M University - Department of Computer and Information Sciences

  21. More Conditional Operations • Use in combination with beq, bne • C++ Statement: if (g >= 1) goto L1; • Compiled MIPS: • slti $t0, $s0, 1 # immediatebeq $t0, $0, Loop Florida A & M University - Department of Computer and Information Sciences

  22. More Conditional Operations • Now, we can implement <, but how do we implement >, ≤ and ≥ ? • We could add 3 more instructions, but: • MIPS goal: Simpler is Better • Can we implement ≤ in one or more instructions using just slt and the branches? • What about >? What about ≥? • 4 combinations of slt and (beq or bne) Florida A & M University - Department of Computer and Information Sciences

  23. More Conditional Operations • if (g < h) goto Less; • slt $t0, $s0, $s1 # $t0 = 1 if g < h bne $t0, $zero, Less # if (g < h) goto Less • if (g >= h) goto Gteq; • slt $t0, $s0, $s1 # $t0 = 1 if g < h beq $t0, $zero, Gteq # if (g >= h) goto Gteq • if (g > h) goto Grtr; • slt $t0, $s1, $s0 # $t0 = 1 if g > h bne $t0, $zero, Grtr # if (g > h) goto Grtr • if (g <= h) goto Lteq; • slt $t0, $s1, $s0 # $t0 = 1 if g > h beq $t0, $zero, Lteq # if (g <= h) goto Lteq Florida A & M University - Department of Computer and Information Sciences

  24. Branch Instruction Design Why not blt, bge, etc? Hardware for <, ≥, … slower than =, ≠ Combining with branch involves more work per instruction, requiring a slower clock All instructions penalized! beq and bne are the common case This is a good design compromise Florida A & M University - Department of Computer and Information Sciences

  25. Pseudoinstructions (Assembler) • if (g < h) goto LT; • blt $s0, $s1, LT • if (g >= h) goto GTE; • bge $s0, $s1, GTE • if (g > h) goto GRTR; • bgt $s0, $s1, GRTR • if (g <= h) goto LTE; • ble $s0, $s1, LTE Florida A & M University - Department of Computer and Information Sciences

  26. More Conditional Operations Florida A & M University - Department of Computer and Information Sciences

  27. Signed vs. Unsigned Signed comparison: slt, slti Unsigned comparison: sltu, sltui Example $s0 = 1111 1111 1111 1111 1111 1111 1111 1111 $s1 = 0000 0000 0000 0000 0000 0000 0000 0001 slt $t0, $s0, $s1 # signed –1 < +1  $t0 = 1 sltu $t0, $s0, $s1 # unsigned +4,294,967,295 > +1  $t0 = 0 Florida A & M University - Department of Computer and Information Sciences
