  1. All You Need to Know AboutMultiple Flexible Circuits

  2. Capel Technology are professional Flexible circuit and Flex-Rigid PCB manufacturer for more than 10 years, which are focusing on the Research, Development, Design ,Predicting 1-12layer Flex PCB, 4-14 layers Flex-Rigid PCB. The Products are widely used in Mobile, Communication, Smart home, Optoelectronics, and Industrial control, Medical Equipment, Automobile and Consumer Electronics and so on.

  3. Single layer flex Circuit is the most basic and consists of a flexible polyimide film laminated to a thin sheet of copper. The copper layer is then chemically etched to produce a circuit pattern specific to your specific design requirements. A polyimide overlay is then added for insulation and environmental protection of the circuit.

  4. Double sided flex circuit Double sided flex circuit is a circuit having two conductive layers, one on each side of the base layer of polyimide within the circuit. Trace patterns, specific to your needs, can be created on both sides of the substrate film and can be connected where desired with copper plated through-holes. The plated through holes make electrical connections between the two layers.

  5. Multi-layer flex circuit Multi-layer flex circuit combine several single-sided or double-sided circuits with complex interconnections, shielding and/or surface mounted technologies in a multi-layer design. The multi layers may or may not be continuously laminated together throughout the production process. If your design needs require maximum flexibility, continuous lamination may not be appropriate. Multi-layer circuits are an effective solution when confronted with design challenges such as: unavoidable crossovers, specific impedance requirements, elimination of crosstalk, additional shielding and high component density.

  6. Rigid flex circuits Rigid flex circuits have been used in the military and aerospace industries for more than 20 years. In most rigid flex circuit boards, the circuitry consists of multiple flexible circuit inner layers selectively attached together using an epoxy pre-preg bonding film, similar to a multilayer flexible circuit. However, a multilayer rigid flex circuit incorporates a board externally, internally or both as needed to accomplish the design.

  7. Contact Us Address:22,Science Park,The Northern part of HeYi Village City:Shenzhen State:GuangDong Zip Code:518104 Country:China Email:sales@kbefpc.com Website: https://www.cplfpc.com/ Twitter:https://twitter.com/capeltechnology/ Facebook:https://www.facebook.com/capeltechnology/ Linkedin.com:https://www.linkedin.com/company/capeltechnology/ Pinterest.com:https://pinterest.com/capeltechnology/ Instagram.com:https://www.instagram.com/capeltechnology/ Youtube.com:https://www.youtube.com/watch?v=9oCVhAHSVD4

  8. Thank you…
