    1. THE SUN The star we see but seldom notice

    2. Goals Summarize the overall properties of the Sun. What are the different parts of the Sun and how do we know this? Where does the light we see come from? Solar activity and magnetic fields.

    3. The Sun, Our Star The Sun is an average star. From the Sun, we base our understanding of all stars in the Universe. Like Jovian Planets its a giant ball of gas. No solid surface.

    4. Vital Statistics Radius = 100 x Earth (696,000 km) Mass = 300,000 x Earth (1.99 x 1030 kg) Surface temp = 5780 K Core temp = 15,000,000 K Luminosity = 4 x 1026 Watts Solar Day = 24.9 Earth days (equator) 29.8 Earth days (poles)

    5. Structure Surface Photosphere Atmosphere Chromosphere Transistion zone Corona Solar wind Interior Convection zone Radiation zone Core

    6. The Solar Interior How do we know whats inside the Sun? Observe the outside. Theorize what happens on the inside. Complex computer programs model the theory. Model predicts what will happen on the outside. Compare model prediction with observations of the outside. Scientific Method!

    7. Helioseismology Continuous monitoring of Sun. Ground based observatories One spacecraft (SOHO) Surface of the Sun is ringing Sound waves cross the the solar interior and reflect off of the surface (photosphere).

    8. Interior Properties Core = 20 x density of iron Surface = 10,000 x less dense than air Average density = Jupiter Core = 15,000,000 K Surface = 5780 K

    9. Do you see the light? Everything in the solar system reflects light. Everything also absorbs light and heats up producing blackbody radiation. Q: Where does this light come from? A: The Sun. But where does the Suns light come from?

    10. Our Journey through the Sun Journey from the Suns core to the edge of its atmosphere. See where its light originates. See what the different regions of the Sun are like. See how energy in the core makes it to the light we see on Earth.

    11. In The Core Density = 20 x density of Iron Temperature = 15,000,000 K Hydrogen atoms fuse together Create Helium atoms.

    12. Nuclear Fusion 4H ? He The mass of 4 H atoms: 4 x (1.674 x10-27 kg) = 6.694 x 10-27 kg The mass of He atom: = 6.646 x 10-27 kg Where does the extra 4.8 x 10-29 kg go? ENERGY! ? E = mc2 E = (4.8 x 10-29 kg ) x (3.0 x 108 m/s)2 E = hc/l ? l = 4.6 x 10-14 m (gamma rays) So: 4H ? He + light!

    13. The Radiation Zone This region is transparent to light. Why? At the temperatures near the core all atoms are ionized. Electrons float freely from nuclei If light wave hits atom, no electron to absorb it. So: Light and atoms dont interact. Energy is passed from core, through this region, and towards surface by radiation.

    14. The Convection Zone This region is totally opaque to light. Why? Closer to surface, the temperature is cooler. Atoms are no longer ionized. Electrons around nuclei can absorb light from below. No light from core ever reaches the surface! But where does the energy in the light go? Energy instead makes it to the surface by convection.

    15. Convection A pot of boiling water: Hot material rises. Cooler material sinks. The energy from the pots hot bottom is physically carried by the convection cells in the water to the surface. Same for the Sun.

    16. Solar Cross-Section Progressively smaller convection cells carry the energy towards surface. See tops of these cells as granules.

    17. The Photosphere This is the origin of the 5800 K blackbody radiation we see. Why? At the photosphere, the density is so low that the gas is again transparent to light. The hot convection cell tops radiate energy as a function of their temperature (5800 K). l = k/T = k/(5800 K) ? l = 480 nm (visible light) This is the light we see. Thats why we see this as the surface.

    18. The Solar Atmosphere Above the photosphere, transparent to light. Unlike radiative zone, here atoms not totally ionized. Therefore, there are electrons in atoms able to absorb light. Absorption lines in solar spectrum are from these layers in the atmosphere.

    19. Atmospheric Composition Probably same as interior. Same as seen on Jupiter. Same as the rest of the Universe.

    20. The Chromosphere Very low density But also very hot Same as the gas tubes we saw in class and lab. Energy from below excites the atoms and produces emission from this layer. Predominant element Hydrogen. Brightest hydrogen line Ha. Chromosphere = color

    21. Spicules and Prominences Emission from the atmosphere is very faint relative to photosphere. Violent storms in the Chromosphere. Giant curved prominances Long thin spicules.

    22. Prominences

    24. Ha Sun

    25. Corona Spicules and other magnetic activity carry energy up to the Transition Zone. 10,000 km above photosphere. Temperature climbs to 1,000,000 K Remember photosphere is only 5800 K The hot, low density, gas at this altitude emits the radiation we see as the Corona.

    27. The X-Ray Sun Q: At 1,000,000 K where does a blackbody spectrum have its peak? A: X-rays Can monitor the Solar Coronasphere in the X-ray spectrum. Monitor Coronal Holes

    29. Solar Wind At and above the corona: Gas is very hot Very energetic Like steam above our boiling pot of water, the gas evaporates. Wind passes out through Coronal Holes Solar Wind carries away a million tons of Suns mass each second! Only 0.1% of total Suns mass in last 4.6 billion years.

    30. The Aurora The solar wind passes out through the Solar System. Consists of electrons, protons and other charged particles stripped from the Suns surface. Interaction with planetary magnetic fields gives rise to the aurora.

    31. The Active Sun Solar luminosity is nearly constant. Very slight fluctuations. 11-year cycle of activity.

    32. Solar Cycle Increase in Coronal holes Increase in solar wind activity - Coronal Mass Ejections Increase in Auroral displays on Earth Increase in disruptions on and around Earth.

    33. Sunspots

    34. Can see that Sun doesnt rotate as a solid body? Equator rotates faster. This differential rotation leads to complications in the Solar magnetic field.

    35. Magnetic fields and Sunspots At kinks, disruption in convection cells. Sunspots form.

    36. Magnetic fields and Sunspots Sunspots come in pairs. Opposite orientation in North and South. Every other cycle the magnetic fields switch.

    37. Sunspot Numbers

    38. Active Regions Areas around sunspots give rise to the prominences
