  1. Executing Boot PROM Commands

  2. Boot PROM Fundamentals • All Sun systems have resident boot PROM firmware • Provides basic hardware testing and initialization prior to booting • Enables to boot from wide range of devices • Has access to a standard set of generic device drivers

  3. Goal of the OpenBoot Architecture Standard • Goal of IEEE standard for the OpenBoot Architecture • Test and initialize system hardware • Determine the system’s hardware configuration • Boot the Operating Environment • Provide an interactive interface for configuration, testing, and debugging • Enable the use of third-party devices

  4. Boot PROM • Each system has a boot PROM chip • 1 Mbyte chip is typically located on the same board as the CPU • Boot PROM chips are usually found in a pluggable socket on older systems • As of 3.x PROM, they are permanently soldered to the main system board

  5. The Ultra workstations use a reprogrammable boot PROM called Flash PROM (FPROM) • Desktop systems have a write-protect jumper

  6. The main functions of the boot PROM are to test the system hardware and to boot the OE. • The boot PROM firmware is referred to as the “monitor program” • Also provides a user interface and firmware utility commands, known as the FORTH command set

  7. Generations of Sun boot PROM • 1.x - The first boot PROM used on SPARC systems • 2.x - The first Openboot PROM • 3.x - The Openboot PROM with a flash update feature • 4.x - The Openboot PROM that supports the 64-bit UltraSPARC III processor • 5.x - Available on the Sun Enterprise 3500, 4500, 5500 & 6500 servers

  8. To determine which version of OpenBoot PROM is running on the system • “# /usr/platform/’uname -m’/sbin/prtdiag -v”

  9. NVRAM • Important hardware element • Removable chip is often located on the main system board • Contains EEPROM • EEPROM stores user-configurable parameters that have been changed or customized from the boot PROM’s default parameter settings • Single lithium battery within the NVRAM module provides battery backup for the NVRAM and the clock

  10. NVRAM contains editable and noneditable areas. • Non Editable areas • The Ethernet address • The system host ID • Editable areas • The time-of-day (TOD) clock value • The configuration data describing system operating parameters • A diagnostic mode switch that enables or disables POST • The device name and the path to the default boot device • A location for customized programming that is used during the boot process

  11. POST • When a system’s power is turned on, a low-level POST is initiated • Low-level POST code is stored in the boot PROM and is designed to test the basic functions of the system hardware

  12. On successful completion of the low-level POST phase, the boot PROM firmware takes the control and performs the following initialization sequence: • Probes the memory and then CPU • Probes bus devices, interprets their drivers, and builds a device tree • Installs the console

  13. After the boot PROM initializes the system, the banner displays on the system console • The system checks parameters stored in the boot PROM and NVRAM determine if and how to boot the OE

  14. Controlling the POST phase • Stop-D key sequence • Hold down the Stop and D keys simultaneously while system power is turned on, and the firmware automatically switches to diagnostic mode. • This mode runs extensive POST diagnostics on the system hardware. • The OpenBoot PROM variable “diag-switch?” is set to “true”

  15. Stop-N key sequence • Hold down to set the NVRAM parameters to the default values • Can release the keys on seeing the LEDs on the keyboard begins to flash

  16. Stop-A key sequence • To interrupt any program that is running at the time these keys are pressed and to put the system into the command entry mode for the OpenBoot PROM • Not recommended unless there is absolutely no alternative

  17. Disabling the Abort Sequence • Edit the “/etc/default/kbd” file • Remove the comment from in front of “KEYBOARD_ABORT=disable” • Save the file and execute the command “kbd -i” • When the above steps are completed the system allows Stop-A key sequence only during the boot process

  18. Displaying POST to the Serial Port • Can attach a terminal to the serial port of a system to capture a far greater amount of information from the POST output • When the power is turned on POST looks for a keyboard, if there is no keyboard present, POST diverts system output to serial port A

  19. POST runs more extensive tests when the system is in diagnostics mode with the PROM parameter “diag-switch?” set to “true” • Be sure to attach the correct type of null modem cable for your system type to serial port A
