  1. Inventory Database Group one is: Mike Rucker Lue Yang Chuck Smothers Tabitha Guion Isaac Chellepo

  2. Transition of the code to database (4E0004376D10) (4E0004376D10)

  3. (4E0004376D10) 4 1 4. As the coil gets the power, it transmits its code, which the RFID reader then captures 2 3 1. RFID reader broadcasts signal to a tag. 2. Antenna in the tag receives the signal, sending the energy to the capacitor. 3. When the capacitor is fully charged, it releases energy to the coils

  4. Begin Unloading Form Flow Chart Loading Form Flow Chart Begin Set Communications parameters Unload Serial Com object Exit Begin Listening A closer look at the methods and how information flows inside each one. Serial port error? Yes Display Error Exit No

  5. Begin Serial port event handler - Flow Chart (4E0004376D10) Accept value from COM port (USB) Exit Is this appropriate data? No Refresh Form Me.Refresh Yes Set Form record Me.LastSeen = Now() Trim whitespace Yes Found match? Found match? Display error Seek Record No Me.LastSeen = Now()

  6. Conclusion
