  1. Representing and Manipulating Hardware in Standard C and C++ by Dan Saks

  2. Overview • This presentation was about • hardware manipulation using ANSI C and ANSI C++ • common idioms for controlling devices • make code more portable

  3. Aids for Embedded Programming • Features provided by C and C++ • bitwise operators and bitfields • const qualifier • volatile qualifier • type sig_atomic_t • Feature provided by C++ • Class concept (encapsulation of hardware)

  4. I/O Architectures • Presentation was especially about memory mapped i/o architectures (ex. Motorola) • C and C++ are best at MMIO • Port I/O was tackled at the end

  5. Basic Techniques • How to represent a register • use the correspondent type (eg. one byte => char) • How to assign an adres to a variable in C/C++ • not possible • solution: declare a pointer with the specified adres • How to change bits in a register • use masks • Use structs when registers are physically colocated

  6. Compiler optimizations • Several compiler optimizations are based on variables • distinction `standard` variable and `device` variable is not made by compiler • compiler could alter program making it incorrect • use the keyword `volatile` • for a volatile variable the compiler will not make optimizitions

  7. More Advanced Topics • Access the register on a per bit base • use a struct • often big/little endian problems • Classes • public functions are used to read/write values • overhead can be eliminated thanks to inlining • the object encapsulates exact position/structure of register • Write-only registers

  8. More Advanced Topics • Port I/O • no standard C or C++ solution • rely on ASM or language extensions • Interrupt Handling • als no standard C or C++ solution • rely on ASM or language extensions • sig_atomic_t: use it in asynchronous environments (as environments where interrupts occur)

  9. Conclusion • Tutorial was ... • interesting for C/C++ programmers • not groundbreaking in terms of new concepts • interesting part (use of classes) not seen in depth
